W771-Z00

Rev. 100

GPU Workstation - AMD Ryzen™ Threadripper™ PRO 5000/3000 WX-Series - UP

# AI # AI Training # AI Inference # Visual Computing # HPC

Supports up to 4 x Dual slot Gen4 GPUs
Single AMD Ryzen™ Threadripper™ PRO 5000/3000 WX-Series Processors
8-Channel DDR4 UDIMM/RDIMM/LRDIMM, 8 x DIMMs
2 x 10Gb/s LAN ports via Intel^® X550-AT2
1 x 1Gb/s LAN port via Intel^® I210-AT
Up to 8 x 3.5"/2.5" SATA hot-swappable bays (4 x optional bays)
2 x M.2 slots with PCIe Gen4 x4 or SATA interface
1 x M.2 slot for Wi-Fi add-in cards
7 x PCIe Gen4 x16 and x8 slots
1+1 2000W 80 PLUS Platinum redundant power supplies

Get a Quote

So sánh sản

Get a Quote

* The entire materials provided herein are for reference only. GIGABYTE reserves the right to modify or revise the content at anytime without prior notice.
* Advertised performance is based on maximum theoretical interface values from respective Chipset vendors or organization who defined the interface specification. Actual performance may vary by system configuration.
* All trademarks and logos are the properties of their respective holders.
* Due to standard PC architecture, a certain amount of memory is reserved for system usage and therefore the actual memory size is less than the stated amount.

SPECIFICATIONS

Dimensions (WxHxD, mm)

Pedestal
175 x 438 x 680 mm

Motherboard

MC62-G40

CPU

AMD Ryzen™ Threadripper™ PRO 5000 WX-Series Processors
AMD Ryzen™ Threadripper™ PRO 3000 WX-Series Processors
Up to 64 cores, 128 threads
TDP up to 280W

Socket

1 x sWRX8

Chipset

AMD WRX80

Memory

8 x DIMM slots
DDR4 memory supported only
8-channel memory architecture
ECC UDIMM supported
Total capacity up to 2TB (256GB LRDIMM)
Memory speed: 3200/2933/2666/2400/2133 MT/s

LAN

2 x 10Gb/s LAN ports (Intel^® X550-AT2)
1 x 1Gb/s LAN port (Intel^® I210-AT)
Supports NCSI function on Intel^® I210-AT

1 x 10/100/1000 Mbps Management LAN

Video

Integrated in Aspeed^® AST2600
2D Video Graphic Adapter with PCIe bus interface
1920x1200@60Hz 32bpp

Audio

Realtek^® ALC4080 HD Audio Codec
Supports 7.1 channel configuration
3 x Audio Jacks (Audio in/Audio out/Mic)

Storage

4 x 3.5"/2.5" SATA hot-swappable bays, from FCH
Optional 4 x 3.5"/2.5" SATA hot-swappable bays, from FCH

SAS card is required for SAS devices support

RAID

RAID 0/1/5/10

Peripheral Drives

2 x 5.25" space reserved for ODD devices

Expansion Slots

Slot_7: PCIe x16 (Gen4 x16) slot
Slot_6: PCIe x16 (Gen4 x16) slot
Slot_5: PCIe x16 (Gen4 x16) slot
Slot_4: PCIe x16 (Gen4 x16) slot
Slot_3: PCIe x16 (Gen4 x16) slot
Slot_2: PCIe x16 (Gen4 x8) slot
Slot_1: PCIe x16 (Gen4 x16) slot

2 x M.2 slots for storage:
- M-key
- PCIe Gen4 x4 or SATA, from CPU
- Support 2242/2280 cards

1 x M.2 slot for Wi-Fi:
- E-key
- Supports 2230 cards

Internal I/O

1 x TPM header

Front I/O

2 x USB 3.2 Gen1 (FCH)
1 x Power button
1 x Reset button
1 x Power LED
2 x LAN activity LEDs
1 x Storage activity LED
1 x System status LED
1 x ID LED

Rear I/O

1 x USB 3.2 Gen2x1 (Type-C)(FCH)
4 x USB 3.2 Gen2x1 (Type-A)(CPU)
1 x USB 3.2 Gen2x1 (Type-A)(FCH)
1 x VGA
2 x RJ45 (10Gb/s)
1 x RJ45 (1Gb/s)
1 x MLAN
3 x Audio jacks
1 x ID button with LED

TPM

1 x TPM header with SPI interface
- Optional TPM2.0 kit: CTM010

Power Supply

1+1 2000W 80 PLUS Platinum redundant power supplies

AC Input:
- 100-127V~/ 13A, 50-60Hz
- 200-240V~/ 12A, 50-60Hz

DC Output:
- Max 996W/ 90-140V~
+12.2V/ 83A
+12Vsb/ 2.1A
- Max 1560W/ 180-220V~
+12.2V/ 130A
+12Vsb/ 3A
- Max 2000W/ 240-300V~
+12.2V/ 166.7A
+12Vsb/ 3A

System Management

ASPEED^® AST2600 Management Controller
GIGABYTE Management Console (AMI MegaRAC SP-X) web interface

Dashboard
HTML5 KVM
Sensor Monitor (Voltage, RPM, Temperature, CPU Status …etc.)
Sensor Reading History Data
FRU Information
SEL Log in Linear Storage / Circular Storage Policy
Hardware Inventory
Fan Profile
System Firewall
Power Consumption
Power Control
Advanced power capping
LDAP / AD / RADIUS Support
Backup & Restore Configuration
Remote BIOS/BMC/CPLD Update
Event Log Filter
User Management
Media Redirection Settings
PAM Order Settings
SSL Settings
SMTP Settings

OS Compatibility

Red Hat Enterprise Linux 8.2 (x64)
Red Hat Enterprise Linux 8.3 (x64)

Ubuntu 20.04 LTS (x64)

Windows 10 (x64)
Windows 11 (x64)

System Fans

4 x 80x80x38mm (11,000rpm)
2 x 80x80x38mm (8,200rpm)

Optional GPU fan modules are recommended to achieve maximum performance with multiple 300W GPUs.

Operating Properties

Operating temperature: 10°C to 35°C
Operating humidity: 8-80% (non-condensing)
Non-operating temperature: -40°C to 60°C
Non-operating humidity: 20%-95% (non-condensing)

Weight

Net Weight: 22 kg
Gross Weight: 24 kg

Packaging Dimensions

1078 x 588 x 388 mm

Packaging Content

1 x W771-Z00
1 x CPU fansink
1 x Quick installation guide

Part Numbers

- Barebone package: 6NW771Z00MR-00-1*
- Motherboard: 9MC62G40MR-00
- CPU fansink (A)+(B):
  (A) 25ST2-88382C-D0R (fan)
  (B) 25ST1-243103-A0R (heatsink)
- FCH fansink: 12SF2-01A095-00R
- I/O shield: 12AIO-MC62G4-00R
- Power supply: 25EP0-22000G-A0S

Optional parts:

- GPU fan module: 25HB1-MC6200-C0R
- Storage cage: 25HB1-MC6201-C0R
- Rail kit (A)+(B):
  (A) 25HB2-A66123-C0R (Slide rail)(Qty: 1)
  (B) 25HB4-MC6200-C0R (Handle+Rack ear+Rail screws)(Qty: 1)
