Intel Z390 UD Motherboard with 8*+1 Digital PWM Design, 2-Way CrossFire™ Multi-Graphics, GIGABYTE GAMING LAN, Smart Fan 5, PCIe Gen3 X4 M.2, PCIe X16 Slot Armor with Ultra Durable™ Design, CEC 2019

  • Supports 9th and 8th Gen Intel® Core™ Processors
  • Dual Channel Non-ECC Unbuffered DDR4, 4 DIMMs
  • New 8*+1 Phases Digital PWM Design
  • NVMe PCIe Gen3 x4 22110 M.2 Connector
  • Multi-Way Graphics Support with PCIe Armor and Ultra Durable™ Design
  • GIGABYTE Exclusive 8118 Gaming LAN with Bandwidth Management
  • Support RGB Light Strip in Full Colors
  • CEC 2019 Ready, Save Power With a Simple Click
  • Smart Fan 5 features Multiple Temperature Sensors and Hybrid Fan Headers with FAN STOP
  • Lightning-Fast Intel® Thunderbolt™ 3 AIC Support
  • Intel® Optane™ Memory Ready
