W773-W80

GPU Workstation - Intel® Xeon® W-3500/2500/3400/2400 - UP
  • Supports up to 4 x Dual slot Gen5 GPUs
  • Single Intel® Xeon® W-3500/3400 Processors
  • Single Intel® Xeon® W-2500/2400 Processors*
  • 8-Channel DDR5 RDIMM/3DS-RDIMM, 8 x DIMMs
  • Intel® W790 Chipset
  • 2 x 10Gb/s LAN ports via Intel® X710-AT2
  • 2 x M.2 slots with PCIe Gen4 x4 interface
  • Up to 8 x 3.5"/2.5" SATA bays
  • 5 x PCIe Gen5 x16 slots
  • 2 x PCIe Gen4 x16 slots
  • Single 2000W ATX 80 PLUS Gold power supply
Get a Quote
* 以上產品之規格、圖片及其他資訊僅供參考,如與實際產品有任何不相符之處,應以實際產品為準。技嘉科技保留在任何時間做出修改之權利。對任何因使用上述資料而引致之損失,技嘉科技概不承擔任何責任。
* 本產品所標示之各項效能表現為各晶片廠商或各制定介面官方組織所提出的最大理論值,實際效能可能因規格及設備而有所不同。
* 本文中所使用之各項商標及企業識別圖示,均為其合法所有人之財產。
* 基於PC基本架構,有部分記憶體空間須留作系統用途,故所偵測到之記憶體大小會比實際上較少。

SPECIFICATIONS

Dimensions (WxHxD, mm)
Pedestal
218 x 455 x 726.3
Motherboard
MW83-RP0
CPU
Intel® Xeon® W-3500 Processors
Intel® Xeon® W-2500 Processors*
Intel® Xeon® W-3400 Processors
Intel® Xeon® W-2400 Processors*
Single processor, TDP up to 385W

*Carriers for Intel® Xeon® W-2500/2400 Processors are not included. Please refer to the optional parts for proper support.

Notice: Please select Intel® Xeon® W-3500/3400 Processors to enable all functions.
Socket
1 x LGA 4677
Socket E
Chipset
Intel® W790
Memory
*8 x DIMM slots
DDR5 memory supported only
8-channel memory architecture
RDIMM up to 64GB supported
3DS RDIMM up to 256GB supported
Memory speed: Up to 4800 MT/s

*Only 4 x DIMM slots are supported with Intel® Xeon® W-2500/2400 Processors.

Note: When installing memory modules, make sure to begin with the first socket of each channel, such as DIMM_P0_A0, DIMM_P0_B0, DIMM_P0_C0, DIMM_P0_D0.
LAN
2 x 10Gb/s LAN ports (1 x Intel® X710-AT2)
Support NCSI function

1 x 10/100/1000 Mbps Management LAN
Video
Integrated in Aspeed® AST2600
- 1 x VGA port
Audio
Realtek® ALC897 HD Audio Codec
Supports 2/4/5.1/7.1 channel configurations
Rear 3 x Audio jacks (Audio in/Audio out/Mic)
Front 2 x Audio jacks (Audio out/Mic)
Storage
4 x 3.5"/2.5" SATA hot-swappable bays
Additional 4 x 3.5"/2.5" SATA hot-swappable bays (optional)

Note: Storage card is required to support NVMe and SAS drives.
RAID
Intel® SATA RAID 0/1/10/5
Peripheral Drives
5.25" space reserved for ODD device
Expansion Slots
Slot_7: PCIe x16 (Gen5 x16) slot, from CPU
Slot_6: PCIe x16 (Gen5 x16) slot, from CPU*
Slot_5: PCIe x16 (Gen5 x16) slot, from CPU*
Slot_4: PCIe x16 (Gen5 x16) slot, from CPU*
Slot_3: PCIe x16 (Gen4 x16) slot, from CPU
Slot_2: PCIe x16 (Gen5 x16) slot, from CPU
Slot_1: PCIe x16 (Gen4 x16) slot, from CPU

2 x M.2 slots:
- M-key
- PCIe Gen4 x4, from PCH
- Supports 2280 cards

*Slot_4/5/6 are not supported with Intel® Xeon® W-2500/2400 Processors.
Internal I/O
1 x TPM header
1 x VROC connector
Front I/O
2 x USB 3.2 Gen1 (Type-A)
2 x Audio jacks (Audio out/Mic)
1 x Power button
1 x Reset button
1 x Power LED
1 x Storage activity LED
1 x System status LED
Rear I/O
1 x USB 3.2 Gen2x2 (Type-C)
3 x USB 3.2 Gen2x1 (Type-A)
1 x VGA
1 x COM
2 x RJ45
1 x MLAN
3 x Audio jacks (Audio in/Audio out/Mic)
1 x ID button with LED
TPM
1 x TPM header with SPI interface
- Optional TPM2.0 kit: CTM010
Power Supply
Single 2000W ATX 80 PLUS Gold power supply

AC Input:
- 100-240V~/ 15-12A, 60-50Hz

DC Output:
- Max 1200W/ 100-115V~
+12V/ 100A
+5V/ 25A
+3.3V/ 25A
+5Vsb/ 4A
- Max 1500W/ 115-200V~
+12V/ 125A
+5V/ 25A
+3.3V/ 25A
+5Vsb/ 4A
- Max 2000W/ 200-240V~
+12V/ 166.6A
+5V/ 25A
+3.3V/ 25A
+5Vsb/ 4A

Note: The system power supply requires C19 power cord.

Note: 220-240V AC input is recommended for optimized user experience.
System Management
ASPEED® AST2600 Baseboard Management Controller
GIGABYTE Management Console web interface

  • Dashboard
  • HTML5 KVM
  • Sensor Monitor (Voltage, RPM, Temperature, CPU Status …etc.)
  • Sensor Reading History Data
  • FRU Information
  • SEL Log in Linear Storage / Circular Storage Policy
  • Hardware Inventory
  • Fan Profile
  • System Firewall
  • Power Consumption
  • Power Control
  • Advanced power capping
  • LDAP / AD / RADIUS Support
  • Backup & Restore Configuration
  • Remote BIOS/BMC/CPLD Update
  • Event Log Filter
  • User Management
  • Media Redirection Settings
  • PAM Order Settings
  • SSL Settings
  • SMTP Settings
OS Compatibility
CentOS Stream 9 (x64)
Debian 11.5.0
Red Hat Enterprise Linux 9.0 (x64)
Ubuntu 22.04 LTS (x64)
Windows 11 Enterprise (x64)
System Fans
Middle fan: 3 x 120x120x38mm (4,000 rpm)
Rear fan: 1 x 120x120x25mm (2,800 rpm)
Operating Properties
Operating temperature: 10°C to 30°C
Operating humidity: 8-80% (non-condensing)
Non-operating temperature: -40°C to 60°C
Non-operating humidity: 20%-95% (non-condensing)
Packaging Dimensions
1045 x 588 x 403 mm
Packaging Content
1 x W773-W80
1 x CPU fansink
*1 x W-3500/3400 (E1A) carrier

*Carriers for Intel® Xeon® W-2500/2400 Processors are not included. Please refer to the optional parts for proper support.
Part Numbers
- Barebone package (Refresh): 6NW773W80MR-000-3*
- Barebone package: 6NW773W80MR-000-1*
- Motherboard: 9MW83RP0MR-000
- I/O shield: 12AIO-MW83RP-00R
- CPU fansink: 25ST0-0Z9221-A3R
- W-3500/3400 (E1A) carrier: 12KRC-0I4677-00R
- M.2 heatsink: 12SP2-080027-00R
- Middle fan: 25ST2-113824-S1R
- Rear fan: 25ST2-112522-S1R
- Power supply: 25EP0-22000I-F3S

Optional parts:

- W-2500/2400 (E1B) carrier: 12KRC-0I4677-12R
- Rail kit for W7x3 series ((A)+(B)+(C)+(D)):
  (A) 25HB2-A66126-K0R (Slide Rail), Q'ty: 1 set
  (B) 25HB4-W77304-C0R (Rack Ear Right), Q'ty: 1 set
  (C) 25HB4-W77305-C0R (Rack Ear Left), Q'ty: 1 set
  (D) 25HB7-W77300-C0R (Top Cover for Assembly), Q'ty: 1 set
