H263-V60- AAW1
High Density Arm Server - NVIDIA Grace™ CPU Superchip - 2U 4-Node 16-Bay Gen5 NVMe
- High-performance CPU for HPC and cloud computing
- 2U 4-node rear access server system
- NVIDIA Grace™ CPU Superchip
- 900GB/s NVIDIA® NVLink®-C2C Interconnect
- Up to 960GB LPDDR5X ECC memory per module
- Compatible with NVIDIA BlueField®-3 DPUs
- 16 x 2.5" Gen5 NVMe hot-swappable bays
- 8 x M.2 slots with PCIe Gen5 x4 interface
- 8 x LP PCIe Gen5 x16 slots
- 4 x OCP 3.0 Gen5 x16 slots
- 2+1 3000W 80 PLUS Titanium redundant power supplies
* The entire materials provided herein are for reference only. GIGABYTE reserves the right to modify or revise the content at anytime without prior notice.
* Advertised performance is based on maximum theoretical interface values from respective Chipset vendors or organization who defined the interface specification. Actual performance may vary by system configuration.
* All trademarks and logos are the properties of their respective holders.
* Due to standard PC architecture, a certain amount of memory is reserved for system usage and therefore the actual memory size is less than the stated amount.
* Advertised performance is based on maximum theoretical interface values from respective Chipset vendors or organization who defined the interface specification. Actual performance may vary by system configuration.
* All trademarks and logos are the properties of their respective holders.
* Due to standard PC architecture, a certain amount of memory is reserved for system usage and therefore the actual memory size is less than the stated amount.
SPECIFICATIONS
Dimensions (WxHxD, mm)
2U 4-Node - Rear access
440 x 87.5 x 850
440 x 87.5 x 850
Motherboard
MV63-HD0
Superchip
NVIDIA Grace™ CPU Superchip:
- 2 x NVIDIA Grace™ CPUs
- Connected with NVIDIA® NVLink®-C2C
- TDP up to 500W (CPU + memory)
- 2 x NVIDIA Grace™ CPUs
- Connected with NVIDIA® NVLink®-C2C
- TDP up to 500W (CPU + memory)
Memory
Per node:
Up to 960GB of LPDDR5X memory with ECC
Memory bandwidth up to 1TB/s
Up to 960GB of LPDDR5X memory with ECC
Memory bandwidth up to 1TB/s
LAN
Per node:
1 x 10/100/1000 Mbps Management LAN
Total:
4 x 10/100/1000 Mbps Management LAN
1 x CMC port
1 x 10/100/1000 Mbps Management LAN
Total:
4 x 10/100/1000 Mbps Management LAN
1 x CMC port
Video
Integrated in Aspeed® AST2600
2D Video Graphic Adapter with PCIe bus interface
1920x1200@60Hz 32bpp
Management chip on CMC board:
Integrated in Aspeed® AST2520A2-GP
2D Video Graphic Adapter with PCIe bus interface
1920x1200@60Hz 32bpp
Management chip on CMC board:
Integrated in Aspeed® AST2520A2-GP
Storage
Per node:
4 x 2.5" Gen5 NVMe hot-swappable bays
- (2 x from CPU_0, 2 x from CPU_1)
Total:
16 x 2.5" Gen5 NVMe hot-swappable bays
- (8 x from CPU_0, 8 x from CPU_1)
4 x 2.5" Gen5 NVMe hot-swappable bays
- (2 x from CPU_0, 2 x from CPU_1)
Total:
16 x 2.5" Gen5 NVMe hot-swappable bays
- (8 x from CPU_0, 8 x from CPU_1)
SAS
N/A
RAID
N/A
Expansion Slots
Per node:
PCIe Cable x 2:
- 1 x PCIe x16 (Gen5 x16) low-profile slot, from CPU_0
- 1 x PCIe x16 (Gen5 x16) low-profile slot, from CPU_1
1 x OCP 3.0 slot with PCIe Gen5 x16 bandwidth, from CPU_0
Supports NCSI function
2 x M.2 slots:
- M-key
- PCIe Gen5 x4, from CPU_1
- Support 2280/22110 cards
Total:
PCIe Cable x 8:
- 4 x PCIe x16 (Gen5 x16) low-profile slots, from CPU_0
- 4 x PCIe x16 (Gen5 x16) low-profile slots, from CPU_1
4 x OCP 3.0 slots with PCIe Gen5 x16 bandwidth, from CPU_0
Support NCSI function
8 x M.2 slots:
- M-key
- PCIe Gen5 x4, from CPU_1
- Support 2280/22110 cards
PCIe Cable x 2:
- 1 x PCIe x16 (Gen5 x16) low-profile slot, from CPU_0
- 1 x PCIe x16 (Gen5 x16) low-profile slot, from CPU_1
1 x OCP 3.0 slot with PCIe Gen5 x16 bandwidth, from CPU_0
Supports NCSI function
2 x M.2 slots:
- M-key
- PCIe Gen5 x4, from CPU_1
- Support 2280/22110 cards
Total:
PCIe Cable x 8:
- 4 x PCIe x16 (Gen5 x16) low-profile slots, from CPU_0
- 4 x PCIe x16 (Gen5 x16) low-profile slots, from CPU_1
4 x OCP 3.0 slots with PCIe Gen5 x16 bandwidth, from CPU_0
Support NCSI function
8 x M.2 slots:
- M-key
- PCIe Gen5 x4, from CPU_1
- Support 2280/22110 cards
Internal I/O
Per node:
1 x TPM header
1 x TPM header
Front I/O
Per node:
1 x Power button with LED
1 x ID button with LED
1 x Reset button
1 x System status LED
Total:
4 x Power buttons with LED
4 x ID buttons with LED
4 x Reset buttons
4 x System status LEDs
*1 x CMC status LED
*1 x CMC reset button
*Only one CMC status LED and reset button per system.
1 x Power button with LED
1 x ID button with LED
1 x Reset button
1 x System status LED
Total:
4 x Power buttons with LED
4 x ID buttons with LED
4 x Reset buttons
4 x System status LEDs
*1 x CMC status LED
*1 x CMC reset button
*Only one CMC status LED and reset button per system.
Rear I/O
Per node:
2 x USB 3.2 Gen1
1 x VGA
1 x MLAN
1 x ID button with LED
Total:
8 x USB 3.2 Gen1
4 x VGA
4 x MLAN
4 x ID buttons with LED
*1 x CMC port
*Only one CMC port per system.
2 x USB 3.2 Gen1
1 x VGA
1 x MLAN
1 x ID button with LED
Total:
8 x USB 3.2 Gen1
4 x VGA
4 x MLAN
4 x ID buttons with LED
*1 x CMC port
*Only one CMC port per system.
Backplane Board
Speed and bandwidth:
PCIe Gen5 x4
PCIe Gen5 x4
TPM
1 x TPM header with SPI interface
- Optional TPM2.0 kit: CTM012
- Optional TPM2.0 kit: CTM012
Power Supply
2+1 3000W 80 PLUS Titanium redundant power supplies
AC Input:
- 100-127V~/ 16A, 50/60Hz
- 200-207V~/ 16A, 50/60Hz
- 208-240V~/ 16A, 50/60Hz
DC Input: (Only for China)
- 240Vdc/ 16A
DC Output:
- Max 1200W/ 100-127V~
+12.2V/ 98.36A
+12.2Vsb/ 3A
- Max 2600W/ 200-207V~
+12.2V/ 213A
+12.2Vsb/ 3A
- Max 3000W/ 208-240V~ or 240Vdc Input
+12.2V/ 245.9A
+12.2Vsb/ 3A
Note: The system power supply requires C19 power cord.
AC Input:
- 100-127V~/ 16A, 50/60Hz
- 200-207V~/ 16A, 50/60Hz
- 208-240V~/ 16A, 50/60Hz
DC Input: (Only for China)
- 240Vdc/ 16A
DC Output:
- Max 1200W/ 100-127V~
+12.2V/ 98.36A
+12.2Vsb/ 3A
- Max 2600W/ 200-207V~
+12.2V/ 213A
+12.2Vsb/ 3A
- Max 3000W/ 208-240V~ or 240Vdc Input
+12.2V/ 245.9A
+12.2Vsb/ 3A
Note: The system power supply requires C19 power cord.
System Management
Aspeed® AST2600 management controller
GIGABYTE Management Console (AMI MegaRAC SP-X) web interface
GIGABYTE Management Console (AMI MegaRAC SP-X) web interface
- Dashboard
- HTML5 KVM
- Sensor Monitor (Voltage, RPM, Temperature, CPU Status …etc.)
- Sensor Reading History Data
- FRU Information
- SEL Log in Linear Storage / Circular Storage Policy
- Hardware Inventory
- Fan Profile
- System Firewall
- Power Consumption
- Power Control
- Advanced power capping
- LDAP / AD / RADIUS Support
- Backup & Restore Configuration
- Remote BIOS/BMC/CPLD Update
- Event Log Filter
- User Management
- Media Redirection Settings
- PAM Order Settings
- SSL Settings
- SMTP Settings
OS Compatibility
Please refer to OS compatibility table in support page
System Fans
4 x 80x80x80mm (16,500rpm)
Operating Properties
Operating temperature: 10°C to 30°C
Operating humidity: 10-80% (non-condensing)
Non-operating temperature: -40°C to 60°C
Non-operating humidity: 20%-90% (non-condensing)
Operating humidity: 10-80% (non-condensing)
Non-operating temperature: -40°C to 60°C
Non-operating humidity: 20%-90% (non-condensing)
Packaging Dimensions
1180 x 706 x 306 mm
Packaging Content
1 x H263-V60-AAW1
8 x Superchip heatsinks
1 x Mini-DP to D-Sub cable
1 x 3-Section Rail kit
8 x Superchip heatsinks
1 x Mini-DP to D-Sub cable
1 x 3-Section Rail kit
Part Numbers
- Barebone w/ Nvidia module: 6NH263V60MR000AAW1*
- Motherboard: 9MV63HD0UR-000
- 3-Section Rail kit: 25HB2-A66125-K0R
- Superchip heatsink: 25ST1-2532Z1-A0R
- Superchip heatsink: 25ST1-2532Z4-A0R
- Front panel board - CFPH004: 9CFPH004NR-00
- Backplane board - CBPH7O1: 9CBPH7O1NR-00
- Fan module: 25ST2-888020-S1R
- M.2 riser card - CMTP0A2: 9CMTP0A2NR-00
- LAN board - CLBH010: 9CLBH010NR-00
- Mini-DP to D-Sub cable: 25CRN-200801-K1R
- Power supply: 25EP0-23000L-L0S
Optional parts:
- RMA packaging: 6NH263V60SR-RMA-A100
- Motherboard: 9MV63HD0UR-000
- 3-Section Rail kit: 25HB2-A66125-K0R
- Superchip heatsink: 25ST1-2532Z1-A0R
- Superchip heatsink: 25ST1-2532Z4-A0R
- Front panel board - CFPH004: 9CFPH004NR-00
- Backplane board - CBPH7O1: 9CBPH7O1NR-00
- Fan module: 25ST2-888020-S1R
- M.2 riser card - CMTP0A2: 9CMTP0A2NR-00
- LAN board - CLBH010: 9CLBH010NR-00
- Mini-DP to D-Sub cable: 25CRN-200801-K1R
- Power supply: 25EP0-23000L-L0S
Optional parts:
- RMA packaging: 6NH263V60SR-RMA-A100
* The entire materials provided herein are for reference only. GIGABYTE reserves the right to modify or revise the content at anytime without prior notice.
* Advertised performance is based on maximum theoretical interface values from respective Chipset vendors or organization who defined the interface specification. Actual performance may vary by system configuration.
* All trademarks and logos are the properties of their respective holders.
* Due to standard PC architecture, a certain amount of memory is reserved for system usage and therefore the actual memory size is less than the stated amount.
* Advertised performance is based on maximum theoretical interface values from respective Chipset vendors or organization who defined the interface specification. Actual performance may vary by system configuration.
* All trademarks and logos are the properties of their respective holders.
* Due to standard PC architecture, a certain amount of memory is reserved for system usage and therefore the actual memory size is less than the stated amount.
SUPPORT
BIOS
Firmware
OS
BIOS
Mô tả
Phiên bản
Kích cở
Ngày
1. Removed Mellanox CX7 duplicate MAC in boot option
2. Added SMBIOS Type39 PSU detected
3. Modified Redfish BiosAttribute item
2. Added SMBIOS Type39 PSU detected
3. Modified Redfish BiosAttribute item
Version : F18
18.21 MB
Nov 11, 2024
1) Fixed PKfail Vulnerability.
2) Updated to NVIDIA Firmware 02.02.02.
3) Multiple feature updates and bug fixes.
2) Updated to NVIDIA Firmware 02.02.02.
3) Multiple feature updates and bug fixes.
Version : F15
18.04 MB
Aug 23, 2024
1. Updated CVE Patch LogoFAIL CVE-2023-39539 and CVE-2023-39538
2. Fixed previous BIOS chipset item not load default issue
2. Fixed previous BIOS chipset item not load default issue
Version : F07
17.4 MB
May 16, 2024
Windows and UEFI mode flash BIOS SOP
Please download BIOS update tool from AMI Website
Please download BIOS update tool from AMI Website
-
0.31 MB
Jan 29, 2021
Cảnh báo:
Do việc flash BIOS chứa đựng rủi ro, nếu bạn không gặp vấn dề với BIOS cũ, bạn không nên flash BIOS. Để flash BIOS, hãy cẩn thận. Quá trình flash BIOS có thể dẫn đến trục trặc hệ thống.
Thế nào là BETA?
BETA là mô tả phiên bản mới đáng tin cậy, nhưng vẫn chưa đầy đủ các tính năng cuối cùng. Trong giai đoạn này chúng tôi xem trước các tính năng mới và thu thập ý kiến của khác hàng để đảm bảo sàn phẩm của chúng tôi, cung cấp những kinh nghiệm tốt nhất có thể.
Do việc flash BIOS chứa đựng rủi ro, nếu bạn không gặp vấn dề với BIOS cũ, bạn không nên flash BIOS. Để flash BIOS, hãy cẩn thận. Quá trình flash BIOS có thể dẫn đến trục trặc hệ thống.
Thế nào là BETA?
BETA là mô tả phiên bản mới đáng tin cậy, nhưng vẫn chưa đầy đủ các tính năng cuối cùng. Trong giai đoạn này chúng tôi xem trước các tính năng mới và thu thập ý kiến của khác hàng để đảm bảo sàn phẩm của chúng tôi, cung cấp những kinh nghiệm tốt nhất có thể.
Firmware
Mô tả
Phiên bản
Kích cở
Ngày
BMC firmware with embedded GIGABYTE Management Console
(AST2600)
For NVIDIA Grace/ Grace Hopper platform
For NVIDIA Grace/ Grace Hopper platform
Version : 13.99.09
114.4 MB
Mar 29, 2024
Tiếng Anh
Mô tả
Phiên bản
Kích cở
Ngày
OS Support List
Version : 1.0
0.02 MB
Mar 28, 2024
NVIDIA Grace/ Grace Hopper OS Support List
