The signature specifications for GIGABYTE Ultra Durable™ 3 motherboards are 2 oz Copper PCB, Japanese Solid Capacitors featuring 50,000hr. operation time, Ferrite core chokes with higher energy efficiency compared to the commonly used iron core chokes and Lower RDS(on) MOSFETs that feature lower resistance, which reduces power consumption and heat generation. GIGABYTE Ultra Durable™ 3 series motherboards provide the stability, reliability and longevity essential to meet the power needs of high-end processors and other components running today's most demanding applications and games.





Ferrite Core
Chock
Lower RDS(on)
MOSFET
Singal Layer
Ground
Layer(2oz)
Core
Ground
Layer(2oz)
Singal Layer
Core
Singal Layer
Ground
Layer(2oz)
core
Ground
Layer(2oz)
Singal Layer




Japanese Solid Capacitor

  2 OZ Copper
Inner Layer


  Copper PCB Traditional

  PCB layer cross-section image, magnified 200x
PCB (Printed Circuit Board)
2x copper PCB (2 oz copper PCB) = weight of copper layer
30.48 cm x 30.48 cm (1 square foot) PCB is 56.7 g (2 oz)
Cpooer Layer       Thiickness
2X copper
1X cpooer
