GA-MA770-S3 (rev. 2.0)

GA-MA78LM-S2 offers high performance platform based on AMD 760G chipset, it is integrated ATI Radeon HD 3000 (DX10) graphics engine and supports AMD AM3 Phenom II/ Phenom/ Athlon processors, HyperTransport™ 3.0 technology links, DDR2 memory, PCI Express 2.0 graphics interface and so on. With the innovative GIGABYTE Easy Energy Saver technology, GA-MA78LM-S2 is able to provide user friendly computing, reach the maximum system performance easily while still able to save the power and environment in real life at the same time.

이 모델은 Split Power Plane 기술이 적용되었고 4+1 페이즈 VRM 설계로 차세대 45nm AMD AM3 Phenom™II 시리즈 프로세서를 지원하여 시스템 성능이 크게 제고되고 하드웨어의 확장성이 더욱 확대되었다.

Stable system operation depends upon the quality of CPU VRM (voltage regulator module). GIGABYTE adopts Conductive Polymer Aluminum Solid Capacitors for CPU VRM to ensure a longer lifespan for systems in daily operation and boost system stability under extreme conditions. CPU VRM with Solid Capacitors featuring better electronic conductivity, excellent heat resistance enhances system durability even operating in high temperature environment.

AMD OverDrive™는 AMD사가 하이엔드 사용자를 위해 개발한 오버클럭 소프트웨어로서, AMD CPU, socket 및 칩셋에 대한 시스템의 튜닝을 편하게 해준다.
* AMD OverDrive™ 드라이버의 다운로드는 AMD의 공식 사이트를 참조한다: http://game.amd.com/us-en/drivers_overdrive.aspx
** 이 소프트웨어의 지원은 제품모델(칩셋)에 따라 다를 수 있다.

AMD Live Ready Requirement compliant.

Windows Vista Premium promises to deliver a streamlined computing experience designed to fundamentally change how users view, find and organize their digital information. With GIGABYTE AM2+/ AM2 solutions enabling support for Vista Premium, GIGABYTE offers a fresh and unique desktop experience that will be more informative, intuitive and completely new....more

The leading-edge performance and unparallel technology of AMD AM2+ Phenom™ processors have built its strength on the well-known AMD64 framework which consisted next generation of HyperTransport 3.0 Technology, and integrated DDR2 1066 memory controller, and 128-bit Floating Point Units. The AMD Phenom™ processors are an ideal choice for multi-media enthusiasts and intensive multi-tasking environments to offer significant performance boosts and provides an overall more energy efficient platform.

The AMD 770 Chipset is the system logic of the latest AM2+ (HyperTransport 3.0) platform from AMD that enables its next generation Phenom™ processors. The AMD 770 Chipset, with optimized next generation of PCI-E 2.0 graphics capabilities, providing outstanding quality and performance for every PC users. Confidently manage and back-up precious digital files, surf the Internet faster, and play the latest games with technology designed today and ready for tomorrow.

Experience the advanced technology of DDR2 1066* memory, featuring faster speeds and higher data bandwidth, which delivers superior performance for the most demanding applications.
* DDR2 1066 is supported with combination of AM2+ processors and DDR2 1066 memory modules, please refer "Memory Support List" for detail memory support information.

PCI-E 2.0 doubles the bus standard's bandwidth from 2.5 Gbit/s to 5 Gbit/s, meaning a x32 connector can transfer data at up to 16 GB/s in each direction. PCI-E 2.0 also features improvements to the point-to-point data transfer protocol and its software architecture.

SATA 3Gb/s저장 인터페이스의 전송폭이 초당1.5Gb에서 초당3Gb로 향상되었다. SATA 3Gb/s는 SATA속도를 두배로 향상시켰고 또한 훨씬 전송폭의 활용이 효율적이고 데이터 백업 및 저장 능력이 강화되었다.

This motherboard with IEEE1394 FireWire interface from Texas Instruments (TI). With the transfer speed up to 400Mb/s, the new generation IEEE1394 interface further enhances PC connectivity with consumer electronics audio/video.

Experience home theater-quality sound with your PC using High Definition Audio for enhanced 6/ 8-channel* audio, improved voice and communication input, and multi-streaming capability.
* To use 8-channel HD audio, please use the system case with HD audio front panel featured and see manual for detail configuration.

기가바이트(Gigabit)LAN은 기존의 초고속 네트워크를 제공하여 연결 대역폭을 최고 1,000 Mbps까지 지원하고 광대역을 제공할 때 네트워크 연결을 최적화해준다. 또한 네트워크를 연결할 때 사용자가 동영상 또는 음악을 제공하는 홈페이지를 브라우징해도 막히거나 끊김 현상이 전혀 없다.

The Speed compliant motherboards of GIGABYTE S-series provide intelligent over-clocking and over-voltage software settings through both hardware and software design...more

The Smart featured motherboards of GIGABYTE S-series provide GIGABYTE proprietary innovative software such as Download Center, @BIOS, Q-Flash, Xpress Install, Boot menu, and Smart Fan. BIOS and driver management now becomes much easier and user friendly through GIGABYTE Smart features!...more

Safe is the key feature of GIGABYTE S-series motherboards with the following elements: Excellent hardware design reinforced BIOS protection through GIGABYTE Virtual Dual BIOS Technology and GIGABYTE BIOS Setting Recovery Technology. Unique system software such as Xpress Recovery 2, PC Health Monitor, HDD S.M.A.R.T., and C.O.M. further strengthen the stability and reliability of your PC!...more
