GA-IMB410TN (rev. 1.0)
- Socket LGA1200 for Intel core i9/i7/i5/i3 Pentium/Celeron(Comet lake -S)
- Intel Gen9.5,Intel Graphics DX12, OGL4.5
- Support Dual channel DDR4 2666/2933MHz, 2 x So-DIMM up to 32G System Memory
- Socket LGA1200 for Intel core i9/i7/i5/i3 Pentium/Celeron(Comet lake -S 65W)
- 1 x HDMI2.0, 2 x HDMI1.4a, 1 x Dual Channel 24-bits LVDS
- 4 x USB3.0, 4 x USB2.0, 2 x SATA3
- 1 x Mini PCIe/mSATA , 1 x PCIe x16, 1 x M.2 Wifi, 1 x 2280 SSD slot
- Gigabit LAN : 2 x Intel LAN
- 1 x TPM IC(Optional)
- DC in 12/19~24V
- Op temp : 0~60 degree
* Datasheet Download
GA-IMBLAP3455 (rev. 2.0)
- Built-in Intel® Celeron™ J3455 F1 stepping (up to 2.3 GHz) Quad-core processor
- GIGABYTE Ultra Durable™ Technology
- Dual channel DDR3L SO-DIMM slot support
- All Solid Capacitors with Humidity Protection New Glass Fabric PCB design
- Dual GbE LAN with WOL/PXE support and high ESD Protection
- 2 x RS232/422/485, 4 x RS232, Digital I/O 8-in/8-out
- M.2 Socket 3 Key-M for PCIe NVMe or SATA Storage Support
- Mini-PCIe Slot for Full/ Half-Height WIFI Card Support
- LVDS Header for System Integrated Flat Panel Display Support
- Rear Panel HDMI 1.4 & D-sub connectors for Multi-Display Connection
- Amplified Speaker Header Able to Drive Up to 2W System Integrated Speaker
- Thin Mini-ITX 170x170mm Form Factor with 12/19~24V DC-In Power Design
- Compatible with GIGABYTE Thin mini ITX Chassis
GA-IMB1900N (rev. 1.0)
- Intel® Celeron Baytrail SoC Processor
- Integrated Intel® Gen7 Intel Graphics DX 10
- Supports Dual Channel DDR3L 1333MHz, 2 x SO-DIMM, up to 16GB system memory
- 1 x HDMI, 1 x D-Sub, 1 x Dual Channel 24-bit LVDS
- 4 x USB 3.0, 4 x USB 2.0, 2 x SATA2
- 1 x mini-PCIe, 1 x M.2 SSD, 1 x M.2 Wifi slot
- Gigabit LAN : 2 x Intel i211AT Lan
- 1 x TPM Module IC(Optional)
- ATX power require
* Datasheet Download
GA-IMB1900TN (rev. 1.0)
- Intel® Celeron Baytrail SoC Processor
- Integrated Intel® Gen7 Intel Graphics DX 10
- Supports Dual Channel DDR3L 1333MHz, 2 x SO-DIMM, up to 16GB system memory
- 1 x HDMI, 1 x D-Sub, 1 x Dual Channel 24-bit LVDS
- 4 x USB 3.0, 4 x USB 2.0, 2 x SATA3
- 1 x mini-PCIe, 1 x M.2 SSD, 1 x M.2 Wifi slot
- Gigabit LAN : 2 x Intel i211AT Lan
- 1 x TPM Module IC(Optional)
- 12/19~24 V DC-in
* Datasheet Download
GA-H310TN-R2 (rev. 1.0)
- Socket LGA1151 for Intel Core i9/i7/i5/i3/Pentium/Celeron (Coffee lake-S)
- Intel® Gen10 Intel Graphics DX 11/12, OGL4.3/4.4
- Supports Single Channel DDR4 2133/2400MHz, 2 x SO-DIMM, up to 32GB system memory
- 1 x HDMI,1 x DP Port ,1 x Dual Channel 24-bit LVDS
- 4 xUSB 3.0, 2 x USB 2.0, 2 x SATA3
- 1 x M.2 wifi , 1 x M.2 SSD
- Gigabit LAN : 1 x Realtek Lan
- 1 x TPM 2.0 IC onboard
- 19 V DC-in
* Datasheet Download
GA-IMB370TN (rev. 1.0)
- Supports 9th and 8th Generation Intel® Core™ Processors up to 65W
- Dual Channel DDR4 SO-DIMM, 2 DIMMs
- 2 x RS232/422/485, 2 x RS232, Digital I/O 4-in/4-out
- M.2 Socket 1 for PCIe WIFI co-lay with CNVI Hybird E key WIFI
- M.2 Socket 2260/80 Storage support PCIe/SATA Mode
- Mini-PCIe Slot Full size Support mSATA/PCIe mode
- VGA Header for legacy Monitor
- LVDS Header for System Integrated Flat Panel Display Support
- Rear Panel DisplayPort, HDMI 2.0 Ports & D-sub Header for Multi-Display Connection
- Amplified Speaker Header Able to Drive Up to 3W System Integrated Speaker
- Dual Intel® GbE LAN for WOL and PXE Support
- 4 USB 3.0 and 4 USB 2.0 Ports, USB 3.0 support OTG function
- OP: 0~60 degree
- Thin Mini-ITX 170x170mm Form Factor with 12/19~24V DC-In Power Design
- Compatible with GIGABYTE Thin mini ITX Chassis
* Datasheet Download
GA-H310TN (rev. 1.0)
- Socket LGA1151 for Intel Core i9/i7/i5/i3/Pentium/Celeron (Coffee lake-S)
- Intel® Gen10 Intel Graphics DX 11/12, OGL4.3/4.4
- Supports Single Channel DDR4 2133/2400MHz, 1 x SO-DIMM, up to 16GB system memory
- 1 x HDMI, 1 x VGA, 1 x Dual Channel 24-bit LVDS
- 4 x USB 3.0, 4 x USB 2.0, 2 x SATA3
- 1 x M.2 wifi, 1 x M.2 SSD
- Gigabit LAN : 1 x Realtek Lan
- 1 x TPM 2.0 IC onboard
- 19 V DC-in
- Compatible with GIGABYTE Thin mini ITX Chassis
* Datasheet Download
GA-IMB310TN (rev. 1.0)
- Supports 9th and 8th Generation Intel® Core™ Processors up to 65W
- Dual Channel DDR4 SO-DIMM, 2 DIMMs
- 2 x RS232/422/485, 2 x RS232, Digital I/O 4-in/4-out
- M.2 Socket 1 for PCIe WIFI co-lay with CNVI Hybird E key WIFI
- M.2 Socket 2260/80 Storage support PCIe/SATA Mode
- Mini-PCIe Slot Full size Support mSATA/PCIe mode
- VGA Header for legacy Monitor
- LVDS Header for System Integrated Flat Panel Display Support
- Rear Panel DisplayPort, HDMI 2.0 Ports & D-sub Header for Multi-Display Connection
- Amplified Speaker Header Able to Drive Up to 3W System Integrated Speaker
- Dual Intel® GbE LAN for WOL and PXE Support
- 4 USB 3.0 and 4 USB 2.0 Ports, USB 3.0 support OTG function
- OP 0~60 degree
- Thin Mini-ITX 170x170mm Form Factor with 12/19~24V DC-In Power Design
- Compatible with GIGABYTE Thin mini ITX Chassis
* Datasheet Download
GA-IMBLAP3450 (rev. 1.0)
- Built-in Intel® Celeron™ N3450 (up to 2.2 GHz) quad-core processor
- GIGABYTE Ultra Durable™ Technology
- Dual channel DDR3L SO-DIMM slot support
- All Solid Capacitors with Humidity Protection New Glass Fabric PCB design
- Dual GbE LAN with WOL/PXE support and high ESD Protection
- 2 x RS232/422/485, 4 x RS232, Digital I/O 8-in/8-out
- M.2 Socket 3 Key-M for PCIe NVMe or SATA Storage Support
- Mini-PCIe Slot for Full/ Half-Height WIFI Card Support
- LVDS Header for System Integrated Flat Panel Display Support
- Rear Panel HDMI 1.4 & D-sub connectors for Multi-Display Connection
- Amplified Speaker Header Able to Drive Up to 2W System Integrated Speaker
- Thin Mini-ITX 170x170mm Form Factor with 12/19~24V DC-In Power Design
- Compatible with GIGABYTE Thin mini ITX Chassis
* Datasheet Download
GA-IMBLAP3350 (rev. 2.0)
- Built-in Intel® Celeron™ N3350 F1 stepping (up to 2.4 GHz) dual-core processor
- GIGABYTE Ultra Durable™ Technology
- Dual channel DDR3L SO-DIMM slot support
- All Solid Capacitors with Humidity Protection New Glass Fabric PCB design
- Dual GbE LAN with WOL/PXE support and high ESD Protection
- 2 x RS232/422/485, 4 x RS232, Digital I/O 8-in/8-out
- M.2 Socket 3 Key-M for PCIe NVMe or SATA Storage Support
- Mini-PCIe Slot for Full/ Half-Height WIFI Card Support
- LVDS Header for System Integrated Flat Panel Display Support
- Rear Panel HDMI 1.4 & D-sub connectors for Multi-Display Connection
- Amplified Speaker Header Able to Drive Up to 2W System Integrated Speaker
- Thin Mini-ITX 170x170mm Form Factor with 12/19~24V DC-In Power Design
- Compatible with GIGABYTE Thin mini ITX Chassis
* Datasheet Download
GA-H110TN-E (rev. 1.0)
- Supports 6th Generation Intel® Core™ Processor
- Dual Channel DDR4 SO-DIMM, 2 DIMMs
- Mini-PCIe Slot for Full/ Half-Height WIFI Card Support
- Mini-PCIe Dual Purpose Slot for mSATA SSD Support
- LVDS Header for System Integrated Flat Panel Display Support
- Rear Panel DisplayPort, HDMI 1.4 Ports for Multi-Display Connection
- Amplified Speaker Header Able to Drive Up to 3W System Integrated Speaker
- Intel® GbE LAN for WOL and PXE Support
- Features 4 USB 3.0 and 4 USB 2.0 Ports
- GIGABYTE UEFI DualBIOS™ Technology
- Thin Mini-ITX 170x170mm Form Factor with 12/19~24V DC-In Power Design
GA-H110TN-M (rev. 1.0)
- Supports 6th Generation Intel® Core™ Processor
- Dual Channel DDR4 SO-DIMM, 2 DIMMs
- 2 x RS232/422/485, Digital I/O 4-in/4-out
- Mini-PCIe Slot for Full/ Half-Height WIFI Card Support
- Mini-PCIe Dual Purpose Slot for mSATA SSD Support
- LVDS Header for System Integrated Flat Panel Display Support
- Rear Panel DisplayPort, HDMI 1.4 Ports & D-sub Header for Multi-Display Connection
- Amplified Speaker Header Able to Drive Up to 3W System Integrated Speaker
- Intel® GbE LAN for WOL and PXE Support
- Features 4 USB 3.0 and 4 USB 2.0 Ports
- GIGABYTE UEFI DualBIOS™ Technology
- Thin Mini-ITX 170x170mm Form Factor with 12/19~24V DC-In Power Design
