R282-Z9G

Rev. A00/B00

AMD EPYC™ 7003 DP Server System - 2U 20-Bay Gen4 NVMe with GRAID solution

# Networking

Hardware-level root of trust
Equipped with GRAID SupremeRAID NVMe/NVMe-oF RAID Card
AMD EPYC™ 7003 series processors
Dual processor, 7nm technology
8-Channel RDIMM/LRDIMM DDR4 per processor, 32 x DIMMs
2 x 1Gb/s LAN ports (Intel^® I350-AM2)
1 x Dedicated management port
20 x 2.5" Gen4 NVMe hot-swappable bays
2 x 2.5" SATA/SAS hot-swappable bays on rear side
1 x M.2 slot with PCIe Gen4 x4 interface
1 x FHHL PCIe Gen4 x16 slot
1600W (240V) 80 PLUS Platinum redundant power supply

Get a Quote

比較リストに追加

Get a Quote

* ここに記載されている全ての資料は参考用です。 GIGABYTEは、予告なしに変更する場合があります。
* パフォーマンスについては、インターフェイス仕様の理論上の最大値に基づいています。実際のパフォーマンスは、システム構成によって異なる場合があります。
* 記載されている会社名、商品名、およびロゴは各社の商標または登録商標です。
* メモリー容量は、システムリソースに予約され実際の搭載メモリーより少なくなる場合があります。

SPECIFICATIONS

Dimensions (WxHxD, mm)

2U
438 x 87 x 730

Motherboard

MZ92-FS1 Rev. 3.0

CPU

AMD EPYC™ 7003 series processors
Dual processor, 7nm technology
Up to 64-core, 128 threads per processor
TDP up to 225W, cTDP up to 240W

Fully support 280W

NOTE: If only 1 CPU is installed, some PCIe or memory functions might be unavailable

Compatible with AMD EPYC™ 7002 series processors

Socket

2 x LGA 4094
Socket SP3

Chipset

System on Chip

Memory

32 x DIMM slots
DDR4 memory supported only
8-Channel memory per processor architecture
RDIMM modules up to 128GB supported
LRDIMM modules up to 128GB supported
3DS RDIMM/LRDIMM modules up to 256GB supported
Memory speed: Up to 3200*/2933 MHz

Note: Follow BIOS setting and memory QVL list if running 3200 Mhz with 2DPC

LAN

Rear side:
2 x 1GbE LAN ports (1 x Intel^® I350-AM2)
1 x 10/100/1000 management LAN

Video

Integrated in Aspeed^® AST2500
2D Video Graphic Adapter with PCIe bus interface
1920x1200@60Hz 32bpp

Storage

Front side:
20 x 2.5" Gen4 NVMe hot-swappable bays
- (12 x from CPU_0, 8 x from CPU_1)

Rear side:
2 x 2.5" SATA/SAS hot-swappable bays, from CPU_0

SAS card is required for SAS devices support

SAS

Depends on SAS Add-on card

RAID

Equipped with GRAID SupremeRAID NVMe/NVMe-oF RAID Card
RAID Card models: SR1010, SR1000
Support RAID 0/1/10/5/6
Maximum 20 physical drives
Support NVMe/SAS/SATA SSD and SAS/SATA HDD

Expansion Slots

Riser Card CRS2033:
- 1 x PCIe x16 (Gen4 x16) FHHL slot, from CPU_0, occupied by CNV3134 - 4 x NVMe HBA
- 1 x PCIe x8 (Gen4 x8) FHHL slot, from CPU_0, occupied by CNV3132 - 2 x NVMe HBA
- 1 x PCIe x8 (Gen4 x8) FHHL slot, form CPU_0, occupied by CNV3132 - 2 x NVMe HBA

Riser Card CRS2015:
- 1 x PCIe x16 (Gen4 x16) HHHL slot, from CPU_1, occupied by CNV3134 - 4 x NVMe HBA

Riser Card CRS2026:
- 1 x PCIe x16 (Gen4 x16) FHHL slot, from CPU_1, occupied by GRAID SupremeRAID SR-1000 NVMe/NVMe-oF RAID Card
- 1 x PCIe x16 (Gen4 x16) FHHL slot, from CPU_1

1 x OCP 3.0 slot with PCIe Gen4 x16 bandwidth, from CPU_0
Supports NCSI function, occupied by CNV9134 - 4 x NVMe HBA

1 x OCP 2.0 mezzanine slot with PCIe Gen3 x8 bandwidth (Type1, P1, P2), from CPU_1
Supports NCSI function, occupied by CNVO132 - 2 x NVMe HBA

1 x M.2 slot:
- M-key
- PCIe Gen4 x4, from CPU_0
- Supports 2242/2260/2280/22110 cards
- CPU TDP is limited to 225W if using M.2 device

Internal I/O

1 x M.2 slot
1 x USB 3.0 header
1 x COM header
1 x TPM header
1 x Front panel header
1 x HDD backplane board header
1 x PMBus connector
1 x IPMB connector
1 x Clear CMOS jumper
1 x BIOS recovery jumper

Front I/O

2 x USB 3.0
1 x Power button with LED
1 x ID button with LED
1 x Reset button
1 x NMI button
1 x System status LED
1 x HDD activity LED
2 x LAN activity LEDs

Rear I/O

2 x USB 3.0
1 x VGA
2 x RJ45
1 x MLAN
1 x ID button with LED

Backplane Board

Speed and bandwidth:
Front side - CBP20O8: PCIe Gen4 x4
Rear side - CBP2022: SATA 6Gb/s or SAS 12Gb/s

TPM

1 x TPM header with SPI interface
Optional TPM2.0 kit: CTM010

Power Supply

2 x 1600W 80 PLUS Platinum redundant power supplies

AC Input:
- 100-120V~/ 12A, 50-60Hz
- 200-240V~/ 10.0A, 50-60Hz

DC Input:
- 240Vdc/ 10A

DC Output:
- Max 1000W/ 100-120V~
+ 12V/ 81.5A
+ 12Vsb/ 2.5A
- Max 1600W/ 200-240V~ or 240Vdc Input
+ 12V/ 133A
+ 12Vsb/ 2.5A

System Management

Aspeed^® AST2500 management controller
GIGABYTE Management Console (AMI MegaRAC SP-X) web interface

Dashboard
HTML5 KVM
Sensor Monitor (Voltage, RPM, Temperature, CPU Status …etc.)
Sensor Reading History Data
FRU Information
SEL Log in Linear Storage / Circular Storage Policy
Hardware Inventory
Fan Profile
System Firewall
Power Consumption
Power Control
LDAP / AD / RADIUS Support
Backup & Restore Configuration
Remote BIOS/BMC/CPLD Update
Event Log Filter
User Management
Media Redirection Settings
PAM Order Settings
SSL Settings
SMTP Settings

OS Compatibility

Windows Server 2019
Red Hat Enterprise Linux 8.3, 8.4, 8.5 (x64)
CentOSLinux 8.3, 8.4, 8.5 (x64)
SUSE Linux Enterprise Server 15 SP2, SP3 (x64)
openSUSE Leap Server 15.2, 15.3 (x64)
Ubuntu 20.04 LTS (x64)

System Fans

4 x 80x80x38mm (16,300rpm)

Operating Properties

Operating temperature: 10°C to 35°C
Operating humidity: 8%-80% (non-condensing)
Non-operating temperature: -40°C to 60°C
Non-operating humidity: 20%-95% (non-condensing)

Packaging Dimensions

982 x 588 x 268 mm

Packaging Content

1 x R282-Z9G
2 x CPU heatsinks
1 x Rail kit

Part Numbers

- Barebone with SR-1000 package: 6NR282Z9GMR-00-A*
- Barebone with SR-1010 package: 6NR282Z9GMR-00-B*
- Motherboard: 9MZ92FS1NR-00
- Rail kit: 25HB2-3A0202-K0R
- CPU heatsink: 25ST1-44320G-A0R
- Front panel board - CFP2001: 9CFP2001NR-00
- Backplane board - CBP20O8: 9CBP20O8NR-00
- Backplane board - CBP2022: 9CBP2022NR-00
- Fan module: 25ST2-883829-D0R
- Power supply: 25EP0-216008-L0S
