MC62-G40

Rev. 1.x

Motherboard - AMD Ryzen™ Threadripper™ PRO 5000/3000 WX-Series - CEB UP

Single AMD Ryzen™ Threadripper™ PRO 5000/3000 WX-Series Processors
8-Channel UDIMM/RDIMM/LRDIMM DDR4, 8 x DIMMs
2 x 10Gb/s LAN ports via Intel^® X550-AT2
1 x 1Gb/s LAN port via Intel^® I210-AT
3 x SlimSAS connectors with PCIe Gen4 x4 or SATA interface
4 x SATA 6Gb/s ports
2 x M.2 slots with PCIe Gen4 x4 or SATA interface
1 x M.2 slot for Wi-Fi add-in cards
7 x PCIe Gen4 x16 and x8 expansion slots

Get a Quote

Perbandingan

Get a Quote

* Semua bahan yang tersedia disini adalah hanya untuk referensi. GIGABYTE berhak merubah atau merevisi isi sewaktu-waktu tanpa pemberitahuan terlebih dahulu.
* Semua logo dan merek dagang adalah hak cipta dari masing-masing pemegangnya.
* Sehubungan dengan rancangan standar PC, sebagian jumlah memori dicadangkan untuk penggunaan sistem sehingga ukuran memori yang sesungguhnya lebih kecil dari yang disebutkan.

SPECIFICATIONS

Form Factor

CEB
305W x 267D mm

CPU

AMD Ryzen™ Threadripper™ PRO 5000 WX-Series Processors
AMD Ryzen™ Threadripper™ PRO 3000 WX-Series Processors
Up to 64 cores, 128 threads
TDP up to 280W

Socket

1 x sWRX8

Chipset

AMD WRX80

Memory

8 x DIMM slots
DDR4 memory supported only
8-channel memory architecture
ECC UDIMM supported
Total capacity up to 2TB (256GB LRDIMM)
Memory speed: 3200/2933/2666/2400/2133 MT/s

Note: When installing memory modules, make sure to begin with the first socket of each channel, such as DIMM_P0_A0, DIMM_P0_B0, DIMM_P0_C0, DIMM_P0_D0.

LAN

2 x 10Gb/s LAN ports (Intel^® X550-AT2)
1 x 1Gb/s LAN port (Intel^® I210-AT)
Supports NCSI function on Intel^® I210-AT

1 x 10/100/1000 Mbps Management LAN

Video

Integrated in Aspeed^® AST2600
2D Video Graphic Adapter with PCIe bus interface
1920x1200@60Hz 32bpp

Audio

Realtek^® ALC4080 HD Audio Codec
Supports 7.1 channel configuration
3 x Audio Jacks (Audio in/Audio out/Mic)

Storage Interface

CPU:
- 1 x SlimSAS connector (PCIe Gen4 x4 or SATA)

FCH:
- 2 x SlimSAS connectors (PCIe Gen4 x4 or SATA)
- 4 x SATA 6Gb/s ports

RAID

RAID 0/1/5/10

Expansion Slots

Slot_7: PCIe x16 (Gen4 x16) slot
Slot_6: PCIe x16 (Gen4 x16) slot
Slot_5: PCIe x16 (Gen4 x16) slot
Slot_4: PCIe x16 (Gen4 x16) slot
Slot_3: PCIe x16 (Gen4 x16) slot
Slot_2: PCIe x16 (Gen4 x8) slot
Slot_1: PCIe x16 (Gen4 x16) slot

2 x M.2 slots for storage:
- M-key
- PCIe Gen4 x4 or SATA, from CPU
- Support 2242/2280 cards

1 x M.2 slot for Wi-Fi:
- E-key
- Supports 2230 cards

Internal I/O

1 x 24-pin ATX main power connector
2 x 8-pin ATX 12V power connectors
1 x CPU fan header
1 x FCH fan header
8 x System fan headers
2 x USB 3.2 Gen1 x2 headers
2 x M.2 slots for storage
1 x M.2 slot for Wi-Fi
3 x SlimSAS connectors
4 x SATA connectors
1 x Front panel header
1 x Backplane board header
1 x COM header
1 x PMBus header
1 x IPMB header
1 x TPM header

Rear I/O

1 x USB 3.2 Gen2x1 (Type-C)(FCH)
4 x USB 3.2 Gen2x1 (Type-A)(CPU)
1 x USB 3.2 Gen2x1 (Type-A)(FCH)
1 x VGA
2 x RJ45 (10Gb/s)
1 x RJ45 (1Gb/s)
1 x MLAN
3 x Audio jacks
1 x ID button with LED

TPM

1 x TPM header with SPI interface
Optional TPM2.0 kit: CTM010

OS Supported

Red Hat Enterprise Linux 8.2 (x64)
Red Hat Enterprise Linux 8.3 (x64)

Ubuntu 20.04 LTS (x64)

Windows 10 (x64)
Windows 11 (x64)

Board Management

ASPEED^® AST2600

PSU Connectors

1 x 24-pin ATX main power connector
2 x 8-pin ATX 12V power connectors

Operating Properties

Operating temperature: 10°C to 40°C
Operating humidity: 8-80% (non-condensing)
Non-operating temperature: -40°C to 60°C
Non-operating humidity: 20%-95% (non-condensing)

Retail Packaging Content

1 x MC62-G40
1 x I/O shield
1 x Quick start guide
1 x SlimSAS to 4 x SATA 6Gb/s cable (600mm)
4 x SATA 6Gb/s cables (500mm)

Single Box dimensions: 360 x 330 x 80 mm
Carton dimensions: 674 x 424 x 385 mm
Quantity: 10 x single boxes in one carton

Bulk Packaging Content

10 x MC62-G40
10 x I/O shields

Carton dimensions: 600 x 473 x 495 mm

Reference Numbers

Retail: 9MC62G40MR-00-1*
Bulk: 9MC62G40NR-00-1*

Part Numbers:

- I/O shield: 12AIO-MC62G4-00R
- SlimSAS to 4 x SATA cable (600mm): 25CFM-600700-A4R
- SATA cable (500mm)(2 in 1 package): 12CF1-2SAT01-31R

Optional parts:

- CPU fansink (A)+(B)+(C):
  (A) 25ST2-88382C-D0R (fan)
  (B) 25ST1-243103-A0R (heatsink)
  (C) 25CRI-350B02-A4R (fan extension power cable)
