R292-4S1

4-Way Rack Server - 3rd Gen Intel® Xeon® Scalable - 2U QP 10-Bay Gen3 NVMe/SATA/SAS
  • Quad 3rd Gen Intel® Xeon® Scalable Processors
  • 6-Channel DDR4 RDIMM/LRDIMM, 48 x DIMMs
  • Supports Intel® Optane™ Persistent Memory 200 series
  • 2 x 10Gb/s LAN ports via Intel® X710-AT2
  • 10 x 2.5" Gen3 NVMe/SAS/SATA hot-swappable bays
  • 1 x M.2 slot with PCIe Gen3 x2 interface
  • 8 x FHFL PCIe Gen3 x16 slots
  • 1 x OCP 3.0 Gen3 x16 slot on the front side
  • 1+1 3200W 80 PLUS Platinum redundant power supplies
Get a Quote
* 사이트에서 제공되는 모든 자료는 참조용일 뿐입니다. 기가바이트는 사이트의 자료를 사전 통지없이 언제든지 수정할 권리를 지닙니다.
* 모든 상표와 로고는 해당 소유자의 자산입니다.
* PC의 표준 아키텍쳐에 의해, 메모리의 특정 부분이 시스템에 사용되어 실제 메모리 크기는 표준보다 적게 표시될 수 있습니다.

SPECIFICATIONS

Dimensions (WxHxD, mm)
2U
438 x 87.5 x 858
Motherboard
MRQ2-4S0
CPU
3rd Generation Intel® Xeon® Scalable Processors
Intel® Xeon® Platinum 8300 Processors
Intel® Xeon® Gold 6300 Processors
6 UPI Links per processor
Quad processor, TDP up to 250W
Socket
4 x LGA 4189
Socket P5
Chipset
Intel® C621A
Memory
Total 48 x DIMM slots
DDR4 memory supported only
6-channel memory architecture
RDIMM up to 128GB supported
LRDIMM up to 128GB supported
Supports Intel® Optane™ Persistent Memory 200 series
1.2V modules: 3200 (1DPC)/2933 (2DPC) MT/s
LAN
Rear side:
2 x 10Gb/s LAN ports (1 x Intel® X710-AT2)
Support NCSI function

1 x 10/100/1000 Mbps Management LAN
Video
Integrated in Aspeed® AST2500
- 1 x VGA port
Storage
Front side:
10 x 2.5" Gen3 NVMe/SAS/SATA hot-swappable bays

SAS card is required for SAS devices support
SATA
Supported
SAS
Depends on SAS add-in cards
RAID
Intel® SATA RAID 0/1/10/5
Expansion Slots
Riser Card CRS202A:
- 1 x PCIe x16 (Gen3 x16) FHFL slot, from CPU_0
- 1 x PCIe x16 (Gen3 x16) FHFL slot, from CPU_1

Riser Card CRS2040:
- 1 x PCIe x16 (Gen3 x16) FHFL slot, from CPU_0
- 1 x PCIe x16 (Gen3 x16) FHFL slot, from CPU_1
- 1 x PCIe x16 (Gen3 x16) FHFL slot, from CPU_2
- 1 x PCIe x16 (Gen3 x16) FHFL slot, from CPU_3

Riser Card CRS2029:
- 1 x PCIe x16 (Gen3 x16) FHFL slot, from CPU_2
- 1 x PCIe x16 (Gen3 x16) FHFL slot, from CPU_3

1 x OCP 3.0 slot with PCIe Gen3 x16 bandwidth (Supports OCP 3.0 SFF standard), from CPU_1

1 x M.2 slot:
- M-key
- PCIe Gen3 x2, from PCH
- Supports 2280 cards
Internal I/O
1 x TPM header
1 x VROC connector
Front I/O
2 x USB 3.0
1 x Power button with LED
1 x ID button with LED
1 x NMI button
1 x Reset button
2 x LAN activity LEDs
1 x Storage activity LED
1 x System status LED
Rear I/O
2 x USB 3.0
1 x VGA
1 x COM
2 x RJ45
1 x MLAN
1 x ID button with LED
Backplane Board
Speed and bandwidth:
PCIe Gen3 x4 or SATA 6Gb/s or SAS 12Gb/s
TPM
1 x TPM header with SPI interface
- Optional TPM2.0 kit: CTM010
Power Supply
1+1 3200W 80 PLUS Platinum redundant power supplies

AC Input:
- 100-127V~/ 14A, 50/60Hz
- 200-208V~/ 16A, 50/60Hz
- 214-234V~/ 16A, 50/60Hz
- 240V~/ 16A, 50/60Hz

DC Input: (Only for China)
- 240Vdc/ 16A

DC Output:
- Max 1106W/ 100-127V~
+12.3V/ 87A
+12Vsb/ 3A
- Max 2434W/ 200-208V~
+12.3V/ 195A
+12Vsb/ 3A
- Max 2828W/ 214-234V~
+12.3V/ 227A
+12Vsb/ 3A
- Max 3234W/ 240V~ or 240Vdc Input
+12.3V/ 260A
+12Vsb/ 3A

Note: The system power supply requires C19 power cord.
System Management
Aspeed® AST2500 Baseboard Management Controller
Avocent® MergePoint IPMI 2.0 web interface:

  • Network settings
  • Network security settings
  • Hardware information
  • Users control
  • Services settings
  • IPMI settings
  • Sessions control
  • LDAP settings
  • Power control
  • Fan profiles
  • Voltages, fans and temperatures monitoring
  • System event log
  • Events management (platform events, trap settings, email settings)
  • Serial Over LAN
  • vKVM & vMedia (HTML5)
OS Compatibility
Citrix Hypervisor 8.2.0 or later

Red Hat Enterprise Linux 7.9 or later
Red Hat Enterprise Linux 8.2 or later
Red Hat Enterprise Linux 9.0 or later

SUSE Linux Enterprise Server 12 SP5 or later
SUSE Linux Enterprise Server 15 SP2 or later
SUSE Linux Enterprise Server 15 SP3

Ubuntu 20.04 LTS or later
Ubuntu 22.04 LTS or later

VMware ESXi 7.0 U1 or later
VMware ESXi 8.0 or later

Windows Server 2016
Windows Server 2019
Windows Server 2022
System Fans
16 x 40x40x56mm (29,000rpm)
Operating Properties
Operating temperature: 10°C to 35°C
Operating humidity: 8-80% (non-condensing)
Non-operating temperature: -40°C to 60°C
Non-operating humidity: 20%-95% (non-condensing)
Packaging Dimensions
1177 x 670 x 291 mm
Packaging Content
1 x R292-4S1
4 x CPU heatsinks
1 x 2-Section Rail kit
Part Numbers
- Barebone package: 6NR2924S1MR-00-1*
- Motherboard: 9MRQ24S0NR-00
- 2-Section Rail kit (CMA not supported): 25HB2-3A0202-K0R
- CPU heatsink: 25ST1-243104-C1R
- M.2 heatsink: 12SP2-080027-00R
- Front panel board - CFP2001: 9CFP2001NR-00
- Backplane board - CBP10A5: 9CBP10A5NR-00
- Fan module: 25ST2-405624-A0R
- Fan module: 25ST2-405625-A0R
- Fan module: 25ST2-405626-A0R
- Fan module: 25ST2-405627-A0R
- Riser card - CRS202A: 9CRS202ANR-00
- Riser card - CRS2040: 9CRS2040NR-00
- Riser card - CRS2029: 9CRS2029NR-00
- Power supply: 25EP0-232002-D0S

Optional parts:

- 3-Section Rail kit (Supports CMA): 25HB2-AA6105-K0R
- Cable Management Arm: 25HB1-R18300-K0R
