GA-Z97X-Gaming G1 (rev. 1.0)

GIGABYTE G1™ Gaming motherboards are equipped with the GIGABYTE exclusive AMP-UP Audio Technology, which provides the industry’s highest level of onboard audio features and technologies. With GIGABYTE AMP-UP Audio, gamers and audiophiles are able to experience crisp, ultra realistic sound effects while gaming, and the richest possible sound experience when listening to their favorite music and movies.

How does GIGABYTE AMP-UP Audio™ Technology work?

• Shortest route, no wasted trace.
• Less crosstalk & less EMI.
• AMP positioned close to audio jack for lowest noise.
• Better signal quality and better audio quality.

The shortest route is always the best for audio signals.
The GIGABYTE 9 Series G1™ Gaming motherboards feature the shortest audio communication paths between each critical component, from chipset to audio jack. This reduces the crosstalk along the way, and the very close proximity of the AMP to the audio jack directly results in lower noise disturbance.
With this high quality audio design, GIGABYTE G1™ Gaming motherboards are able to bring users better signal quality for the absolute best audio experience.

Customizable + Users can choose audio quality based on individual listening preferences. + Wide availability of additional OP-AMPs. Low Cost way to dramatically improve audio quality + Improve audio dynamics and overall sound-quality with little cost. + No need for expensive speakers or high-end audio equipment.               Well Known Hi-Fi class OP-AMP : TI Burr Brown OPA2134   Exclusive onboard 'Gain Boost' selector switches + Select either standard 2.5x or high-amplification 6x mode. + 6x mode is ideal for high impedance speakers and headphones

Combining world’s first Quad-Core Creative Sound Core3D Audio Processor Plus Advanced Creative SBX PROSTUDIO Audio Suite. + Harnessing the power of a Dedicated Audio Processor to offload workload from CPU + Total solution from Creative (Hardware +Software) + Richer overall audio experience

SBX Pro Studio™ suite of audio playback technologies deliver a new level of audio immersion. Realistic surround sound, the ability to clearly hear specific sounds in a gaming environment are just a few elements of SBX Pro Studio that enhances the overall experience, be it movies, games or music.

GIGABYTE G1™ Gaming motherboards use high end, Japanese branded Nichicon audio capacitors. These professional audio capacitors deliver the highest quality sound resolution and sound expansion to create the most realistic sound effects for professional gamers.

GIGABYTE G1™ Gaming motherboards pack top quality gold plated audio and HDMI connectors for improved connectivity and long lasting durability. Gold has superb signal conductivity and will not tarnish over extended periods of use. The Creative Sound Core3D™ processor is also shielded by a gold plated cover which eliminates electrostatic interference.

Featuring dual USB 2.0 ports, GIGABYTE USB DAC-UP provides clean, noise-free power delivery to your Digital-to-Analog Converter. DACs can be sensitive to fluctuations in power from the other USB ports, which is why GIGABYTE USB DAC-UP takes advantage of an isolated power source that minimizes potential fluctuations and ensures the best audio experience possible.

+ Separation on the PCB layer protects the board's sensitive analog audio components.
+ Separate analog and digital ground to protect against Electromagnetic Interference (EMI).
+ LED trace path lighting illuminates to show the separation of the PCB layers.

Locating the right and left audio channels on separate PCB layers, GIGABYTE 9 Series G1™ gaming motherboards are able to eliminate channel crosstalk and maintain the best audio quality. Left Audio Channel PCB layer   Right Audio Channel PCB layer

NO LAG, JUST FRAG!
GIGABYTE G1™ Gaming motherboards feature the Killer™ E2200 from Qualcomm Atheros, a high-performance, adaptive gigabit Ethernet controller that offers better online gaming and online media performance compared to standard solutions.

GIGABYTE APP Center gives you easy access to wealth of GIGABYTE apps that help you get the most from your GIGABYTE motherboard. Using a simple, unified user interface, GIGABYTE APP Center allows you to launch all GIGABYTE apps installed on your system.

		GIGABYTE EasyTune ™ App
		GIGABYTE's EasyTune™ is a simple and easy-to-use interface that allows users to fine-tune their system settings or adjust system and memory clocks and voltages in a Windows environment. With Smart Quick Boost, one click is all it takes to automatically overclock your system, giving an added performance boost when you need it the most.
		GIGABYTE  Cloud Station™  APP
		GIGABYTE Cloud Station™ is composed of several GIGABYTE's unique apps that allow your smart phones/tablet device to communicate, share resources, and control desktop PCs via wireless connection.

GIGABYTE Game Controller allows you to define your own hotkeys and change the mouse sensitivity, helping you make the most out of your keyboard and mouse in games.
Hot Key: Create macro commands and define your own hotkeys to quickly perform the function your want.
*Create the hotkeys by yourself on normal keyboard.
Speed: Using the Sniper key you can switch the mouse sensitivity when you are in sniper mode for better sniper accuracy.
With Speed Control Without Speed Control Enable mouse Sniper Mode to make your shot quick and stable. High DPI Mouse in sniper mode : Hard to focus
