MP72-HB0

Rev. 3.0

Motherboard - Ampere^® Altra^®/Altra^® Max - E-ATX DP

Dual Ampere^® Altra^®/Altra^® Max Processors
8-Channel RDIMM/LRDIMM DDR4, 16 x DIMMs
Dual ROM Architecture
2 x 10Gb/s BASE-T LAN ports via Broadcom^® BCM57416
2 x SlimSAS connectors for 2 x Gen4 NVMe
1 x SlimSAS connectors for 4 x SATA 6Gb/s
2 x SATA 6Gb/s ports
1 x M.2 slot with PCIe Gen4 x4 interface
4 x PCIe Gen4 x16 and x8 expansion slots

Get a Quote

Vergelijker

Get a Quote

* Alle materialen zijn alleen voor uw referenctie. GIGABYTE behoudt zich het recht om zonder aankondiging de inhoud te wijzigen of te herzien.
* Alle handelsmerken en logo's zijn eigendom van hun respectieve houders.
* Door de standaard PC-architectuur, wordt een bepaalde hoeveelheid geheugen gereserveerd voor gebruik van het systeem en dus is de werkelijke geheugengrootte kleiner dan de aangegeven hoeveelheid.

SPECIFICATIONS

Form Factor

E-ATX
305W x 330D mm

CPU

Ampere^® Altra^® Processors
Ampere^® Altra^® Max Processors
Dual processor, 7nm technology
Up to 128 cores, TDP 250W

Note: If only 1 CPU is installed, some PCIe or memory functions might be unavailable.

Socket

2 x LGA 4926

Chipset

System on Chip

Memory

16 x DIMM slots
DDR4 memory supported only
8-Channel memory architecture
RDIMM up to 256GB supported
LRDIMM up to 256GB supported
Memory speed: Up to 3200 MT/s

Note: Only supports configurations with 1, 2, 4, 6, 8 DIMMs (1DPC).

LAN

2 x 10Gb/s BASE-T LAN ports (Broadcom^® BCM57416)
Support NCSI function

1 x 10/100/1000 Mbps Management LAN

Video

Integrated in Aspeed^® AST2600
2D Video Graphic Adapter with PCIe bus interface
1920x1200@60Hz 32bpp

Audio

N/A

Storage Interface

2 x SlimSAS connectors for 2 x Gen4 NVMe
1 x SlimSAS connectors for 4 x SATA 6Gb/s
2 x SATA 6Gb/s ports

RAID

N/A

Expansion Slots

Slot_4: PCIe x16 (Gen4 x16) slot, from CPU_0
Slot_3: PCIe x16 (Gen4 x16) slot, from CPU_0
Slot_2: PCIe x16 (Gen4 x16) slot, from CPU_1
Slot_1: PCIe x16 (Gen4 x8) slot, from CPU_0

1 x M.2 slot:
- M-key
- PCIe Gen4 x4, from CPU_0
- Supports 2280/22110 cards
- From CPU_0

Internal I/O

1 x 24-pin ATX main power connector
2 x 8-pin ATX 12V power connectors
2 x CPU fan headers
2 x System fan headers
1 x USB 3.2 Gen1 x2 header
1 x USB 2.0 header
1 x M.2 slot
3 x SlimSAS connectors
2 x SATA connectors
1 x Front panel header
1 x Backplane board header
1 x PMBus connector
1 x IPMB connector
1 x TPM header

Rear I/O

2 x USB 3.2 Gen1
1 x VGA
2 x RJ45
1 x MLAN
1 x ID button with LED

TPM

1 x TPM header with SPI interface
Optional TPM2.0 kit: CTM010

OS Supported

CentOS 8.3-2011 (aarch64) or later
CentOS-8.4.2105 (aarch64) or later
CentOS-8.5.2111 (aarch64) or later

Debian 10.9 (Buster)
Debian 11.1

Fedora Server 33-1.2 (aarch64) or later
Fedora Server 35-1.2 (aarch64) or later

OracleLinux R8 U2
OracleLinux R8 U5

Red Hat Enterprise Linux 8.3 (aarch64) or later
Red Hat Enterprise Linux 8.5 (aarch64) or later
Red Hat Enterprise Linux 9.0 (aarch64) or later

SUSE Linux Enterprise Server 15 SP2 (aarch64) or later
SUSE Linux Enterprise Server 15 SP3 (aarch64) or later

Ubuntu 18.04.5 LTS (aarch64) or later
Ubuntu 20.04.1 LTS (aarch64) or later

Board Management

Aspeed^® AST2600 management controller
GIGABYTE Management Console (AMI MegaRAC SP-X) web interface

Dashboard
HTML5 KVM
Sensor Monitor (Voltage, RPM, Temperature, CPU Status …etc.)
Sensor Reading History Data
FRU Information
SEL Log in Linear Storage / Circular Storage Policy
Hardware Inventory
Fan Profile
System Firewall
Power Consumption
Power Control
Advanced power capping
LDAP / AD / RADIUS Support
Backup & Restore Configuration
Remote BIOS/BMC/CPLD Update
Event Log Filter
User Management
Media Redirection Settings
PAM Order Settings
SSL Settings
SMTP Settings

PSU Connectors

1 x 24-pin ATX main power connector
2 x 8-pin ATX 12V power connectors

Operating Properties

Operating temperature: 10°C to 40°C
Operating humidity: 8-80% (non-condensing)
Non-operating temperature: -40°C to 60°C
Non-operating humidity: 20%-95% (non-condensing)

Retail Packaging Content

N/A

Bulk Packaging Content

10 x MP72-HB0
10 x I/O shields

Carton dimensions: 600 x 473 x 495 mm

Reference Numbers

Bulk: 9MP72HB0NR-00-3*

Part Numbers:

- I/O shield: 12AIO-MZ72H0-00R

Optional parts:

- Fansink: 12SF2-01A101-00R
