• Supports 6th Generation Intel® Core™ Processor
  • Dual Channel DDR4 SO-DIMM, 2 DIMMs
  • Features USB 3.0 with USB Type-C™ Support
  • 1 x RS232 COM Port Support
  • M.2 Socket 1 Interface for WIFI+BT Module Support
  • M.2 Socket 3 Interface for SATA Mode SSD Support
  • Rear Panel DisplayPort, HDMI 1.4, D-Sub Ports for Multi-Display Connection
  • Amplified Speaker Header Able to Drive Up to 3W System Integrated Speaker
  • Intel® GbE LAN for WOL and PXE Support
  • GIGABYTE UEFI DualBIOS™ Technology
  • Mini-STX 147x140mm Form Factor with 12~19V DC-In Power Design
  • Support Intel® Small Business Basics
  • GIGABYTE Ultra Durable ™ Motherboards

    GIGABYTE 100 series motherboards support the latest 6th Generation Intel® Core™ processors, a 14nm desktop CPU which features improved performance, power efficiency and support for DDR4 memory, bringing cutting edge features and ultimate performance to your next PC build.
  • Connecting the Future - USB Type-C™:
    The World's Next Universal Connector

    The USB Type-C™ port with USB 3.0 support is a robust and slim connector for all of your devices with reversible plug orientation.


    USB Type-C
  • Dual M.2 Technology for SSD Drive and WIFI Card
    Fast Data Transfer and Advanced WIFI Networking

    GIGABYTE H110MSTX-HD3 motherboard features Dual M.2 technology which for SATA mode SSD devices connectivity and also for 11ac WIFI & Bluetooth 4.0 card usage. GIGABYTE’s stacked design optimizes the PCB real-estate usage, allowing more components to be efficiently added without compromising any space.

  • High Definition Digital Outputs
    Enjoy true HD display capability using the most commonly integrated digital output technologies on today’s HD displays and TVs.
     * Support for up to 2 displays at the same time.
    High Definition Digital Outputs
  • 4‎K Ultra HD Support
    4K resolution is the next technological milestone in high-definition content delivery, utilizing approximately 4,000 pixels on the horizontal axis, more than four times today's standard HD pixel density. GIGABYTE motherboards provide native 4K support with integrated Intel® HD Graphics via HDMI.
  • HDMI™-The Next Generation Multimedia Interface
    HDMI™ is a High-Definition Multimedia Interface which provides up to 5Gb/s video transmitting bandwidth and 8-channel high quality audio all through a single cable. Able to transmit superior, uncompressed digital video and audio, HDMI™ ensures the crispest rendering of digital content up to 1080p without the quality losses associated with analog interfaces and their digital-to-analog conversion. In addition, HDMI™ is compatible with HDCP (High-bandwidth Digital Content Protection), allowing the playback of Blu-ray/HD DVD and other protected media content.
  • پشتیبانی از Display Port
    مادربردهای گیگابایت مجهز به جدیدترین نسل رابط های تصویری یعنی Display Port هستند. این رابط ارائه دهنده 10.8 گیگابیت در ثانیه پهنای باند به وسیله یک کابل استاندارد است. این رابط ارائه دهنده میلیارها رنگ، بالاترین سرعت نرخ بازیابی اطلاعات و بیشترین عمق رنگ است.
  • Intel® GbE LAN with WOL and PXE Support
    Intel® Gigabit LAN with WOL and PXE support, deliver better network responsiveness and conveniently user experience in crowded LAN environments, to offer hassle free and high speed network connectivity.
    Intel® GbE LAN with WOL and PXE Support
  • USB 3.0 Ports Onboard
    With superfast transfer rates of up to 5 Gbps, users are able to experience an almost a 10x improvement over USB 2.0. Additionally, backwards compatibility with USB 2.0 assures users legacy USB 2.0 devices will still work.


    * USB 3.0 10x performance is a maximum theoretical value.
    Actual performance may vary by system configuration.
  • INTEL® SMALL BUSINESS BASICS
    With 6th Generation Intel® Core™ Processor
    Security and Productivity Solution with built in IT
    New compelling usages in one intuitive Customizable UI
  • Compatible with GIGABYTE Mini STX Chassis
    (Part number : 20EC5-01MS01-01R)
    (Size : 193 x 153 x 67 mm)
    Compatible with GIGABYTE Mini STX Chassis

* The terms HDMI, HDMI High-Definition Multimedia Interface, HDMI Trade dress and the HDMI Logos are trademarks or registered trademarks of HDMI Licensing Administrator, Inc.
* کلیه موارد ارایه شده در این صفحه تنها مربوط به نوع مرجع می باشد. گیگابایت حق تغییر یا تجدید نظر محتویات را در هر لحظه و بدون اطلاع قبلی دارد.
* کارایی ارایه شده بر اساس مقادیر حداکثر نظری رابط است که توسط فروشنده چیپ ست یا سازمان هایی که مشخصات رابط را تعیین کردند، ارائه شده است. کارایی واقعی ممکن است بنا بر پیکربندی سیستم متفاوت باشد.
* کلیه لوگو ها و آرم های ثبت شده تحت مالکیت مالکین مربوطه آن ها قرار دارد.
* با توجه به معماری استاندارد رایانه های شخصی، مقدار مشخصی از حافظه جهت استفاده درونی سیستم درنظر گرفته می شود و طبیعتا مقدار واقعی حافظه سیستم کم تر از مقدار اظهار شده خواهد بود.
