MU72-SU0

Rev. 1.x/2.x

Motherboard - 3rd Gen Intel^® Xeon^® Scalable & Intel^® Xeon^® W-3300 - ATX UP

Single 3rd Gen Intel^® Xeon^® Scalable Processors
Single Intel^® Xeon^® W-3300 Processors
8-Channel RDIMM/LRDIMM DDR4, 8 x DIMMs
Supports Intel^® Optane™ Persistent Memory 200 series
Intel^® C621A Chipset
2 x 1Gb/s LAN ports via Intel^® I210-AT
3 x SlimSAS connectors for 12 x SATA 6Gb/s
1 x M.2 slot with PCIe Gen3 x4 interface
7 x PCIe Gen4 x16 and x8 expansion slots

Get a Quote

加入比較表

Get a Quote

* 以上產品之規格、圖片及其他資訊僅供參考，如與實際產品有任何不相符之處，應以實際產品為準。技嘉科技保留在任何時間做出修改之權利。對任何因使用上述資料而引致之損失，技嘉科技概不承擔任何責任。
* 本產品所標示之各項效能表現為各晶片廠商或各制定介面官方組織所提出的最大理論值，實際效能可能因規格及設備而有所不同。
* 本文中所使用之各項商標及企業識別圖示，均為其合法所有人之財產。
* 基於PC基本架構，有部分記憶體空間須留作系統用途，故所偵測到之記憶體大小會比實際上較少。

SPECIFICATIONS

Board Size

ATX
304.8W x 244D mm

Processor Supported

3rd Generation Intel^® Xeon^® Scalable Processors
Intel^® Xeon^® W-3300 Processors
Single processor, 10nm technology
TDP up to 270W

Socket

1 x LGA 4189
Socket P+

Chipset Description

Intel^® C621A

Memory Type

8 x DIMM slots
DDR4 memory supported only
8-channel memory architecture
RDIMM up to 128GB supported
LRDIMM up to 128GB supported
3DS RDIMM/LRDIMM up to 256GB supported
Memory speed: 3200/2933/2666 MT/s

Integrated Network

2 x 1Gb/s LAN ports (Intel^® I210-AT)
Support NCSI function

1 x 10/100/1000 Mbps Management LAN

Integrated Video Controller

Integrated in Aspeed^® AST2600
2D Video Graphic Adapter with PCIe bus interface
1920x1200@60Hz 32bpp

Integrated Audio Controller

N/A

Storage Interface

PCH:
- 3 x SlimSAS connectors for 12 x SATA 6Gb/s

Support RAID Function

Intel^® SATA RAID 0/1/10/5

Expansion Slot

Slot_7: PCIe x16 (Gen4 x16) slot
Slot_6: PCIe x16 (Gen4 x16 or x8) slot, shared with Slot_5
Slot_5: PCIe x16 (Gen4 x8) slot
Slot_4: PCIe x16 (Gen4 x16 or x8) slot, shared with Slot_3
Slot_3: PCIe x16 (Gen4 x8) slot
Slot_2: PCIe x16 (Gen4 x16 or x8) slot, shared with Slot_1
Slot_1: PCIe x16 (Gen4 x8) slot

1 x M.2 slot:
- M-key
- PCIe Gen3 x4, from PCH
- Supports 2280 cards

On-Board Connector

1 x 24-pin ATX main power connector
1 x 8-pin ATX 12V power connector
1 x 6-pin ATX 12V power connector for PCIe slots
1 x CPU fan header
6 x System fan headers
1 x USB 3.0 header
1 x M.2 slot
3 x SlimSAS connectors
1 x VROC connector
1 x Front panel header
1 x Backplane board header
1 x PMBus header
1 x IPMB header
1 x TPM header

Rear I/O Connectors

4 x USB 3.0
1 x VGA
1 x COM
2 x RJ45
1 x MLAN
1 x ID button with LED

TPM

1 x TPM header with SPI interface
Optional TPM2.0 kit: CTM010

OS Driver Supported

Windows Server 2016
Windows Server 2019 (x64)
Windows Server 2022 (x64)

Red Hat Enterprise Linux 7.9 or later
Red Hat Enterprise Linux 8.2 or later
Red Hat Enterprise Linux 9.0 or later

SUSE Linux Enterprise Server 12 SP5 or later
SUSE Linux Enterprise Server 15 SP2 or later

Ubuntu 20.04 LTS or later
Ubuntu 22.04 LTS or later

VMware ESXi 6.7 Update3 P03 or later
VMware ESXi 7.0 Update2 or later
VMware ESXi 8.0 or later

Citrix Hypervisor 8.2.0 or later

Server Management

Aspeed^® AST2600 management controller
GIGABYTE Management Console (AMI MegaRAC SP-X) web interface

Dashboard
HTML5 KVM
Sensor Monitor (Voltage, RPM, Temperature, CPU Status …etc.)
Sensor Reading History Data
FRU Information
SEL Log in Linear Storage / Circular Storage Policy
Hardware Inventory
Fan Profile
System Firewall
Power Consumption
Power Control
Advanced power capping
LDAP / AD / RADIUS Support
Backup & Restore Configuration
Remote BIOS/BMC/CPLD Update
Event Log Filter
User Management
Media Redirection Settings
PAM Order Settings
SSL Settings
SMTP Settings

PSU Connector

1 x 24-pin ATX main power connector
1 x 8-pin ATX 12V power connector
1 x 6-pin ATX 12V power connector

Operating Properties

Operating temperature: 10°C to 40°C
Operating humidity: 8-80% (non-condensing)
Non-operating temperature: -40°C to 60°C
Non-operating humidity: 20%-95% (non-condensing)

Packaging Bundle

1 x MU72-SU0
1 x I/O shield
1 x Quick start guide
1 x SlimSAS to 4 x SATA 6Gb/s cable (600mm)

Single Box dimensions: 360 x 330 x 80 mm
Carton dimensions: 674 x 424 x 385 mm
Quantity: 10 x single boxes in one carton

Bulk Packaging Content

10 x MU72-SU0
10 x I/O shields

Carton dimensions: 600 x 473 x 495 mm

Ordering Information

Retail: 9MU72SU0MR-00-2*/1*
Bulk: 9MU72SU0NR-00-2*/1*

Part Numbers:

- I/O shield: 12AIO-MU72SU-00R
- SlimSAS to 4 x SATA cable (600mm): 25CFM-600700-A4R

Optional parts:

- Fansink: 25ST4-353203-M1R
