• Elegant design with enhanced computing power
  • 13th Gen Intel® Core™ i3-1315U Processor
  • Intel® Iris® Xe Graphics , 96EU, 1.25GHz
  • Super Fast 2.5G LAN + Wi-Fi 6 Module
  • 4 x 4K Module - 2 x HDMI 2.1 and 2 x USB Type C with DP alt mode
  • 2 x USB 3.2 Gen2 , 2 x USB 2.0 Ports
  • Low Noise
  • VESA Support


    * Barebone products do not include the operating system.
    * Product may vary based on local distribution.
    * Wireless module inclusion may vary based on local distribution.

Elegant design with enhanced computing power

Upgrade to the future
Minimalism meets power

The most recent generation of mainstream BRIX products adopts an all-new chassis design. Computing performance has increased, but the design does not require an increase in the size of the chassis. Its appearance has curved, soft, and twisted lines with a liveliness that makes it very unobtrusive.

By the way it was assembled and layered, and designing oblique angles around the base, a sense of simplicity is created to achieve a lightweight design. This allows users to enjoy ultimate computing performance while also having a stylish and elegant product.

GIGABYTE BRIX™s with Intel® Core™ Processors - Uncompromised Performance

With 13th Gen Intel® Core™ Processors, Intel advanced its hybrid design and made it even better than our previous product with 10th Gen Intel® Processors. Faster Performance-cores means getting dedicated tasks done faster and easier. More Efficiency-cores means better multi-tasking.Great on-board graphics and best-in-class connectivity means a fully immersive experience and ultra-responsive wired and wireless connections.

Cinebech R23

GB-BRi7H-1355

(Intel® i7-1355U)

GB-BRi7H-10710

(Intel® i7-10710U)

Multi-threaded

+ 88% faster

7679
4079

Single-threaded

+ 120% faster

1897
863

3DMark

140% higher score

GB-BRi7H-1355

(Intel® i7-1355U)

15891

GB-BRi7H-10710

(Intel® i7-10710U)

6590

Sisoftware Sandra

40% + UP

GB-BRi7H-1355

(Intel® i7-1355U)

171.44

GB-BRi7H-10710

(Intel® i7-10710U)

142.84

Superior Low Noise

Thanks to the enhanced thermal and firmware designs, we can now present the updated 2023 BRIX as one of the lowest-noise mini PCs on the market. There are three levels of power plan settings in the BIOS (quiet, standard, and performance). Users can find a noise level suitable for all applications. In standby mode, the noise generated is 20 dB, and at 100% CPU load, 40 dB.

Noise Level

Idle/Standby (12W)

20 20dB = Calm breath

Heavy Load (15W)

30 30dB = A quiet room or whisper

13th Gen Intel® Core™ Mobile Processors

Increasing performance gets more done

With the latest 13th Gen Intel® Core™ Mobile Processors, Intel has taken its hybrid design to the next level. The new processors boast more powerful Performance-cores (P-cores), allowing for swift and seamless completion of tasks. The improved Efficient-cores (E-cores) enable even better multi-tasking, making it easier to tackle several tasks at once. These advanced processors also deliver stunning graphics and unparalleled connectivity, providing an unparalleled immersive display and lightning-fast wired and wireless connections.

Computing with ultra efficient multi-tasking

Up to 10 cores (2 P-cores, 8 E-cores) and enhanced Intel Thread Director.

Intel® Iris® Xᵉ Graphics

Render in the background while editing video; enjoy responsive HD gaming while streaming music; or game, stream and record at once.

Amazing End-to-End Connectivity with Wi-Fi 6

Nearly a threefold improvement in throughput speed allows for fast uploads and downloads at low latency. Intel® Wi-Fi 6 (Gig+) gives you the freedom to work and learn from anywhere—and relax with smooth, high-quality streaming.

Connecting the Future

Clean

(Current Modularized Chassis)

Untidy

(The Previous Chassis)

USB Type-C Connector

The USB Type-C™ is a new reversible connector that comes with a variety of excellent features, including support for USB 3.2 Gen 2x1, which provides transfer speeds of up to 10 Gb/s.

Version

USB 2.0

USB 3.0

USB 3.2 Gen2

Transfer Speeds

480 Mbps

5 Gbps

10 Gbps

HD Movie 25GB

~ 14 mins

~ 70 sec

~ 30 sec

Support HDMI 2.1 / DP 1.4 Dual Output

HDMI 2.1 offers 18 Gb/s of bandwidth, which is nearly twice that of the previous generation, and it is also backward compatible with HDMI 1.4.

HDMI 2.1

77% More Bandwidth

18Gb/s

HDMI 1.4

10.2Gb/s

Quad-Display Support (4x4K)

Easily connect to your dream set-up with support for multiple 4K displays and keep your peripheral suite organized with HDMI and Type C USB.

4 x 4K Outputs

The GIGABYTE BRIX with 13th Gen Intel® Core™ Mobile Processors supports up to 4 independent displays with 4K resolution and HDR 10 support, through its HDMI and mini Display ports. This gives users the flexibility to configure their environment without any limitations.

Native Cinematic 21:9 Ratio

This unlocks the potential for users to transfer multiple video streams, as well as offering a native cinematic 21:9 ratio (in which most movies are shot), providing the best visual experience for viewers.

DDR4 3200MHz Support

GIGABYTE BRIX provides a 128-bit memory controller that supports DDR4 at 3200 MHz. DDR4 is a type of synchronous dynamic random-access memory with a double data rate and a high bandwidth interface. DDR4's primary advantages over its predecessor, DDR3, include higher module density and lower voltage requirements, coupled with increased data rate transfer speeds.

New Intel 7 Processor

10% Faster

3200MHz

Intel 10nm Processor

2933MHz

Intel 2nd Generation 14nm Processor

2400MHz

VESA Support

With a VESA-ready design, the GIGABYTE BRIX™ can easily be mounted behind a monitor or HDTV. This offers a simple and effective way to turn any VESA-compliant display or TV into a full-featured PC or digital signage unit.

The VESA-ready design of the GIGABYTE BRIX™ allows users to easily mount it behind a monitor or HDTV, offering a simple and effective way to turn any VESA-compliant display or TV into a full-featured PC or digital signage unit.

System Overview

Delivering Superior Performance Where You Need It Most

You can save time and enhance the quality of your computing experience by utilizing built-in intelligence. Enjoy features like low noise operation while collaborating and automated text, image, and audio improvements while creating. In addition, enjoy system optimization for bandwidth and video resolution while gaming on the go.

  • The Perfect Compact Home PC
  • Living room
  • Bedroom
  • Kitchen
  • Study
  • Vertical Markets
  • School
  • University computer labs
  • Libraries
  • Hospital / Medical equipment
  • Governmental
  • Vertical Markets
  • School
  • University computer labs
  • Libraries
  • Hospital / Medical equipment
  • Governmental
  • Powerful Commercial Applications
  • Factory testing machine
  • Bank ATM system
  • Gaming equipment
  • Vending machine
  • Security system
  • At the Office
  • Meeting room device
  • Workstation
  • Studio
  • Freelance office space
  • Simpler and Smarter Digital Life
  • Shopping mall signboard
  • Scoreboard system
  • Split-flap display
  • Indoor / Outdoor LED Display
  • Face perception

The BIOS of GIGABYTE BRIX Mini PC Features TPM 2.0 Function to Support Windows 11 Upgrade

GIGABYTE BRIX Mini-PCs

The Perfect Solution for Windows 11 TPM 2.0 Support

Windows 11 is the latest operating system from Microsoft®, featuring dozens of exciting new functions and Android app support that effectively improve productivity, system security, and gaming performance. However, many users may be confused about whether they need TPM 2.0 support to upgrade to Windows 11. In fact, TPM 2.0 hardware is not a requirement to pass TPM 2.0 verification. GIGABYTE BRIX™ mini-PCs are not only known for our world-renowned durability but also for our leading role in product design, especially when it comes to TPM 2.0 support in the BIOS. Many GIGABYTE Intel® and AMD BRIX™ Mini PCs can pass TPM 2.0 verification for Windows 11 simply by enabling the TPM-related function in the BIOS. Intel-based chipset (12th /11th/10th Gen Core i processor) and above platforms will feature firmware-based fTPM function, while AMD models will load with a hardware TPM chip. With this advanced BIOS setting, GIGABYTE BRIX™ mini-PCs can pass TPM 2.0 verification for Windows 11, preventing TPM 2.0 support from becoming an issue for users during system upgrades.

The BIOS of GIGABYTE BRIX Mini PC Features TPM 2.0 Function to Support Windows 11 Upgrade

GIGABYTE BRIX Mini-PCs

The Perfect Solution for Windows 11 TPM 2.0 Support

Windows 11 is the latest operating system from Microsoft®, featuring dozens of exciting new functions and Android app support that effectively improve productivity, system security, and gaming performance. However, many users may be confused about whether they need TPM 2.0 support to upgrade to Windows 11. In fact, TPM 2.0 hardware is not a requirement to pass TPM 2.0 verification. GIGABYTE BRIX™ mini-PCs are not only known for our world-renowned durability but also for our leading role in product design, especially when it comes to TPM 2.0 support in the BIOS. Many GIGABYTE Intel® and AMD BRIX™ Mini PCs can pass TPM 2.0 verification for Windows 11 simply by enabling the TPM-related function in the BIOS. Intel-based chipset (12th /11th/10th Gen Core i processor) and above platforms will feature firmware-based fTPM function, while AMD models will load with a hardware TPM chip. With this advanced BIOS setting, GIGABYTE BRIX™ mini-PCs can pass TPM 2.0 verification for Windows 11, preventing TPM 2.0 support from becoming an issue for users during system upgrades.
