G242-P31
HPC/AI Arm Server - Ampere® Altra® Max - 2U UP 4 x PCIe Gen4 GPUs
- Hardware-level root of trust support
- Supports up to 4 x Dual slot Gen4 GPUs
- Ampere® Altra® Max or Altra® Processors
- Single processor, 7nm technology
- 8-Channel RDIMM/LRDIMM DDR4, 16 x DIMMs
- 2 x 1Gb/s LAN ports (Intel® I350-AM2)
- 1 x Dedicated management port
- 4 x 3.5"/2.5" SATA/SAS hot-swappable bays
- 2 x M.2 slots with PCIe Gen4 x4 interface
- 4 x FHFL PCIe Gen4 x16 slots on the front side for GPUs
- 3 x LP PCIe Gen4 x8 slots on the rear side
- Dual 1600W 80 PLUS Platinum power supply
* 以上產品之規格、圖片及其他資訊僅供參考,如與實際產品有任何不相符之處,應以實際產品為準。技嘉科技保留在任何時間做出修改之權利。對任何因使用上述資料而引致之損失,技嘉科技概不承擔任何責任。
* 本產品所標示之各項效能表現為各晶片廠商或各制定介面官方組織所提出的最大理論值,實際效能可能因規格及設備而有所不同。
* 本文中所使用之各項商標及企業識別圖示,均為其合法所有人之財產。
* 基於PC基本架構,有部分記憶體空間須留作系統用途,故所偵測到之記憶體大小會比實際上較少。
* 本產品所標示之各項效能表現為各晶片廠商或各制定介面官方組織所提出的最大理論值,實際效能可能因規格及設備而有所不同。
* 本文中所使用之各項商標及企業識別圖示,均為其合法所有人之財產。
* 基於PC基本架構,有部分記憶體空間須留作系統用途,故所偵測到之記憶體大小會比實際上較少。
SPECIFICATIONS
Dimensions (WxHxD, mm)
2U
438 x 87.5 x 820
438 x 87.5 x 820
Motherboard
MP32-AR2
CPU
Ampere® Altra® Max or Altra® Processors
Single processor, 7nm technology
Up to 128 cores per processor, TDP up to 250W
Single processor, 7nm technology
Up to 128 cores per processor, TDP up to 250W
Socket
1 x LGA 4926
Chipset
System on Chip
Memory
16 x DIMM slots
DDR4 memory supported only
8-Channel memory architecture
RDIMM modules up to 256GB supported
LRDIMM modules up to 256GB supported
Up to 4TB of memory capacity supported
Memory speed: Up to 3200 MHz
Note: Only supports configurations with 1, 2, 4, 6, 8, 12, or 16 DIMMs.
DDR4 memory supported only
8-Channel memory architecture
RDIMM modules up to 256GB supported
LRDIMM modules up to 256GB supported
Up to 4TB of memory capacity supported
Memory speed: Up to 3200 MHz
Note: Only supports configurations with 1, 2, 4, 6, 8, 12, or 16 DIMMs.
LAN
Rear side:
2 x 1GbE LAN ports (1 x Intel® I350-AM2)
1 x 10/100/1000 Mbps Management LAN
2 x 1GbE LAN ports (1 x Intel® I350-AM2)
1 x 10/100/1000 Mbps Management LAN
Video
Integrated in Aspeed® AST2500
2D Video Graphic Adapter with PCIe bus interface
1920x1200@60Hz 32bpp
2D Video Graphic Adapter with PCIe bus interface
1920x1200@60Hz 32bpp
Storage
Front side:
4 x 3.5"/2.5" SATA/SAS hot-swappable bays, from CRA3338 SAS RAID Card
4 x 3.5"/2.5" SATA/SAS hot-swappable bays, from CRA3338 SAS RAID Card
SAS
Supported
RAID
RAID 0/1/1E/10
Expansion Slots
Riser Card CRSG01B x 4:
- 4 x PCIe x16 (Gen4 x16) FHFL slots, for GPUs
*Compatible with NVIDIA H100 80GB PCIe GPUs at ambient 30°C
Total 3 x PCIe Gen4 low-profile slots on the rear side
Slot_7: Disabled
Slot_6: PCIe x16 (Gen4 x16) slot, occupied by CRSG02F
Slot_5: PCIe x16 (Gen4 x8) slot
Slot_4: PCIe x16 (Gen4 x16) slot, occupied by CRSG02F
Slot_3: PCIe x16 (Gen4 x8) slot
Slot_2: PCIe x8 (Gen4 x8) slot
Slot_1: PCIe x16 (Gen4 x8) slot, occupied by CRA3338 SAS Card
2 x M.2 slots:
- M-key
- PCIe Gen4 x4
- Supports 2242/2260/2280/22110 cards
*Please refer to optional parts for H100 power cables.
3 x 360mm + 1 x 490mm configuration is recommended.
- 4 x PCIe x16 (Gen4 x16) FHFL slots, for GPUs
*Compatible with NVIDIA H100 80GB PCIe GPUs at ambient 30°C
Total 3 x PCIe Gen4 low-profile slots on the rear side
Slot_7: Disabled
Slot_6: PCIe x16 (Gen4 x16) slot, occupied by CRSG02F
Slot_5: PCIe x16 (Gen4 x8) slot
Slot_4: PCIe x16 (Gen4 x16) slot, occupied by CRSG02F
Slot_3: PCIe x16 (Gen4 x8) slot
Slot_2: PCIe x8 (Gen4 x8) slot
Slot_1: PCIe x16 (Gen4 x8) slot, occupied by CRA3338 SAS Card
2 x M.2 slots:
- M-key
- PCIe Gen4 x4
- Supports 2242/2260/2280/22110 cards
*Please refer to optional parts for H100 power cables.
3 x 360mm + 1 x 490mm configuration is recommended.
Internal I/O
1 x USB 3.0 header
1 x USB 2.0 header
1 x TPM header
1 x Front panel header
1 x Backplane board header
1 x PMBus connector
1 x IPMB connector
1 x Clear CMOS jumper
1 x Buzzer
1 x USB 2.0 header
1 x TPM header
1 x Front panel header
1 x Backplane board header
1 x PMBus connector
1 x IPMB connector
1 x Clear CMOS jumper
1 x Buzzer
Front I/O
1 x USB 3.0
1 x Power button with LED
1 x ID button with LED
1 x Reset button
1 x System status LED
1 x Storage activity LED
2 x LAN activity LEDs
1 x Power button with LED
1 x ID button with LED
1 x Reset button
1 x System status LED
1 x Storage activity LED
2 x LAN activity LEDs
Rear I/O
3 x USB 3.0
1 x VGA
1 x Debug port
2 x RJ45
1 x MLAN
1 x ID button with LED
1 x VGA
1 x Debug port
2 x RJ45
1 x MLAN
1 x ID button with LED
Backplane Board
Speed and bandwidth:
SATA 6Gb/s or SAS 12Gb/s
SATA 6Gb/s or SAS 12Gb/s
TPM
1 x TPM header with SPI interface
Optional TPM2.0 kit: CTM010
Optional TPM2.0 kit: CTM010
Power Supply
Dual 1600W 80 PLUS Platinum power supplies (-100)
AC Input:
- 100-120V~/ 12A, 50/60Hz
- 200-240V~/ 10A, 50/60Hz
DC Input: (Only for China)
- 240Vdc/ 10A
DC Output:
- Max 1000W/ 100-120V~
+ 12V/ 81.5A
+ 12Vsb/ 2.5A
- Max 1600W/ 200-240V~ or 240Vdc Input
+ 12V/ 133A
+ 12Vsb/ 2.5A
Dual 1600W 80 PLUS Titanium power supplies (-1T0)
AC Input:
- 100-240V~/ 12-9.5A, 50/60Hz
DC Input: (Only for China)
- 240Vdc/ 9.5A
DC Output:
- Max 1000W/ 100-127V~
+ 12.2V/ 82A
+ 12Vsb/ 3A
- Max 1600W/ 200-240V~ or 240Vdc Input
+ 12.2V/ 131.2A
+ 12Vsb/ 3A
AC Input:
- 100-120V~/ 12A, 50/60Hz
- 200-240V~/ 10A, 50/60Hz
DC Input: (Only for China)
- 240Vdc/ 10A
DC Output:
- Max 1000W/ 100-120V~
+ 12V/ 81.5A
+ 12Vsb/ 2.5A
- Max 1600W/ 200-240V~ or 240Vdc Input
+ 12V/ 133A
+ 12Vsb/ 2.5A
Dual 1600W 80 PLUS Titanium power supplies (-1T0)
AC Input:
- 100-240V~/ 12-9.5A, 50/60Hz
DC Input: (Only for China)
- 240Vdc/ 9.5A
DC Output:
- Max 1000W/ 100-127V~
+ 12.2V/ 82A
+ 12Vsb/ 3A
- Max 1600W/ 200-240V~ or 240Vdc Input
+ 12.2V/ 131.2A
+ 12Vsb/ 3A
System Management
Aspeed® AST2500 management controller
GIGABYTE Management Console (AMI MegaRAC SP-X) web interface
GIGABYTE Management Console (AMI MegaRAC SP-X) web interface
- Dashboard
- HTML5 KVM
- Sensor Monitor (Voltage, RPM, Temperature, CPU Status …etc.)
- Sensor Reading History Data
- FRU Information
- SEL Log in Linear Storage / Circular Storage Policy
- Hardware Inventory
- Fan Profile
- System Firewall
- Power Consumption
- Power Control
- LDAP / AD / RADIUS Support
- Backup & Restore Configuration
- Remote BIOS/BMC/CPLD Update
- Event Log Filter
- User Management
- Media Redirection Settings
- PAM Order Settings
- SSL Settings
- SMTP Settings
OS Compatibility
Red Hat Enterprise Linux 8.3 (aarch64) or later
Red Hat Enterprise Linux 8.5 (aarch64) or later
CentOS 8.3-2011 (aarch64) or later
CentOS-8.4.2105 (aarch64) or later
CentOS-8.5.2111 (aarch64) or later
SUSE Linux Enterprise Server 15 SP2 (aarch64) or later
SUSE Linux Enterprise Server 15 SP3 (aarch64) or later
Ubuntu 18.04.5 LTS (aarch64) or later
Ubuntu 20.04.1 LTS (aarch64) or later
Fedora Server 33-1.2 (aarch64) or later
Fedora Server 35-1.2 (aarch64) or later
OracleLinux R8 U2
OracleLinux R8 U5
Debian 10.9 (Buster)
Debian 11.1
Red Hat Enterprise Linux 8.5 (aarch64) or later
CentOS 8.3-2011 (aarch64) or later
CentOS-8.4.2105 (aarch64) or later
CentOS-8.5.2111 (aarch64) or later
SUSE Linux Enterprise Server 15 SP2 (aarch64) or later
SUSE Linux Enterprise Server 15 SP3 (aarch64) or later
Ubuntu 18.04.5 LTS (aarch64) or later
Ubuntu 20.04.1 LTS (aarch64) or later
Fedora Server 33-1.2 (aarch64) or later
Fedora Server 35-1.2 (aarch64) or later
OracleLinux R8 U2
OracleLinux R8 U5
Debian 10.9 (Buster)
Debian 11.1
System Fans
5 x 80x80x38mm (16,300rpm)
Operating Properties
Operating temperature: 10°C to 35°C
Operating humidity: 8%-80% (non-condensing)
Non-operating temperature: -40°C to 60°C
Non-operating humidity: 20%-95% (non-condensing)
Operating humidity: 8%-80% (non-condensing)
Non-operating temperature: -40°C to 60°C
Non-operating humidity: 20%-95% (non-condensing)
Packaging Dimensions
1077 x 679 x 300 mm
Packaging Content
1 x G242-P31
1 x CPU heatsink
1 x 2-Section Rail kit
1 x CPU heatsink
1 x 2-Section Rail kit
Part Numbers
- Barebone package: 6NG242P31MR-00-1*
- Motherboard: 9MP32AR2NR-00
- 2-Section Rail kit: 25HB2-3A0202-K0R
- CPU heatsink: 25ST1-2534Z0-C1R
- Front panel board - CFP1000: 9CFP1000NR-00
- Backplane board - CBPG041: 9CBPG041NR-00
- Fan module: 25ST2-88382A-D0R
- Fan duct for CPU: 25HA8-G24232-S5R
- PCIe Riser card - CRSG02F: 9CRSG02FNR-00
- GPU Riser card - CRSG01B: 9CRSG01BNR-00
- PCIe type SAS RAID Card - CRA3338: 9CRA3338NR-00
- Power supply (-100): 25EP0-216008-L0S
- Power supply (-1T0): 25EP0-21600E-L0S
Optional parts:
- GPU power cable (12VHPWR, 360mm): 25CRI-360102-Y4R
- GPU power cable (12VHPWR, 490mm): 25CRI-490102-Y4R
- Motherboard: 9MP32AR2NR-00
- 2-Section Rail kit: 25HB2-3A0202-K0R
- CPU heatsink: 25ST1-2534Z0-C1R
- Front panel board - CFP1000: 9CFP1000NR-00
- Backplane board - CBPG041: 9CBPG041NR-00
- Fan module: 25ST2-88382A-D0R
- Fan duct for CPU: 25HA8-G24232-S5R
- PCIe Riser card - CRSG02F: 9CRSG02FNR-00
- GPU Riser card - CRSG01B: 9CRSG01BNR-00
- PCIe type SAS RAID Card - CRA3338: 9CRA3338NR-00
- Power supply (-100): 25EP0-216008-L0S
- Power supply (-1T0): 25EP0-21600E-L0S
Optional parts:
- GPU power cable (12VHPWR, 360mm): 25CRI-360102-Y4R
- GPU power cable (12VHPWR, 490mm): 25CRI-490102-Y4R
* 產品規格會依各國家地區出貨而有所變動,應以各地實際出貨狀況為準。誠摯建議與當地經銷商或零售商確認最新產品販售規格。
* 以上產品之規格、圖片及其他資訊僅供參考,如與實際產品有任何不相符之處,應以實際產品為準。技嘉科技保留在任何時間做出修改之權利。對任何因使用上述資料而引致之損失,技嘉科技概不承擔任何責任。
* 本產品所標示之各項效能表現為各晶片廠商或各制定介面官方組織所提出的最大理論值,實際效能可能因規格及設備而有所不同。
* 本文中所使用之各項商標及企業識別圖示,均為其合法所有人之財產。
* 基於PC基本架構,有部分記憶體空間須留作系統用途,故所偵測到之記憶體大小會比實際上較少。
* 以上產品之規格、圖片及其他資訊僅供參考,如與實際產品有任何不相符之處,應以實際產品為準。技嘉科技保留在任何時間做出修改之權利。對任何因使用上述資料而引致之損失,技嘉科技概不承擔任何責任。
* 本產品所標示之各項效能表現為各晶片廠商或各制定介面官方組織所提出的最大理論值,實際效能可能因規格及設備而有所不同。
* 本文中所使用之各項商標及企業識別圖示,均為其合法所有人之財產。
* 基於PC基本架構,有部分記憶體空間須留作系統用途,故所偵測到之記憶體大小會比實際上較少。
SUPPORT
BIOS
工具程式
Firmware
QVL
BIOS
Warning:
更新BIOS有其潛在的風險,如果您使用目前版本的BIOS沒有問題,我們建議您不要任意更新BIOS。如需更新BIOS,請小心的執行,以避免不當的操作而造成系統毀損.
什麼是 BETA 版?
BETA版是正式推出前的試用版本。雖然該版本已經過測試,但可能還存在部份尚未發現、可能影響執行效能和功能的小問題。 請注意BETA版非正式的版本,並請密切注意正式版本的推出。
更新BIOS有其潛在的風險,如果您使用目前版本的BIOS沒有問題,我們建議您不要任意更新BIOS。如需更新BIOS,請小心的執行,以避免不當的操作而造成系統毀損.
什麼是 BETA 版?
BETA版是正式推出前的試用版本。雖然該版本已經過測試,但可能還存在部份尚未發現、可能影響執行效能和功能的小問題。 請注意BETA版非正式的版本,並請密切注意正式版本的推出。
- All
- All
- Windows Server 2022
- Windows Server 2019
- Windows Server 2016 R2 64bit
- Windows Server 2016 64bit
- Windows Server 2012 R2 64bit
- Windows Server 2012 64bit
- Windows 10 64bit
- Ubuntu
- Linux CentOS
- Linux
工具程式
說明
版本
檔案大小
日期
GSM CLI
Version : 2.1.77
147.89 MB
Sep 27, 2024
作業系統: Windows Server 2012 64bit,Windows Server 2012 R2 64bit,Linux CentOS,Windows 10 64bit,Ubuntu,Windows Server 2016 R2 64bit,Windows Server 2019,Windows Server 2022
GSM Server
Version : 2.12
926.33 MB
Jan 18, 2023
作業系統: Linux,Windows Server 2016 64bit,Windows Server 2019
GSM Agent
Ubuntu Server for ARM 22.04.1 LTS
(Including installation guide)
Ubuntu Server for ARM 22.04.1 LTS
(Including installation guide)
Version : 2.5
226.76 MB
Oct 14, 2022
作業系統: Ubuntu
Firmware
說明
版本
檔案大小
日期
BMC Firmware with embedded GIGABYTE Management Console
(AST2500 AMI for ARM platform)
(AST2500 AMI for ARM platform)
Version : 12.61.06
105.37 MB
Feb 29, 2024
英語
使用手冊
說明
版本
檔案大小
日期
說明
版本
檔案大小
日期
RESOURCES
Success Case
Articles
Success Case | June 06, 2023
CSR、ESG實踐案例:技嘉助攻成功大學 勇奪亞太HPC-AI電腦競賽冠軍
技嘉科技是高性能伺服器解決方案的知名品牌,並且長期投入企業社會責任(CSR),環境、社會和企業治理(ESG)等永續經營目標。2020年,技嘉提供四台G482-Z50伺服器產品給台灣成功大學的超級電腦團隊,協助同學在當年的亞太地區「高速運算暨人工智慧(HPC-AI)學生競賽」上榮獲冠軍。技嘉伺服器的平行運算能力,伺服器之間的高效率資料傳輸,及長時間運作也不會出錯的穩定特性,讓這些伺服器能扮演參賽同學的神隊友。技嘉促進新一代HPC與AI人才培育,同時藉此機會回饋社會,透過高科技產品增進人類福祉。
Success Case | June 02, 2023
技嘉伺服器加持 國研院國網中心與冉色斯引導台灣動畫走向國際
瀚草影視製作影集《2049》,2021年在網飛、台視、東森等平台播出;冉色斯動畫新作《2049+絕處逢聲》,是影集《2049》衍生系列,同步在myVideo首播。精妙絕倫的電腦動畫,使用國研院國網中心算圖農場的技嘉科技高效能運算伺服器渲染製作,透過伺服器搭載的NVIDIA®加速卡,動畫師能駕馭頂尖渲染技術,平行運算功能讓多名用戶能同時使用算圖服務,智慧管理功能則確保服務穩定性。千呼萬喚的台灣卡通巨作問世,《2049+絕處逢聲》受到國內外串流平台高度關注,台灣科技文創業的創意與巧思,期望能被全世界看見。
Success Case | May 30, 2023
西班牙IFISC用技嘉伺服器 為新冠肺炎、氣候變遷尋求解方
西班牙跨學科物理和複雜系統研究所,運用技嘉科技的先進伺服器產品,研究影響全人類的重大議題,包括:氣候變遷、環境污染、新冠肺炎。所面對的運算問題複雜且多元,技嘉伺服器使命必達,因為,研究所使用的三款伺服器,適合進行高效能運算、數值模擬、發展人工智慧、管理和分析大數據。
Success Case | May 25, 2023
技嘉ARM伺服器發威 協助台大「高精準車流模型」開發效率提升200%
台灣大學施吉昇教授率領的研究團隊,使用技嘉科技G242-P32伺服器及Arm HPC Developer Kit,開發能夠準確模擬路況的「高精準車流模型」。尖端科技加持的智慧交通解決方案,可用來測試即將上市的自駕車,也能用來觀察易肇事路段,找出引發事故的背後因素。以ARM處理器做為基石的這套開發平台,讓科學家工作效率提升200%,成功因素包括:「雲端原生」處理器和路測裝置使用相同的「指令語法」,減少裝置間溝通的延遲;Ampere® Altra®處理器內含八十顆核心,適合進行平行運算;CPU和GPU間可發揮異質運算的綜效,提升運算效率。ARM產品符合ISO 26262標準要求,這表示台大推出的電腦模型可以快速應用於車廠和政府機關,協助開創智慧型運輸的大未來。
Tech Guide | May 31, 2022
私有雲的需要與必要:如何評估企業的雲端部署
雲端運算盛行的當下,想必「私有雲」和「公有雲」對讀者來說不是第一次聽到。很有可能,在您的日常生活中,您已經受惠於這兩種雲端服務,但您真的了解兩者之間的差異嗎?如果有必要,您能幫您的工作場所建構「私有雲」嗎?技嘉科技是伺服器技術和雲端運算解決方案的知名品牌,發表本篇《科技指南》,目的是說明私有雲和公有雲的差別,並且介紹私有雲的種種優勢與限制;最後,本篇文章將推薦適合用來建造私有雲的技嘉科技伺服器產品,讓您有機會享用專屬於您的私有雲。
Tech Guide | March 16, 2022
淺談大數據分析應用,掌握先機的關鍵鑰匙
「大數據big data」或許不是陌生的名詞,但是,您知道它的原理和運用方法嗎?您是否聽說過「大數據的5V原則」?還有,您是否熟悉「做好大數據的三個基礎步驟」?更關鍵的是,如果您想使用大數據,您是否擁有適合的工具?技嘉科技是尖端科技解決方案的知名品牌,發表本篇《科技指南》,目的是介紹大數據的基本知識,淺談大數據所蘊藏的無限商機,並且推薦適用於大數據的技嘉科技伺服器產品,讓您能掌握大數據,解決生活和工作上所遇到的問題。
Tech Guide | February 11, 2022
ARM架構處理器的由來與優勢:從智慧型手機到超級電腦
ARM架構處理器是主流x86處理器架構以外的不同選擇,原本在行動裝置上穩居市占龍頭,如今,也逐漸在伺服器和資料中心產品中出現。技嘉科技是高性能伺服器產品的知名品牌,發表本篇《科技指南》文章,回顧ARM處理器的發展過程,介紹ARM產品的優勢與特性,並且推薦適用於不同領域的技嘉科技伺服器解決方案,協助您解決在工作上可能遇到的問題。
Video
Video | October 17, 2023
Explore AmpereOne servers by GIGABYTE with Ampere's Jeff Wittich
At Computex 2023 we had one of our important partners, Ampere Computing, stop by our booth to discover the future with the new ...
Video | October 17, 2023
Dive into GIGABYTE's ARM servers with the AmpereOne platform
Akira Hoshino, Head of Product Planning at Giga Computing, discusses how and what GIGABYTE has developed for Ampere ...
Video | November 16, 2021
Amped for the Cloud - G242-P31 ARM HPC Server
Ampere Altra processors, built with Arm architecture, compete with the x86 platform by having more cores to tackle compute-bound workloads. GIGABYTE ...
Video | November 16, 2021
Talk About Ampere® Altra® Maxwith Jeff Wittich from Ampere Computing
Join the Migration to the Cloud with Ampere and GIGABYTE. Adding Ampere's Altra Max processor, using Arm, to GIGABYTE's server portfolio offers another ...
Video | November 08, 2021
Alternative CPU Architecture is Challenging and Compelling for AI, Cloud, and Edge
In this video we dive into GIGABYTE's current lineup of Arm based servers using the Ampere Altra processor. Also, a great opportunity to learn about the server ...
Video | July 28, 2021
Heroes Ascension
Over the past year or so, due to global warming and climate changes, all parts of the world have witnessed extreme weather events that are more severe than ...
Video | June 01, 2021
GIGABYTE Server with Ampere® Altra® for Heterogeneous Computing
Every once in a while a game changer arrives. GIGABYTE servers utilize Ampere Altra processors to catapult accelerators to the next level. Best of ...
Video | May 28, 2021
Brand New CPU Platform: Ampere® Altra® Servers
Join the Migration to the Cloud: https://gbte.tech/4sjW Adding Ampere's Altra processor, using Arm, to GIGABYTE's server portfolio offers another platform choice ...
News
Media Review
Others
Back to G242-P31
