GA-H87TN (rev. 1.0)

GIGABYTE Thin-Mini-ITX motherboards are the ideal platform for today’s All-in-One, small form factor and slim profile PCs. Offering a full featured PC experience in a minimal device footprint, GIGABYTE Thin Mini-ITX motherboards are 43% thinner than traditional Mini-ITX designs. Complying with the latest Thin Mini-ITX guidelines, GIGABYTE Thin Mini-ITX motherboards offer additional flexibility making them suited to broad range of innovative PC designs.

Selectable Panel Power Driver
GIGABYTE Thin Mini-ITX motherboards feature a selectable power driver allowing for both 3.3v and 5v configurations. This brings additional flexibility for LVDS panels that require both 3.3v and 5v drivers. Voltage settings are configured via an onboard jumper.

Selectable Back Light Power Module
GIGABYTE Thin Mini-ITX motherboards offer flexible backlight power delivery with both 12v and 19v options available via onboard jumpers. This enhances compatibility with the wide range of backlit displays available today.

Wide Range Voltage Input
Offering additional flexibility for system DC voltage input, GIGABYTE Thin Mini-ITX motherboards offer a broad voltage range of 12v to 19v, eliminating compatibility issues with many traditional IPC designs.

PCI Express x4 Expansion Slot
GIGABYTE Thin Mini-ITX motherboards are equipped with a x4 PCI Express expansion slot providing up to 25W of power and easy integration of TV tuner, video capture or RAID cards with a compatible riser card.

GIGABYTE motherboards possess a range of features that are designed to offer vastly improved and simplified control over unmanaged IT infrastructure, with specific focus on security, data backup and raising productivity levels overall.

SECURITY			PRODUCTIVITY
	SOFTWARE MONITOR Monitor critical software below the OS			PC HEALTH CENTER Run after hours— even if PC is off
	DATA BACKUP & RESTORE Run after hours—even if PC is off			ENERGY SAVER Automatically power on each morning
	USB BLOCKER Block unwanted USB device classes			Intel® WIRELESS DISPLAY Share and collaborate, wirelessly (with Intel Wi-Fi module only)*

*GIGABYTE motherboards can support Intel^® Wireless display only when combined with an appropriate Intel Wi-Fi module.

Stay current with automatic, no-wait updates to your email and social networks, even when your PC is asleep.

GIGABYTE motherboards feature an onboard mSATA slot allowing users to easily take advantage of advanced SSD-based technologies like Intel^® Smart Response and Intel^® Rapid Start. Mounting an affordable, low capacity mSATA SSD directly onto your motherboard can enhance your PC's performance with better overall desktop responsiveness, faster boot times and faster system resume from 'Suspend to Disk' and 'Standby' modes.

Faster media encoding performance
Saves your valuable time when create and edit video, synchronize it with other devices, and share it–at home and on the internet. Intel Quick Sync Video uses hardware on the processor, instead of software, to accelerate video encoding.
