XV24-AX0-AAJ1

NVIDIA MGX™ Server - Intel^® Xeon^® 6 Processors - 2U DP 4 x PCIe Gen5 GPUs

# AI # AI Training # AI Inference # Visual Computing # HPC

Supports up to 4 x Dual slot Gen5 GPUs
NVIDIA MGX™ modular server design
Dual Intel^® Xeon^® 6 Processors, LGA 7529
12-Channel DDR5 RDIMM / MRDIMM, 24 x DIMMs
Dual ROM Architecture
2 x 10Gb/s LAN ports via Intel^® X550-AT2
6 x 2.5" Gen5 NVMe/SATA/SAS-4 hot-swap bays
2 x M.2 slots with PCIe Gen5 x2 interface
4 x FHFL PCIe Gen5 x16 slots for GPUs
3 x FHFL PCIe Gen5 x16 slots
4 x 2000W 80 PLUS Titanium redundant power supply

Get a Quote

比較リストに追加

Get a Quote

* ここに記載されている全ての資料は参考用です。 GIGABYTEは、予告なしに変更する場合があります。
* パフォーマンスについては、インターフェイス仕様の理論上の最大値に基づいています。実際のパフォーマンスは、システム構成によって異なる場合があります。
* 記載されている会社名、商品名、およびロゴは各社の商標または登録商標です。
* メモリー容量は、システムリソースに予約され実際の搭載メモリーより少なくなる場合があります。

SPECIFICATIONS

Dimensions (WxHxD, mm)

2U
438 x 87 x 900

Motherboard

MAX4-MG0

CPU

Intel^® Xeon^® 6 Processors
- Intel^® Xeon^® 6900-Series Processors

Dual processor, TDP up to 500W

^[Note]If only 1 CPU is installed, some PCIe or memory functions might be unavailable.

Socket

2 x LGA 7529
Socket BR

Chipset

System on Chip

Memory

24 x DIMM slots
DDR5 memory supported
12-Channel memory architecture
MRDIMM supported^[1]
RDIMM: Up to 6400 MT/s
MRDIMM: Up to 8800 MT/s

^[1]MRDIMMs are only supported with Intel^® Xeon^® 6 Processors with P-cores.

LAN

Rear (I/O board - CFPX141):
2 x 10Gb/s LAN (1 x Intel^® X550-AT2)
- Support NCSI function

1 x 10/100/1000 Mbps Management LAN

Video

Integrated in Aspeed^® AST2600
- 1 x Mini-DP

Storage

Front hot-swap:
6 x 2.5" Gen5 NVMe/SATA/SAS-4^[1]
- (4 x NVMe from CPU_0, 2 x NVMe from CPU_1)

Internal M.2 (I/O board - CFPX141):
2 x M.2 (2280/22110), PCIe Gen5 x2, from CPU_0

^[1]Storage card is required to support SATA and SAS drives.

SAS

N/A

RAID

Require RAID add-in cards
Onboard VROC key header

PCIe Expansion Slots

PCIe Cable x 7:
- 2 x FHFL x16 (Gen5 x16), from CPU_0, for GPUs
- 2 x FHFL x16 (Gen5 x16), from CPU_1, for GPUs
- 2 x FHFL x16 (Gen5 x16), from CPU_0
- 1 x FHFL x16 (Gen5 x16), from CPU_1

Front I/O

2 x USB 3.2 Gen1 ports (Type-A)
1 x Power button with LED
1 x ID button with LED
1 x NMI button
1 x Reset button
1 x Storage activity LED
1 x System status LED

Rear I/O

I/O board - CFPX141:
2 x USB 3.2 Gen1 ports (Type-A)
1 x Mini-DP
2 x RJ45 ports
1 x MLAN port
1 x ID LED

Backplane Board

Speed and bandwidth:
PCIe Gen5 x4 or SATA 6Gb/s or SAS-4 24Gb/s

Security Modules

1 x TPM header with SPI interface
- Optional TPM2.0 kit: CTM012

1 x PRoT connector (only enabled on RoT SKU)

Power Supply

4 x 2000W 80 PLUS Titanium redundant power supply

AC Input:
- 100-127V~/ 13A, 50-60Hz
- 200-220V~/ 10A, 50-60Hz
- 220-240V~/ 10A, 50-60Hz

DC Input: (Only for China)
- 240Vdc/ 10A

DC Output:
- Max 1000W/ 100-127V~
+12.2V/ 82A
+12.2Vsb/ 3A
- Max 1800W/ 200-220V~
+12.2V/ 148A
+12.2Vsb/ 3A
- Max 2000W/ 220-240V~ or 240Vdc Input
+12.2V/ 164A
+12.2Vsb/ 3A

System Management

Aspeed^® AST2600 Baseboard Management Controller
GIGABYTE Management Console web interface

Dashboard
HTML5 KVM
Sensor Monitor (Voltage, RPM, Temperature, CPU Status …etc.)
Sensor Reading History Data
FRU Information
SEL Log in Linear Storage / Circular Storage Policy
Hardware Inventory
Fan Profile
System Firewall
Power Consumption
Power Control
Advanced power capping
LDAP / AD / RADIUS Support
Backup & Restore Configuration
Remote BIOS/BMC/CPLD Update
Event Log Filter
User Management
Media Redirection Settings
PAM Order Settings
SSL Settings
SMTP Settings

OS Compatibility

Please refer to OS compatibility table in support page

System Fans

4 x 80x80x80mm (15,000rpm)

Operating Properties

Operating temperature: 10°C to 35°C
Operating humidity: 8%-80% (non-condensing)
Non-operating temperature: -40°C to 60°C
Non-operating humidity: 20%-95% (non-condensing)

Packaging Dimensions

TBD

Packaging Content

1 x XV24-AX0-AAJ1
2 x CPU heatsinks
1 x Mini-DP to D-Sub cable
1 x GPU power cable (12VHPWR, 450mm)
2 x GPU power cables (12VHPWR, 620mm)
1 x GPU power cable (12VHPWR, 750mm)
2 x Carriers
1 x 2-Section Rail kit (TBD)

Part Numbers

- Barebone package: 6NXV24AX0DR000AAJ1*
- Motherboard: 9MAX4MG0UR-000*
- 2-Section Rail kit (CMA not supported): TBD
- CPU heatsink: TBD
- Front panel board - CFP1010: 9CFP1010NR-00*
- Backplane board - CBPX060: 9CBPX060NR-00*
- Fan module: 25ST2-888024-D0R
- I/O board with M.2 slots - CFPX141: 9CFPX141NR-00*
- DC-SCM board (A)+(B):
A) CDCX101: 9CDCX101NR-00*
B) CSC402: 9CSC402NR-00*
- Mini-DP to D-Sub cable: 25CRN-200801-K1R
- GPU power cable (12VHPWR, 450mm): 25CRI-4500B0-Y4R
- GPU power cable (12VHPWR, 620mm): 25CRI-6200B0-Y4R
- GPU power cable (12VHPWR, 750mm): 25CRI-7500B0-Y4R
- Power supply: 25EP0-22000P-G1S

Optional parts:

- 3-Section Rail kit (Supports CMA): 25HB2-T76100-K0R
- Cable Management Arm: 25HB2-2AA700-K0R
