• Supports Intel® Pentium® D Processor
  • Dual Channel DDR2 667 for advanced system performance
  • Integrated Intel® Graphic Media Accelerator 950
  • Integrated SATA 3Gb/s with RAID 0,1,5,10
  • Features T.I IEEE 1394b and Gigabit Ethernet connections
  • Features 8-channel Intel® High Definition Audio
  • Optimized for Intel® Dual core Processor
    สนุกไปกับเทคโนโลยีการประมวลผลที่เต็มเปี่ยมไปด้วยประสิทธิภาพกับ dual-core CPU. ระบบประมวลผลยุคใหม่ที่มีระบบการคำนวณที่รวดเร็วด้วย CPU cores จำนวน 2 ตัว ที่มีพร้อมกับ L2 Caches ภายในสำหรับเติมเต็มประสิทธิภาพได้มากยิ่งกว่า
  • Intelligent Data Protection
    Highly advanced Intel® Matrix Storage technology allows RAID 0 (Striping), RAID 1 (Mirroring), RAID 0+1 (Striping and Mirroring), and RAID 5 (Parity RAID) multi-disk designs to be created by the user depending on their preference for protection or performance.
  • Intel® Graphics Media Accelerator 950
    The Intel® Graphics Media Accelerator 950 combines faster graphics processing and increased memory bandwidth to deliver richer visual quality and colors without the need for additional discrete graphics cards.
  • Step on to high speed connectivity
    The high-speed Gigabit Ethernet for LAN connection speed of up to 1,000 Mb/s, allows internet activities such as online gaming or watching streaming videos without delays. As well the onboard Firewire (IEEE1394b) delivers high-speed data thru-put of up to 800Mb/s, enhances PC connectivity for consumer electronics A/V appliances, storage peripherals and portable devices.
  • CPU Intelligent Accelerator 2
    With GIGABTYE C.I.A 2 technology, users are able to enjoy the benefits of overclocking without having too much trouble of manually adjustment. C.I.A. 2 provides reasonable and acceptable overclocking options for user to select, all what user need to do is to select the desirable overclocking level and the rest environment settings are automatically setup by the BIOS.
  • Memory Intelligent Booster 2
    Designed to maximize memory performance and boost memory bandwidth by optimizing data transmission among CPU, north bridge chipset and memory. The innovative GIGABYTE M.I.B. 2 technology shortens memory latency time and enhances system performance without sacrificing stability.
  • Intel® High Definition Audio
    Intel® High Definition Audio enables 8 channel premium digital sound in the PC for an immersive surround sound experience. In addition, Intel HD Audio delivers multiple audio channels in your PC so you can listen to two different streams simultaneously in two separate rooms.
  • GigaRAID IDE RAID Controller
    This platform supports reliable storage solution for enhanced data protection and data accessing performance. Serial ATA 3Gb/s is firstly introduced in this platform to provide blazingly 3Gb/s bus bandwidth thus higher disk performance. The NVIDIA RAID allows multi-disk designs to be set up as RAID 0,1,0+1 based on users’ priority of protection/ performance. This NVIDIA RAID function makes the RAID even more accessible by introducing the innovative windows-based facility.
  • i-Cool
    ทำให้ PC ของคุณเย็นและเงียบได้อย่างง่ายๆ โดยการลดความร้อนของ CPU จากการลดความเร็วของสัญญาณนาฬิกา และลดความเร็วของพัดลมให้เงียบลง.
  • SATA 3Gb/s storage interface
    ให้ bandwidth lสูง 1.5Gb/s to 3Gb/s. นับเป็นเทคโนโลยีในการโอนถ่ายข้อมูลใหม่สำหรับฮาร์ดดิสก์ความเร็วสูง. รองรับ Hot Plug ฟังก์ชันที่ไม่ต้องปิดเครื่อง pc เมื่อมีการถอดฮาร์ดดิสก์

* คำว่ำ HDMI, HDMI High-Definition Multimedia Interface, HDMI Trade dress และโลโก้ HDMI เป็ นเคร ื่องหมำยกำรค้ำหรือเครื่องหมำยกำรค้ำจดทะเบียนของ HDMI Licensing Administrator, Inc.
* ข้อมูลเบื้องต้นมีไว้สำหรับอ้างอิงเท่านั้น GIGABYTE ขอสงวนสิทธิ์ในการปรับเปลี่ยนหรือแก้ไขเนื้อหาได้ตลอดเวลาโดยไม่ต้องแจ้งให้ทราบล่วงหน้า
* ประสิทธิภาพสูงสุดที่ใช้ในการประชาสัมพันธ์เป็นเพียงข้อมูลตามทฤษฎีจากผู้ผลิตชิปเซ็ตที่เกี่ยวข้อง หรือองค์กรที่กำหนดคุณสมบัติอินเตอร์เฟส ประสิทธิภาพที่แท้จริงอาจแตกต่างกันโดยการตั้งค่าของระบบที่ไม่เหมือนกัน
* เครื่องหมายการค้าและโลโก้คุณสมบัติต่างๆ เป็นของผู้ถือสิทธิ์นั้นๆ
* เนื่องจากความต้องการหน่วยความจำมาตรฐานของสถาปัตยกรรมคอมพิวเตอร์ต่อหน่วยที่ไม่เหมือนกัน ดังนั้นขนาดหน่วยความจำที่จำเป็นอาจน้อยกว่าจำนวนที่ระบุไว้ก็ได้
