• Supports AMD Ryzen™ 5000 Series/ Ryzen™ 5000 G-Series and Ryzen™ 4000 G-Series processors
  • Dual Channel 2 x DDR4 SO-DIMM and Up to 32G System Memory Support
  • Direct 5 Phases Digital VRM Solution with 55A DrMOS
  • Ultra-Fast NVMe PCIe 3.0 x4 M.2
  • Realtek Gaming GbE LAN with Bandwidth Management and Realtek DASH LAN with Management Console Software
  • 8-Channel HD Audio with 3W Audio Amplifier
  • Dual DisplayPort + HDMI Ports for for Multiple Display
  • Infineon TPM 2.0 Controller Onboard
  • DC in 19V/6A Power Adapter Require
1
HDMI
2
DisplayPort*2
3
DC in 19V/6A
4
Realtek DASH LAN with Management Console
5
Realtek Gaming GbE LAN with Bandwidth Management
6
8-Channel HD Audio
7
Featured 3W Audio Amplifier for Speaker
8
TPM 2.0 Controller Onboard
9
Direct 5 Phases Digital VRM Solution with DrMOS
• 55A DrMOS
• Premium Choke and Capacitor
• 10 Layer PCB
10
Supports AMD Ryzen™ Series processors
11
Dual Channel, 2 x DDR4 SO-DIMMs
12
USB 2.0 Header*2
13
SATA3 Ports*2
14
RS232 COM Header*2
15
NVMe PCIe 3.0 x4 M.2 Connector
16
USB 3.2 Gen1 Header*1
Infineon TPM 2.0 Controller Onboard
TPM (Trusted Platform Module) can enhance data and network security, from your personal drive, E-mails, file system to the client-server environment. Worked with hardware and software, TPM is able to ensure your data flows, data communications and signal transmissions are secure.
Dual Realtek LAN with DASH Capabilities and Better Network Connectivity
Desktop and mobile Architecture for System Hardware (DASH) Standard is a suite of specifications that takes full advantage of its Web Services for Management (WS-Management) specification – delivering standards-based Web services management for desktop and mobile client systems. Through DASH, it provides the next generation of standards for secure out-of-band and remote management of desktop and mobile systems.

Realtek 8118 LAN is a high performance and friendly network chip for gaming players with automatic bandwidth allocation to ensure the highest network priority of the game or application. It can provide users the most comprehensive features and the fastest and smoothest Internet experience.
The Industry's Leading LAN Static-Electricity & Surge Protection
GIGABYTE motherboards use ICs with up to 3 times the ESD resistance levels compared to traditional ICs. This helps to better protect the motherboard and its components against potential damage caused by static electricity. GIGABYTE motherboards also feature special anti-surge ICs that protect your motherboard, and your PC from any surge in power delivery that may occur, helping to ensure that your PC is equipped to deal with any potentially irregular and inconsistent power delivery.
NVMe PCIe Gen3 x4 M.2 Connector
GIGABYTE Motherboards are focused on delivering M.2 technology to enthusiasts who want to maximize their system’s potential.
START SULFURIZATION PROTECTION

Sulfur compounds in the air can penetrate tiny onboard resistors creating chemical change and causing these resistors to open or short. If either of these occurs the motherboard will fail to function. By equipping resistors with an Anti-Sulfur Design GIGABYTE gives Ultra Durable Motherboards a whole new meaning.

Humidity Protection Glass Fabric PCB

There is nothing more harmful to the longevity of your PC than moisture, and most parts of the world experience moisture in the air as humidity at some point during the year. GIGABYTE motherboards have been designed to make sure that humidity is never an issue, incorporating a new Glass Fabric PCB technology that repels moisture caused by humid and damp conditions. Glass Fabric PCB technology uses a new PCB material which reduces the amount of space between the fiber weave, making it much more difficult for moisture to penetrate compared to traditional motherboard PCBs. This offers much better protection from short circuit and system malfunction caused by humid and damp conditions.

High Temperature Protection Lower RDS(on) MOSFETs Design

GIGABYTE motherboards use Low RDS(on) MOSFETs which reduce energy wastage through unnecessary residual heat dissipation. This all amounts to tangible energy savings which are beneficial for both end-users and the environment without impacting system performance.

High Definition Digital Outputs

Enjoy true HD display capability using the most commonly integrated digital output technologies on today’s HD displays and TVs.

* Support for up to 3 displays once at same time. Actual support may vary by CPU.

4K Ultra HD Support

4K resolution is the next technological milestone in high-definition content delivery, utilizing approximately 4,000 pixels on the horizontal axis, more than four times today's standard HD pixel density. GIGABYTE motherboards provide native 4K support with integrated AMD Radeon® Graphics via HDMI.

HDMI™ - The Next Generation Multimedia Interface

HDMI™ is a High-Definition Multimedia Interface which provides up to 5Gb/s video transmitting bandwidth and 8-channel high quality audio all through a single cable. Able to transmit superior, uncompressed digital video and audio, HDMI™ ensures the crispest rendering of digital content up to 1080p without the quality losses associated with analog interfaces and their digital-to-analog conversion. In addition, HDMI™ is compatible with HDCP (High-bandwidth Digital Content Protection), allowing the playback of Blu-ray/HD DVD and other protected media content.
