Model
GA-890FXA-UD7
GA-890FXA-UD5
GA-890GPA-UD3H
GA-890XA-UD3
    GA-890XA-UD3
CPU Support
AMD AM3
PhenomII/ AthlonII CPU
AMD AM3
PhenomII/ AthlonII CPU
AMD AM3
PhenomII/ AthlonII CPU
AMD AM3
PhenomII/ AthlonII CPU
CPU Socket
AMD Socket AM3
AMD Socket AM3
AMD Socket AM3
AMD Socket AM3
FSB
5200MT/s (HT3.0)
5200MT/s (HT3.0)
5200MT/s (HT3.0)
5200MT/s (HT3.0)
Chipset
AMD 890FX + SB850
AMD 890FX + SB850
AMD 890GX + SB850
AMD 790X + SB850
Onboard Graphics
-
-
ATI Radeon HD 4290 (DX10.1)
-
Graphics Interface
4*PCI-E 2.0 x16 slot (4*x8 or 1*x16+2*x8 or 2*x16)
3*PCI-E 2.0 x16 slot (1*x16+2*x8 or 2*x16)
2*PCI-E 2.0 x16 slot (x8, x8)
2*PCI-E 2.0 x16 slot (x8, x8)
Memory Type
Dual-channel DDR3 1866+/1333/1066
Dual-channel DDR3 1866+/1333/1066
Dual-channel DDR3 1866+/1333/1066
Dual-channel DDR3 1866+/1333/1066
Memory DIMM
4*DDR3 (Max 16GB)
4*DDR3 (Max 16GB)
4*DDR3 (Max 16GB)
4*DDR3 (Max 16GB)
Expansion Slots
2*PCI-E 2.0 x16 + 1*PCI
1*PCI-E 2.0 x16 + 2*PCI-E 2.0 x1 + 1*PCI
3*PCI-E 2.0 x1 + 2*PCI
3*PCI-E 2.0 x1 + 2*PCI
ATA connector
6*SATA 6Gb/s + 2*eSATA/USB Combo + 2*SATA 3Gb/s + 1*PATA
6*SATA 6Gb/s + 2*eSATA/USB Combo + 2*SATA 3Gb/s + 1*PATA
6*SATA 6Gb/s +
2*SATA 3Gb/s + 1*PATA
6*SATA 6Gb/s + 2*eSATA 3Gb/s + 2*SATA 3Gb/s + 1*PATA
SATA RAID
0, 1, 5, 10 (SB850)/ 0, 1, JBOD (JM363 & 362)
0, 1, 5, 10 (SB850)/ 0, 1, JBOD (JM363 & 362)
0, 1, 5, 10 (SB850)/ 0, 1, JBOD (JM363)
0, 1, 5, 10 (SB850)/ 0, 1, JBOD (JM363 & 362)
USB
2* USB3.0 + 14*USB2.0
2* USB3.0 + 14*USB2.0
2* USB3.0 + 12*USB2.0
2* USB3.0 + 12*USB2.0
Audio
8-channel HD
8-channel HD
8-channel HD
8-channel HD
1394
3*1394a
3*1394a
3*1394a
3*1394a
LAN
2*GbE
2*GbE
1*GbE
1*GbE
Features & Software
USB 3.0, SATA 6Gb/s, 3x USB power, 8+2 phase, Ultra Durable 3, Easy Energy Saver, Auto Unlock support, On/Off Charge support, 4way ATI CrossFireX, Smart DualLAN, Hybrid Silent-pipe2, Debug LED, Onboard Quick Switches, EasyTune6, ErP Ready
USB 3.0, SATA 6Gb/s, 3x USB power, 8+2 phase, Ultra Durable 3, Easy Energy Saver, Auto Unlock support, On/Off Charge support, 3way ATI CrossFireX, Smart DualLAN, Dolby Home Theater, Onboard Quick Switches, Precision OV, EasyTune6, ErP Ready
USB 3.0, SATA 6Gb/s, 3x USB power, 4+1 phase, Ultra Durable 3 Classic, Easy Energy Saver, Auto Unlock support, On/Off Charge support, ATI Hybrid CrossFireX/CrossFireX, DDR3 SidePort memory, HDMI/DVI, Dolby Home Theater, EasyTune6, ErP Ready
USB 3.0, SATA 6Gb/s, 3x USB power, 8+2 phase, Ultra Durable 3, Easy Energy Saver, Auto Unlock support, On/Off Charge support,
ATI CrossFireX,
Dolby Home Theater, Precision OV, EasyTune6, ErP Ready
Form Factor (mm)
XL-ATX (325x244)
ATX (305x244)
ATX (305x244)
ATX (305x244)



Model
GA-870A-UD3
     GA-870A-UD3
GA-880GA-UD3H
GA-880G-UD3H
GA-880GMA-UD2H
CPU Support
AMD AM3
PhenomII/ AthlonII CPU
AMD AM3
PhenomII/ AthlonII CPU
AMD AM3
PhenomII/ AthlonII CPU
AMD AM3
PhenomII/ AthlonII CPU
CPU Socket
AMD Socket AM3
AMD Socket AM3
AMD Socket AM3
AMD Socket AM3
FSB
5200MT/s (HT3.0)
5200MT/s (HT3.0)
5200MT/s (HT3.0)
5200MT/s (HT3.0)
Chipset
AMD 870 + SB850
AMD 880G + SB850
AMD 880G + SB710
AMD 880G + SB850
Onboard Graphics
-
ATI Radeon HD 4250(DX10.1)
ATI Radeon HD 4250(DX10.1)
ATI Radeon HD 4250(DX10.1)
Graphics Interface
1*PCI-E 2.0 x16 slot (x16)
1*PCI-E 2.0 x16 slot (x16)
1*PCI-E 2.0 x16 slot (x16)
1*PCI-E 2.0 x16 slot (x16)
Memory Type
Dual-channel DDR3 1866+/1333/1066
Dual-channel DDR3 1866+/1333/1066
Dual-channel DDR3 1866+/1333/1066
Dual-channel DDR3 1800+/1333/1066
Memory DIMM
4*DDR3 (Max 16GB)
4*DDR3 (Max 16GB)
4*DDR3 (Max 16GB)
4*DDR3 (Max 16GB)
Expansion Slots
1*PCI-E 2.0 x16 + 2*PCI-E 2.0 x1 + 3*PCI
1*PCI-E 2.0 x16 + 2*PCI-E 2.0 x1 + 3*PCI
1*PCI-E 2.0 x16 + 2*PCI-E 2.0 x1 + 3*PCI
1*PCI-E 2.0 x16 + 1*PCI-E 2.0 x1 + 1*PCI
ATA connector
6*SATA 6Gb/s + 2*eSATA 3Gb/s +2*SATA 3Gb/s + 1*PATA
6*SATA 6Gb/s +
2*SATA 3Gb/s + 1*PATA
6*SATA 3Gb/s + 1*PATA
5*SATA 6Gb/s + 1*eSATA 6Gb/s + 1*PATA
SATA RAID
0, 1, 5, 10 (SB850)/ 0, 1, JBOD (JM363 & 362)
0, 1, 5, 10 (SB850)/ 0, 1, JBOD (JM363)
0, 1, 10 (SB710)
0, 1, 5, 10 (SB850)
USB
2* USB3.0 + 12*USB2.0
2* USB3.0 + 12*USB2.0
12*USB2.0
2* USB3.0 + 10*USB2.0
Audio
8-channel HD
8-channel HD
8-channel HD
8-channel HD
1394
3*1394a
3*1394a
3*1394a
2*1394a
LAN
1*GbE
1*GbE
1*GbE
1*GbE
Features & Software
USB 3.0, SATA 6Gb/s, 3x USB power, 8+2 phase, Ultra Durable 3, Easy Energy Saver, Auto Unlock support,
On/Off Charge support,
Dolby Home Theater, Precision OV, EasyTune6, ErP Ready
USB 3.0, SATA 6Gb/s, 3x USB power, 4+1 phase, Ultra Durable 3 Classic, Easy Energy Saver, Auto Unlock support, On/Off Charge support, Turbo 3D support, ATI Hybrid CrossFireX, HDMI/DVI, Dolby Home Theater, EasyTune6, ErP Ready
3x USB power, 4+1 phase, Ultra Durable 3 Classic, Easy Energy Saver,
ACC support, Turbo 3D support, ATI Hybrid CrossFireX, HDMI/DVI, Dolby Home Theater, EasyTune6, ErP Ready
USB 3.0, SATA 6Gb/s, 3x USB power, 4+1 phase, Ultra Durable 3 Classic, Easy Energy Saver, Auto Unlock support, On/Off Charge support, Turbo 3D support, ATI Hybrid CrossFireX, HDMI/DVI, Dolby Home Theater, EasyTune6, ErP Ready
Form Factor (mm)
ATX (305x230)
ATX (305x244)
ATX (305x229)
mATX (244x244)



Model
GA-880GM-USB3
GA-880GM-UD2H
CPU Support
AMD AM3
PhenomII/ AthlonII CPU
AMD AM3
PhenomII/ AthlonII CPU
CPU Socket
AMD Socket AM3
AMD Socket AM3
FSB
5200MT/s (HT3.0)
5200MT/s (HT3.0)
Chipset
AMD 880G + SB710
AMD 880G + SB710
Onboard Graphics
ATI Radeon HD 4250(DX10.1)
ATI Radeon HD 4250(DX10.1)
Graphics Interface
1*PCI-E 2.0 x16 slot (x16)
1*PCI-E 2.0 x16 slot (x16)
Memory Type
Dual-channel DDR3 1800+/1333/1066
Dual-channel DDR3 1800+/1333/1066
Memory DIMM
4*DDR3 (Max 16GB)
4*DDR3 (Max 16GB)
Expansion Slots
1*PCI-E x1 + 2*PCI
1*PCI-E x1 + 2*PCI
ATA connector
5*SATA 3Gb/s + 1*eSATA 3Gb/s + 1*PATA
5*SATA 3Gb/s + 1*eSATA 3Gb/s + 1*PATA
SATA RAID
0, 1, 10 (SB710)
0, 1, 10 (SB710)
USB
2* USB3.0 + 10*USB2.0
12*USB2.0
Audio
8-channel HD
8-channel HD
1394
2*1394a
2*1394a
LAN
1*GbE
1*GbE
Features & Software
USB 3.0, 3x USB power,
4+1 phase, Ultra Durable 3 Classic, Easy Energy Saver, ACC support, Turbo 3D support, ATI Hybrid CrossFireX, HDMI/DVI, Dolby Home Theater, EasyTune6, ErP Ready
3x USB power, 4+1 phase, Ultra Durable 3 Classic, Easy Energy Saver, ACC support, Turbo 3D support, ATI Hybrid CrossFireX, HDMI/DVI, Dolby Home Theater, EasyTune6,
ErP Ready
Form Factor (mm)
mATX (244x244)
mATX (244x244)

U : 2 oz copper PCB design     D : All solid capacitor design
* Product features may vary by model.
* Motherboard models may vary based on local distribution.
* Please refer to GIGABYTE website for CPU support information.
For further product information, please visit our website: www.gigabyte.com
* The specifications and pictures are subject to change without notice.
* All trademarks and logos are the properties of their respective holders.
