1. Ultra Durable 3 technology with 2 oz copper PCB for lower working temperature
  2. Supports newest NEC SuperSpeed USB 3.0 with superfast transfer rates
  3. 3X USB power delivery for greater compatibility and extra power for USB devices
  4. Revolution energy saving design with DES Advanced featuring hardware based Dynamic 4-Gear switching
  5. Supports 45nm Intel Core 2 multi-core processors with FSB 1600 MHz (O.C.)
  6. Natively support dual channel DDR3 1600+ for remarkable system performance
  7. Ultimate graphics performance with PCI-E 2.0 x16 interface
  8. Patented DualBIOS with dual hardware BIOS protection
  9. Hardware Overvoltage Control IC provides more voltage control options
  10. Home theater quality 8-channel High Definition Audio
  11. Compatible with Window 7 to deliver the best operation experience
  12. Meet European Union ErP(Energy-related Products) requirement
  • Support USB 3.0
    The GIGABYTE motherboards support the latest generation SuperSpeed USB 3.0 technology made possible through an onboard USB3.0 host controller. With superfast transfer rates of up to 5 Gbps, users are able to experience an almost a 10x improvement over USB 2.0. Additionally, backwards compatibility with USB 2.0 assures users of long term use of their legacy USB 2.0 devices. The onboard SuperSpeed USB 3.0 technology also provides new power management features that include increased maximum bus power and device current draw to better accommodate power-hungry devices.
  • 3x USB Power Boost
    L'emploi de 3x USB Power Boost permet d'assurer stabilité et compatibilité optimale avec des périphériques tels que HDDs externes ou lecteurs optiques en leur assurant des sources d'énergies nécessaires à leur bon fonctionnement.

    (note) Seuls les ports frontaux supportent la technologie 3X USB Power
  • Qualified for Windows® 7
    The motherboard qualified for WHQL (Windows Hardware Quality Labs) certification of Windows 7 from Microsoft®, setting the standard for future Windows 7 certified motherboards...more
  • Ultra Durable 3

    Ultra Durable 3
    GIGABYTE Ultra Durable 3 design, featuring 2 ounces of copper for both the Power and Ground layers which dramatically lowers system temperature by delivering a more efficient spreading of heat from critical areas of the motherboard such as the CPU power zone throughout the entire PCB. GIGABYTE's Ultra Durable 3 also lowers the PCB impedance by 50%, which helps to reduce electrical waste and further lowers component temperatures. A 2oz Copper layer design also provides improved signal quality and lower EMI (Electromagnetic Interference), providing better system stability and allowing for greater margins for overclocking...more
  • DDR3 1600+ Support
    Delivering native support for DDR3 memory up to1600+MHz, GIGABYTE Ultra Durable 3 series motherboards allow users to easily reach higher memory frequencies at lower voltages; achieving higher memory performance with lower power consumption to run even the most memory intensive applications such as high-definition video and 3D games with ease.
  • Dynamic Energy Saver Advanced
    GIGABYTE Dynamic Energy Saver Advanced provides better energy saving capabilities and enhanced system performance. GIGABYTE Dynamic Energy Saver Advanced is the world’s only motherboard energy saving technology with hardware-based Dynamic 4-Gear* Switching. With support for VRD 11.1, GIGABYTE’s DES Advanced allows the motherboard to switch to 1 Gear phase switching during idle, allowing for a dramatic increase in power savings.

    GIGABYTE has also retooled Dynamic Energy Saver to allow overclockers to experience the benefits of multi-gear power phase switching while overclocking, providing ultra stable, ultra smooth overclocking performance.
    * The 4-Gear feature may vary by model. Gear 1 phase switching requires 45nm processors with PSI signal enabled.


  • Overclocking sans effort en un click !
    GIGABYTE quick boost propose 3 niveaux de performances pour votre cpu, en un simple click vous pourrez choisir le profil de votre choix et bénéficier d'un overclocking rapide et sans effort !
  • EasyTune6
    Logiciel de gestion et de tweaking de votre système
  • Hardware OverVoltage Control IC-- Enabling Extreme Overclocking
    GIGABYTE Hardware Overvoltage Control ICs featuring more voltage control options than before for the CPU North Bridge and memory. The overvoltage controllers also provide hardware linear real-time voltage control, which means there is no delay compared to the GPIO controller in past implementations. In addition, GIGABYTE's Hardware Overvoltage Controller ICs also allow for much finer voltage control, allowing power users to adjust voltage in as little increments as 20mV for better overclocking performance.
  • DualBIOS™ - Protection Double Bios
    DualBIOS™ - Protection Double Bios
  • Intel® High Definition Audio
    La norme Intel® High Definition Audio vous offre un système audio totalement immersif pour que votre PC devienne votre centre multimédia HD
  • Produit à la norme ErP
    l'ErP (Energy releated Products) est une directive faisant partie d'un ensemble de normes et régulations européennes visant à réduire l'impact négatif des composants electroniques sur l'environnement pendant leur cycle de vie. Chez GIGABYTE, nous dédions l'ensemble de notre travail à la cause environnementale et sommes fiers de faire partie des constructeurs leader dévelopant des technologies de pointe respectant la biosphère. En proposant des innovations telles que la solution DES, GIGABYTE vous offre d'ores et déjà un ensemble de produits bâtissant un avenir plus vert !
  • Condensateurs solides japonais - 50,000h
    GIGABYTE Ultra Durable motherboards are equipped with solid capacitors developed by leading Japanese manufacturers. With an average lifespan of 50,000 hours, these solid capacitors provide the stability, reliability and longevity essential to meet the power needs of high-end processors and other components running today's most demanding applications and games...more


    * 50000 hours of work time is calculated at 85℃ ambient temperature.
  • Innovation On / Off Charge
    Dérivée de notre innovation 3x USB Power, la technologie On / Off Charge, permet de maximiser les rendements de courant fournis par les ports USB de nos cartes mères, que votre PC soit allumé, en mode « Stand by » ou éteint.Pour en savoir plus
    * Pour cause de limitations sur certains téléphones mobiles, vous aurez peut être besoin de connecter votre appareil à votre PC avant que celui ci n'entre en mode S4/S5 pour bénéficier de la charge rapide.
     On/Off Charge Driver download

* Les termes HDMI, interface multimédia haute définition HDMI et habillage commercial HDMI, et les logos HDMI sont des marques commerciales et des marques déposées de HDMI Licensing Administrator, Inc.
* Les informations ici proposées le sont pour référence uniquement. GIGABYTE se réserve le droit de modifier ce contenu à tout moment et sans préavis.
* Marques et logos appartiennent aux détenteurs respectifs de leurs droits.
* L'architecture de grand nombre de PC affectera directement la capacité mémoire, en effet, une certaine quantité de RAM sera affectée au système, la quantité totale affichée pourra alors varier de celle insérée sur votre carte mère
