R162-ZA2

Rev. A00

Rack Server - AMD EPYC™ 7003/7002 - 1U UP 12-Bay Gen4 NVMe

# Networking

Hardware-level root of trust support
Single AMD EPYC™ 7003/7002 Series Processors
8-Channel DDR4 RDIMM/LRDIMM, 16 x DIMMs
2 x 1Gb/s LAN ports via Intel^® I350-AM2
12 x 2.5" Gen4 NVMe hot-swap bays
1 x M.2 slot with PCIe Gen4 x4 interface
2 x M.2 slots with PCIe Gen3 x4 interface
2 x FHHL PCIe Gen4 x16 and x8 slots
1 x Internal FHHL PCIe Gen4 x16 slot
1 x OCP NIC 3.0 PCIe Gen4 x16 slot
1 x OCP 2.0 Gen3 x8 mezzanine slot
1+1 800W 80 PLUS Platinum redundant power supplies

Get a Quote

比較リストに追加

Get a Quote

* ここに記載されている全ての資料は参考用です。 GIGABYTEは、予告なしに変更する場合があります。
* パフォーマンスについては、インターフェイス仕様の理論上の最大値に基づいています。実際のパフォーマンスは、システム構成によって異なる場合があります。
* 記載されている会社名、商品名、およびロゴは各社の商標または登録商標です。
* メモリー容量は、システムリソースに予約され実際の搭載メモリーより少なくなる場合があります。

SPECIFICATIONS

Dimensions (WxHxD, mm)

1U
438 x 43.5 x 780

Motherboard

MZA2-CE0 Rev. 3.0

CPU

AMD EPYC™ 7003 Series Processors
AMD EPYC™ 7002 Series Processors

Single processor, cTDP up to 240W

^[Note]Select 1300W power supply to support cTDP 280W CPUs.

Socket

1 x LGA 4094
Socket SP3

Chipset

System on Chip

Memory

16 x DIMM slots
DDR4 memory supported
8-Channel memory per processor
RDIMM/LRDIMM: Up to 3200/2933 MT/s^[1]

^[1]Follow BIOS setting and memory QVL if running 3200 MT/s with 2DPC.

LAN

Rear:
2 x 1Gb/s LAN (1 x Intel^® I350-AM2)
- Support NCSI function

1 x 10/100/1000 Mbps Management LAN

Video

Integrated in ASPEED^® AST2500
- 1 x VGA port

Storage

Front hot-swap:
12 x 2.5" Gen4 NVMe

Internal M.2:
1 x M.2 (2280/22110), PCIe Gen4 x4

Internal M.2 (CMTP063):
2 x M.2 (2280/22110), PCIe Gen3 x4

SAS

N/A

RAID

Require RAID add-in cards

PCIe Expansion Slots

Riser Card CRS1221 x 2:
- 1 x FHHL x16 (Gen4 x16)
- 1 x FHHL x16 (Gen4 x8 or x16), shared with OCP 2.0^[1]

Internal Riser Card CRS101H:
- 1 x FHHL x16 (Gen4 x16), occupied for NVMe

1 x OCP NIC 3.0 (Gen4 x16)
- Supports NCSI function

1 x OCP 2.0 mezzanine (Gen3 x8 or x0), shared with CRS1221
- Supports NCSI function

^[1]GIGABYTE offers an optional riser card to support full bandwidth PCIe Gen4 x16 and OCP 2.0 Gen3 x8.

Front I/O

1 x USB 3.0 port (Type-A)
1 x Power button with LED
1 x ID button with LED
1 x NMI button
1 x Reset button
2 x LAN activity LEDs
1 x Storage activity LED
1 x System status LED

Rear I/O

2 x USB 3.0 ports (Type-A)
1 x VGA port
2 x RJ45 ports
1 x MLAN port
1 x ID button with LED

Backplane Board

Speed and bandwidth:
PCIe Gen4 x4

Security Modules

1 x TPM header with SPI interface
- Optional TPM2.0 kit: CTM010

Power Supply

1+1 800W 80 PLUS Platinum redundant power supplies

AC Input:
- 100-240V~/ 10-4A, 50-60Hz

DC Input:
- 240Vdc/ 4.5A

DC Output:
- Max 800W
+12V/ 66A
+12Vsb/ 2.5A

System Management

ASPEED^® AST2500 Baseboard Management Controller
GIGABYTE Management Console web interface

Dashboard
HTML5 KVM
Sensor Monitor (Voltage, RPM, Temperature, CPU Status …etc.)
Sensor Reading History Data
FRU Information
SEL Log in Linear Storage / Circular Storage Policy
Hardware Inventory
Fan Profile
System Firewall
Power Consumption
Power Control
LDAP / AD / RADIUS Support
Backup & Restore Configuration
Remote BIOS/BMC/CPLD Update
Event Log Filter
User Management
Media Redirection Settings
PAM Order Settings
SSL Settings
SMTP Settings

OS Compatibility

Citrix Hypervisor 8.2.0 or later

Red Hat Enterprise Linux 8.3 or later
Red Hat Enterprise Linux 9.0 or later

SUSE Linux Enterprise Server 12 SP5 or later
SUSE Linux Enterprise Server 15 SP2 or later

Ubuntu 18.04.5 LTS or later
Ubuntu 20.04 LTS or later
Ubuntu 22.04 LTS or later

VMware ESXi 6.7 Update3 P03 or later
VMware ESXi 7.0 Update1 or later
VMware ESXi 8.0 or later

Windows Server 2016 (X2APIC/256T not supported)
Windows Server 2019
Windows Server 2022

System Fans

4 x 40x40x28mm (25,000rpm)
4 x 40x40x56mm (29,700rpm)

Operating Properties

Operating temperature: 10°C to 35°C
Operating humidity: 8%-80% (non-condensing)
Non-operating temperature: -40°C to 60°C
Non-operating humidity: 20%-95% (non-condensing)

Weight

Net Weight: 14.6 kg

Packaging Dimensions

1038 x 588 x 223 mm

Packaging Content

1 x R162-ZA2
1 x CPU heatsink
1 x 2-Section Rail kit

Part Numbers

- Barebone package: 6NR162ZA2MR-00-A*
- Motherboard: 9MZA2CE0NR-00*
- 2-Section Rail kit (CMA not supported): 25HB2-3A0203-K0R
- CPU heatsink: 25ST1-443107-A3R
- Front panel board - CFP1030: 9CFP1030NR-00*
- Backplane board - CBP10C0: 9CBP10C0NR-00*
- Riser card - CRS1221: 9CRS1221NR-00*
- Internal Riser card - CRS101H: 9CRS101HNR-00*
- 4-port NVMe card - CNVP142: 9CNVP142NR-00*
- Fan module: 25ST2-405622-A0R/25ST2-442828-D0R
- Power supply (800W): 25EP0-208004-L0S

Optional parts:

- 3-Section Rail kit (Supports CMA): 25HB2-A56121-K0R
- Cable Management Arm: 25HB1-R18300-K0R
- Power Supply (1300W): 25EP0-213004-F3S
- Power Supply (1300W): 25EP0-213006-F3S
- RMA packaging: 6NR162ZA2SR-RMA-A100
