W281-G40
已停產
High Performance Workstation
- High performance tower workstation / e-business server
- Intel® Xeon® W-2200 and W-2100 Processor Family
- Single processor, LGA 2066
- Intel® C422 Chipset
- Quad Channel RDIMM/LRDIMM DDR4, 8 x DIMMs
- Intel® VROC ready
- Realtek ALC1150 HD audio codec
- 2 x GbE LAN ports (Intel® I210)
- 4 x 3.5"/2.5" SATAIII HDD/SSD bays
- 1 x 2.5" SATAIII internal fixed drive bay
- 1 x M.2 slot with PCIe Gen3 x4 interface
- 1 x U.2 connector with PCIe Gen3 x4 interface
- 7 x PCIe Gen3 x16 and x8 slots
- Single 1200W 80 PLUS Gold power supply
* 以上產品之規格、圖片及其他資訊僅供參考，如與實際產品有任何不相符之處，應以實際產品為準。技嘉科技保留在任何時間做出修改之權利。對任何因使用上述資料而引致之損失，技嘉科技概不承擔任何責任。
* 本產品所標示之各項效能表現為各晶片廠商或各制定介面官方組織所提出的最大理論值，實際效能可能因規格及設備而有所不同。
* 本文中所使用之各項商標及企業識別圖示，均為其合法所有人之財產。
* 基於PC基本架構，有部分記憶體空間須留作系統用途，故所偵測到之記憶體大小會比實際上較少。
* 本產品所標示之各項效能表現為各晶片廠商或各制定介面官方組織所提出的最大理論值，實際效能可能因規格及設備而有所不同。
* 本文中所使用之各項商標及企業識別圖示，均為其合法所有人之財產。
* 基於PC基本架構，有部分記憶體空間須留作系統用途，故所偵測到之記憶體大小會比實際上較少。
SPECIFICATIONS
Dimensions (WxHxD, mm)
Pedestal
438 x 178 x 595
438 x 178 x 595
Motherboard
CPU
Intel® Xeon® W-2200 and W-2100 Processor Family
Single processor, TDP up to 165W
Single processor, TDP up to 165W
Socket
1 x LGA 2066
Socket R4
Mounting pitch: square ILM (80x80mm)
Socket R4
Mounting pitch: square ILM (80x80mm)
Chipset
Intel® C422 Chipset
Memory
8 x DIMM slots
DDR4 memory module supported only
Quad channel memory architecture
RDIMM modules up to 64GB supported
LRDIMM modules up to 128GB supported
1.2V modules: 2666/2400/2133/1866 MHz
NOTE: When installing memory modules, make sure to begin with the first socket of each channel, such as DIMM_P0_A0, DIMM_P0_B0, DIMM_P0_C0, DIMM_P0_D0
DDR4 memory module supported only
Quad channel memory architecture
RDIMM modules up to 64GB supported
LRDIMM modules up to 128GB supported
1.2V modules: 2666/2400/2133/1866 MHz
NOTE: When installing memory modules, make sure to begin with the first socket of each channel, such as DIMM_P0_A0, DIMM_P0_B0, DIMM_P0_C0, DIMM_P0_D0
LAN
2 x GbE LAN ports (Intel® I210)
Video
N/A
Audio
Realtek® ALC1150 HD audio codec
Supports 7.1 channel configurations
Supports 7.1 channel configurations
Storage
4 x 3.5"/2.5" HDD/SSD bays
1 x 2.5" SATAIII internal fixed drive bay
SATA devices supported only
1 x 2.5" SATAIII internal fixed drive bay
SATA devices supported only
RAID
Intel® SATA RAID 0/1/10/5
Peripheral Drives
N/A
Expansion Slots
Slot_7: 1 x PCIe x16 (Gen3 x16) slot, from CPU
Slot_6: 1 x PCIe x16 (Gen3 x0 or x8) slot, from CPU
Slot_5: 1 x PCIe x16 (Gen3 x16 or x8) slot, from CPU, shared with slot_6
Slot_4: 1 x PCIe x16 (Gen3 x0 or x8) slot, from PEX8747
Slot_3: 1 x PCIe x16 (Gen3 x16 or x8) slot, from PEX8747, shared with slot_4
Slot_2: 1 x PCIe x16 (Gen3 x0 or x8) slot, from PEX8747
Slot_1: 1 x PCIe x16 (Gen3 x16 or x8) slot, from PEX8747, shared with slot_2
1 x M.2 slot:
- M-key
- PCIe Gen3 x4, from C422
- Supports NGFF-2242/2260/2280/22110 cards
Supports NVIDIA® SLI™ and AMD® CrossFireX™ technologies
NOTE: Graphic card requests UEFI-ready
Slot_6: 1 x PCIe x16 (Gen3 x0 or x8) slot, from CPU
Slot_5: 1 x PCIe x16 (Gen3 x16 or x8) slot, from CPU, shared with slot_6
Slot_4: 1 x PCIe x16 (Gen3 x0 or x8) slot, from PEX8747
Slot_3: 1 x PCIe x16 (Gen3 x16 or x8) slot, from PEX8747, shared with slot_4
Slot_2: 1 x PCIe x16 (Gen3 x0 or x8) slot, from PEX8747
Slot_1: 1 x PCIe x16 (Gen3 x16 or x8) slot, from PEX8747, shared with slot_2
1 x M.2 slot:
- M-key
- PCIe Gen3 x4, from C422
- Supports NGFF-2242/2260/2280/22110 cards
Supports NVIDIA® SLI™ and AMD® CrossFireX™ technologies
NOTE: Graphic card requests UEFI-ready
Internal I/O
1 x 24-pin ATX main power connector
1 x 8-pin ATX 12V power connector
1 x 4-pin and 1 x 3-pin for GPU power connectors
1 x CPU fan header
5 x System fan headers
2 x USB 3.0 headers for 4 ports
1 x USB 2.0 header for 2 ports
1 x Front audio header
1 x PMBus connector
1 x Clear CMOS jumper
10 x SATA III 6Gb/s ports
2 x SATA DOM jumpers
2 x SATA DOM SGPIO connectors
1 x ME update jumper
1 x M.2 slot
1 x U.2 connector
1 x Front panel header
1 x Backplane board header
2 x COM headers
1 x TPM header
1 x VROC connector
1 x BIOS recovery jumper
1 x Buzzer
1 x 8-pin ATX 12V power connector
1 x 4-pin and 1 x 3-pin for GPU power connectors
1 x CPU fan header
5 x System fan headers
2 x USB 3.0 headers for 4 ports
1 x USB 2.0 header for 2 ports
1 x Front audio header
1 x PMBus connector
1 x Clear CMOS jumper
10 x SATA III 6Gb/s ports
2 x SATA DOM jumpers
2 x SATA DOM SGPIO connectors
1 x ME update jumper
1 x M.2 slot
1 x U.2 connector
1 x Front panel header
1 x Backplane board header
2 x COM headers
1 x TPM header
1 x VROC connector
1 x BIOS recovery jumper
1 x Buzzer
Front I/O
2 x USB 3.0
1 x Power button with LED
1 x Reset button
1 x Power LED
1 x System status LED
1 x HDD activity LED
2 x LAN activity LEDs
Hard drive cage:
1 x Fan filed LED
1 x Over temperature LED
1 x Cage Buzzer Disable button
1 x Power button with LED
1 x Reset button
1 x Power LED
1 x System status LED
1 x HDD activity LED
2 x LAN activity LEDs
Hard drive cage:
1 x Fan filed LED
1 x Over temperature LED
1 x Cage Buzzer Disable button
Rear I/O
1 x PS/2
8 x USB 3.0
2 x USB 3.1 (red) in Type-A and Type-C (5V/3A)
2 x RJ45
5 x Audio jacks
1 x Optical S/PDIF-Out
8 x USB 3.0
2 x USB 3.1 (red) in Type-A and Type-C (5V/3A)
2 x RJ45
5 x Audio jacks
1 x Optical S/PDIF-Out
TPM
1 x TPM header
Power Supply
1 x 1200W 80 PLUS Gold PSU
AC Input:
100-240V~, 16-8A, 50-60Hz
DC Output:
Max. 1200W
+12V/ 100A
+5V/ 30A
+3.3V/ 30A
-12V/ 0.8A
+5Vsb/ 4.0A
NOTE: The system power supply requires C19 power cord
100-240V~, 16-8A, 50-60Hz
DC Output:
Max. 1200W
+12V/ 100A
+5V/ 30A
+3.3V/ 30A
-12V/ 0.8A
+5Vsb/ 4.0A
NOTE: The system power supply requires C19 power cord
System Management
N/A
OS Compatibility
Windows 10 (x64)
Based on Microsoft support policy, GIGABYTE recommends users to upgrade Skylake-based systems to Windows 10 before July 17th, 2018 to continue receiving support
Red Hat Enterprise Linux 6.8 (x64)
Red Hat Enterprise Linux 7.3 (x64)
SUSE Linux Enterprise Server 11.4 (x64)
SUSE Linux Enterprise Server 12.2 (x64)
Ubuntu 16.04 LTS (x64)
Ubuntu 16.10 LTS (x64)
Based on Microsoft support policy, GIGABYTE recommends users to upgrade Skylake-based systems to Windows 10 before July 17th, 2018 to continue receiving support
Red Hat Enterprise Linux 6.8 (x64)
Red Hat Enterprise Linux 7.3 (x64)
SUSE Linux Enterprise Server 11.4 (x64)
SUSE Linux Enterprise Server 12.2 (x64)
Ubuntu 16.04 LTS (x64)
Ubuntu 16.10 LTS (x64)
System Fans
2 x 80x80x25mm (4,500rpm)
1 x 92x92x25mm (4,500rpm)
1 x 120x120x38mm (4,200rpm)
1 x 92x92x25mm (4,500rpm)
1 x 120x120x38mm (4,200rpm)
Operating Properties
Operating temperature: 10°C to 35°C
Operating humidity: 8-80% (non-condensing)
Non-operating temperature: -40°C to 60°C
Non-operating humidity: 20%-95% (non-condensing)
Operating humidity: 8-80% (non-condensing)
Non-operating temperature: -40°C to 60°C
Non-operating humidity: 20%-95% (non-condensing)
Weight
Net Weight: 21.5 kg
Gross Weight: 30 kg
Gross Weight: 30 kg
Packaging Dimensions
918 x 630 x 373 mm
Packaging Content
1 x W281-G40
1 x Quick Installation guide
1 x Quick Installation guide
Part Numbers
- Barebone package: 6NW281G40MR-00
- Motherboard: 9MW51HP0NR-00
- I/O shield: 12AIO-MW51H0-00R
- Power supply: 25EP0-212006-F3S
- Fan-sink: 25ST0-7C9220-T1R (optional)
- C19 power cord 125V/13A (US): 25CP1-018000-Q0R (optional)
- C19 power cord 125V/13A (EU): 25CP3-01830H-Q0R (optional)
- C19 power cord 250V/15A (US): 25CP1-018300-Q0R (optional)
- I/O shield: 12AIO-MW51H0-00R
- Power supply: 25EP0-212006-F3S
- Fan-sink: 25ST0-7C9220-T1R (optional)
- C19 power cord 125V/13A (US): 25CP1-018000-Q0R (optional)
- C19 power cord 125V/13A (EU): 25CP3-01830H-Q0R (optional)
- C19 power cord 250V/15A (US): 25CP1-018300-Q0R (optional)
