TO25-Z11-AA01

Rev. 1.x Rev. 3.x

ORv3 Compute Node - AMD EPYC™ 9004 - 2OU 2-Node UP 12-Bay E1.S Gen4 NVMe

Single AMD EPYC™ 9004 Series Processors
12-Channel DDR5 RDIMM, 12 x DIMMs
Dual ROM Architecture
12 x E1.S Gen4 NVMe hot-swap bays
1 x M.2 slot with PCIe Gen4 x4 interface (optional)
1 x LP PCIe Gen5 x16 slot
1 x OCP NIC 3.0 PCIe Gen5 x16 slot
48V DC Bus Bar power solution

Get a Quote

* 사이트에서 제공되는 모든 자료는 참조용일 뿐입니다. 기가바이트는 사이트의 자료를 사전 통지없이 언제든지 수정할 권리를 지닙니다.
* 모든 상표와 로고는 해당 소유자의 자산입니다.
* PC의 표준 아키텍쳐에 의해, 메모리의 특정 부분이 시스템에 사용되어 실제 메모리 크기는 표준보다 적게 표시될 수 있습니다.

SPECIFICATIONS

Dimensions (WxHxD, mm)

2OU 2-Node
262.7 x 90 x 740

Open Rack Version

ORv3

Motherboard

MZ13-HD0

CPU

AMD EPYC™ 9005 Series Processors
AMD EPYC™ 9004 Series Processors

Single processor, cTDP up to 300W

^[Note]cTDP supported up to 400W under limited thermal conditions. Please contact our sales representatives for more details.

Memory

12 x DIMM slots
DDR5 memory supported
12-Channel memory architecture
RDIMM: Up to 4800 MT/s

LAN

Front:
1 x 10/100/1000 Mbps Management LAN

Video

Integrated in Aspeed^® AST2600
- 1 x VGA port

Storage

Front hot-swap:
12 x 9.5mm E1.S Gen4 NVMe

Optional internal M.2 (CMTP192):
1 x M.2 (2280/22110), PCIe Gen4 x4

SAS

N/A

RAID

N/A

PCIe Expansion Slots

Riser Card CRSH01Q:
- 1 x LP x16 (Gen5 x16)

Riser Card CRSH01R:
- 1 x LP x16 (Gen5 x16), occupied for NVMe

1 x OCP NIC 3.0 (Gen5 x16)
- Supports NCSI function

Front I/O

2 x USB 3.2 Gen1 ports (Type-A)
1 x VGA port
1 x MLAN port
1 x Power button with LED
1 x ID button with LED
1 x System status LED
1 x ID LED

Security Modules

1 x TPM header with SPI interface
- Optional TPM2.0 kit: CTM010

Power Supply

Supports up to 1600W

System Management

Aspeed^® AST2600 Baseboard Management Controller
GIGABYTE Management Console web interface

Dashboard
HTML5 KVM
Sensor Monitor (Voltage, RPM, Temperature, CPU Status …etc.)
Sensor Reading History Data
FRU Information
SEL Log in Linear Storage / Circular Storage Policy
Hardware Inventory
Fan Profile
System Firewall
Power Consumption
Power Control
Advanced power capping
LDAP / AD / RADIUS Support
Backup & Restore Configuration
Remote BIOS/BMC/CPLD Update
Event Log Filter
User Management
Media Redirection Settings
PAM Order Settings
SSL Settings
SMTP Settings

OS Compatibility

Please refer to OS compatibility table in support page

System Fans

N/A

Operating Properties

Operating temperature: 10°C to 35°C
Operating humidity: 8%-80% (non-condensing)
Non-operating temperature: -40°C to 60°C
Non-operating humidity: 20%-95% (non-condensing)

Packaging Dimensions

N/A

Packaging Content

1 x TO25-Z11-AA01
1 x CPU heatsink

Part Numbers

- Barebone package (EPYC 9005/9004): 6NTO25Z11DR000AB01*
- Barebone package (EPYC 9004): 6NTO25Z11DR000AA01*
- Motherboard: 9MZ13HD0UR-000*
- CPU heatsink: 25ST1-143100-A0R
- Front panel board - COFP111: 9COFP111NR-00*
- Re-driver card - CORC211: 9CORC211NR-00*
- Riser card - CRSH01Q: 9CRSH01QNR-00*
- Riser card - CRSH01R: 9CRSH01RNR-00*
- EDSFF base board - COBP740: 9COBP740NR-00*
- EDSFF riser card - CSPP010: 9CSPP010NR-00*

Optional parts:

- M.2 expansion card - CMTP192: 9CMTP192NR-00*

No. of Bus Bars

1 x 48V Bus Bar
