GA-H110TN-E (rev. 1.0)
Intel® H110 Chipset
![](/FileUpload/Global/Other/2/Photo/3826.png)
- Supports 7th / 6th Generation Intel® Core™ Processor
- Dual Channel DDR4 SO-DIMM, 2 DIMMs
- Mini-PCIe Slot for Full/ Half-Height WIFI Card Support
- Mini-PCIe Dual Purpose Slot for mSATA SSD Support
- LVDS Header for System Integrated Flat Panel Display Support
- Rear Panel DisplayPort, HDMI 1.4 Ports for Multi-Display Connection
- Amplified Speaker Header Able to Drive Up to 3W System Integrated Speaker
- Intel® GbE LAN for WOL and PXE Support
- Features 4 USB 3.0 and 4 USB 2.0 Ports
- GIGABYTE UEFI DualBIOS™ Technology
- Thin Mini-ITX 170x170mm Form Factor with 12/19~24V DC-In Power Design
-
-
GIGABYTE Ultra Durable of Mini-ITX MotherboardGIGABYTE H110 Thin Mini-ITX motherboards support the latest 6th Generation Intel® Core™ processors, a 14nm desktop CPU which features improved performance, power efficiency and support for DDR4 memory, bringing cutting edge features and ultimate performance to your next PC build. Offering an All-in-One, small form factor and slim profile PC experience, GIGABYTE H110 Thin Mini-ITX motherboards are 43% thinner than traditional Mini-ITX designs. Complying with the latest Thin Mini-ITX guidelines, GIGABYTE motherboards offer additional flexibility making them suited to broad range of innovative PC designs.
-
Intel® GbE LAN with WOL and PXE SupportIntel® Gigabit LAN with WOL and PXE support, deliver better network responsiveness and conveniently user experience in crowded LAN environments, to offer hassle free and high speed network connectivity.
-
High Definition Digital Outputs
-
4K Ultra HD Support4K resolution is the next technological milestone in high-definition content delivery, utilizing approximately 4,000 pixels on the horizontal axis, more than four times today's standard HD pixel density. GIGABYTE motherboards provide native 4K support with integrated Intel® HD Graphics via HDMI.
-
HDMI™-The Next Generation Multimedia InterfaceHDMI™ is a High-Definition Multimedia Interface which provides up to 5Gb/s video transmitting bandwidth and 8-channel high quality audio all through a single cable. Able to transmit superior, uncompressed digital video and audio, HDMI™ ensures the crispest rendering of digital content up to 1080p without the quality losses associated with analog interfaces and their digital-to-analog conversion. In addition, HDMI™ is compatible with HDCP (High-bandwidth Digital Content Protection), allowing the playback of Blu-ray/HD DVD and other protected media content.
-
Suport Display PortPlăcile de bază GIGABYTE sunt dotate cu interfața DisplayPort pentru viitoarele generații de siplay-uri grafice. Acesta permite o lățime de bandă de până la 10.8 Gbps prin cabluri normale, oferind miliarde de culori, cele mai rapide rate de refresh și cele mai bune adâncimi de culoare.
-
USB 3.0 Ports OnboardWith superfast transfer rates of up to 5 Gbps, users are able to experience an almost a 10x improvement over USB 2.0. Additionally, backwards compatibility with USB 2.0 assures users legacy USB 2.0 devices will still work.
* USB 3.0 10x performance is a maximum theoretical value.
Actual performance may vary by system configuration. -
Low Power Loss - Ferrite Core Choke Design
-
GIGABYTE Patented DualBIOS™ (UEFI) DesignGIGABYTE Ultra Durable™ motherboards feature GIGABYTE DualBIOS™, an exclusive technology from GIGABYTE that protects arguably one of your PC's most crucial components, the BIOS. GIGABYTE DualBIOS™ means that your motherboard has both a 'Main BIOS' and a 'Backup BIOS', making users protected from BIOS failure due to virus attack, hardware malfunction, improper OC settings or power failure during the update process.
-
2x Copper PCB Design (2 oz Copper PCB)GIGABYTE’s exclusive 2X Copper PCB design provides sufficient power trace paths between components to handle greater than normal power loads and to remove heat from the critical CPU power delivery area. This is essential to ensure the motherboard is able to handle the increased power loading that is necessary when overclocking.
-
INTEL® SMALL BUSINESS BASICSWith 6th Generation Intel® Core™ Processor
Security and Productivity Solution with built in IT
New compelling usages in one intuitive Customizable UI
![](/FileUpload/global/Other/11/Photo/hdmi_logo.png)
* Termenii HDMI, HDMI High-Definition Multimedia Interface, Imaginea comercială HDMI și Siglele HDMI sunt mărci comerciale sau mărci comerciale înregistrate ale HDMI Licensing Administrator, Inc.
* Materialele oferite aici sunt doar pentru referinţă. GIGABYTE îşi rezervă dreptul de a modifica sau revizui continutul oricând fără notificare prealabilă.
* Perfomanţa prezentată este bazată pe valorile teoretice maxime ale interfeţei de la vendorii respectivi de Chipset-uri sau de la organizaţiile ce au definit specificaţiile interfeţei. Perfomanţele reale pot varia în funcţie de sistem.
* Toate mărcile inregistrate şi logo-urile sunt proprietatea deţinătorilor respectivi.
* Datorită arhitecturii standard PC, o anumită cantitate de memorie este rezervată pentru sistem şi de aceea mărimea actuală a memoriei este mai mică decât cea indicată.
