H242-Z11

HCI Server - AMD EPYC™ 7002/7001 - 2U 4-Node UP 4-Bay NVMe/SATA
  • Supports 5G network infrastructure
  • 2U 4-node front access server system for Edge Computing
  • Single AMD EPYC™ 7002/7001 Series Processors per node
  • 8-Channel DDR4 RDIMM/LRDIMM, 32 x DIMMs
  • 8 x 1Gb/s LAN ports via Intel® I350-AM2
  • 4 x 2.5" Gen3 NVMe/SATA hot-swappable bays
  • 8 x M.2 slots with PCIe Gen3 x4 interface
  • 4 x LP PCIe Gen4 x16 slots
  • 4 x LP PCIe Gen3 x16 slots
  • 4 x OCP 2.0 Gen3 x16 mezzanine slots
  • Dual 1300W 80 PLUS Platinum redundant power supply
Get a Quote
* The entire materials provided herein are for reference only. GIGABYTE reserves the right to modify or revise the content at anytime without prior notice.
* Advertised performance is based on maximum theoretical interface values from respective Chipset vendors or organization who defined the interface specification. Actual performance may vary by system configuration.
* All trademarks and logos are the properties of their respective holders.
* Due to standard PC architecture, a certain amount of memory is reserved for system usage and therefore the actual memory size is less than the stated amount.

SPECIFICATIONS

Dimensions (WxHxD, mm)
2U 4-Node - Front access
440 x 87.5 x 475
Motherboard
MZ12-HD0
CPU
AMD EPYC™ 7002 Series Processors
AMD EPYC™ 7001 Series Processors
Single processor per node, 7nm technology
Up to 64 cores, 128 threads
TDP up to 225W, cTDP up to 240W

Supports cTDP 280W at ambient 30°C
Socket
Per Node:
1 x LGA 4094

Total:
4 x LGA 4094

Socket SP3
Chipset
System on Chip
Memory
Per node:
8 x DIMM slots

Total:
32 x DIMM slots

DDR4 memory supported only
8-Channel memory architecture
RDIMM up to 128GB supported
LRDIMM up to 128GB supported
Memory speed: Up to 3200 MT/s
LAN
Per node:
2 x 1Gb/s LAN ports (1 x Intel® I350-AM2)
Support NCSI function

1 x 10/100/1000 Mbps Management port

Total:
8 x 1Gb/s LAN ports (4 x Intel® I350-AM2)
Support NCSI function

4 x 10/100/1000 Mbps Management ports
Video
Integrated in Aspeed® AST2500 x 4
- 4 x VGA ports
Storage
Per node:
1 x 2.5" Gen3 NVMe/SATA hot-swappable bay

Total:
4 x 2.5" Gen3 NVMe/SATA hot-swappable bays
SAS
N/A
RAID
N/A
Expansion Slots
Per node:
1 x PCIe x16 (Gen4 x16) low-profile slot
1 x PCIe x16 (Gen3 x16) low-profile slot

1 x OCP 2.0 mezzanine slot with PCIe Gen3 x16 bandwidth (Type1, P1, P2, P3, P4 with NCSI supported)

2 x M.2 slots:
- M-key
- PCIe Gen3 x4
- Supports 2242/2260/2280/22110 cards

Total:
4 x PCIe x16 (Gen4 x16) low-profile slots
4 x PCIe x16 (Gen3 x16) low-profile slots

4 x OCP 2.0 mezzanine slots with PCIe Gen3 x16 bandwidth (Type1, P1, P2, P3, P4 with NCSI supported)

8 x M.2 slots:
- M-key
- PCIe Gen3 x4
- Supports 2242/2260/2280/22110 cards
Internal I/O
Per node:
1 x TPM header
Front I/O
Per node:
2 x USB 3.0
1 x VGA
2 x RJ45
1 x MLAN
1 x Power button with LED
1 x ID button with LED
1 x Reset button
1 x System status LED
1 x ID LED

Total:
8 x USB 3.0
4 x VGA
8 x RJ45
4 x MLAN
4 x Power buttons with LED
4 x ID buttons with LED
4 x Reset buttons
4 x System status LEDs
4 x ID LEDs
Rear I/O
N/A
Backplane Board
Speed and bandwidth:
PCIe Gen3 x4 or SATA 6Gb/s
TPM
1 x TPM header with SPI interface
- Optional TPM2.0 kit: CTM010
Power Supply
Dual 1300W 80 PLUS Platinum redundant power supply

AC Input:
- 100-240V~/ 12-7A, 50-60Hz
- 200-240V~/ 8A, 50-60Hz

DC Input: (Only for China)
- 240Vdc/ 6.5A

DC Output:
- Max 1000W/ 100-240V~
+12V/ 80.5A
+12Vsb/ 3A
- Max 1300W/ 200-240V~ or 240Vdc Input
+12V/ 105.4A
+12Vsb/ 3A
System Management
Aspeed® AST2500 Baseboard Management Controller
GIGABYTE Management Console web interface

  • Dashboard
  • JAVA Based Serial Over LAN
  • HTML5 KVM
  • Sensor Monitor (Voltage, RPM, Temperature, CPU Status …etc.)
  • Sensor Reading History Data
  • FRU Information
  • SEL Log in Linear Storage / Circular Storage Policy
  • Hardware Inventory
  • Fan Profile
  • System Firewall
  • Power Consumption
  • Power Control
  • LDAP / AD / RADIUS Support
  • Backup & Restore Configuration
  • Remote BIOS/BMC/CPLD Update
  • Event Log Filter
  • User Management
  • Media Redirection Settings
  • PAM Order Settings
  • SSL Settings
  • SMTP Settings
OS Compatibility
Citrix Hypervisor 8.1.0 or later

Red Hat Enterprise Linux 7.6 or later
Red Hat Enterprise Linux 8.0 or later
Red Hat Enterprise Linux 9.0 or later

SUSE Linux Enterprise Server 12 SP4 or later
SUSE Linux Enterprise Server 15 SP1 or later

Ubuntu 16.04.6 LTS or later
Ubuntu 18.04.3 LTS or later
Ubuntu 20.04 LTS or later

VMware ESXi 6.5 EP15 or later
VMware ESXi 6.7 Update3 or later
VMware ESXi 7.0 or later
VMware ESXi 8.0 or later

Windows Server 2016 (X2APIC/256T not supported)
Windows Server 2019
System Fans
3 x 80x80x38mm (16,300rpm)
1 x 40x40x28mm (25,000rpm)
Operating Properties
Operating temperature: 10°C to 35°C
Operating humidity: 8%-80% (non-condensing)
Non-operating temperature: -40°C to 60°C
Non-operating humidity: 20%-95% (non-condensing)
Packaging Dimensions
857 x 670 x 280 mm
Packaging Content
1 x H242-Z11
4 x CPU heatsinks
1 x 2-Section Rail kit
Part Numbers
- Barebone package: 6NH242Z11MR-00-1*
- Motherboard: 9MZ12HD0NR-00
- 2-Section Rail kit: 25HB2-AA6107-K0R
- Backplane board - CBPH043: 9CBPH043NR-00
- CPU heatsink: 25ST1-44320J-A0R
- Fan module: 25ST2-44282D-D0R/25ST2-88382E-D0R
- Power supply: 25EP0-213006-F3S

Optional parts:

- M.2 expansion card - CMTP051: 9CMTP051NR-00
- CMC kit: 6NH242Z13SR-00
- M.2 heatsink kit: 6NH242Z17SR-00-100
- RMA packaging: 6NH242Z11SR-RMA-A100
