GA-Z77-HD3 (rev. 1.0)

GIGABYTE Z77-HD3 Motherboard combine a host of new and exciting technologies with the latest Intel Z77 Express Chipset, creating a unique range of motherboard designs that harness the outstanding performance of the new 3rd generation Intel^® Core™ processors. With an exclusive GIGABYTE 3D BIOS (Dual UEFI), UD4 Classic technology and unique EZ Set Up uilities, GIGABYTE Z77-HD3 Motherboard ensure outstanding system absolute control, with additional features that ensure an unrivalled experience on your next PC build.

The new GIGABYTE HD motherboard series defies the current ethos that means true digital display outputs are reserved for upper mainstream models, adding both HDMI and DVI ports to a range of motherboard models at attractive and affordable price points. All DIY enthusiasts can now enjoy true HD display capability using the most commonly integrated digital output technologies on today's HD displays and TVs...More

The revolutionary GIGABYTE 3D BIOS application is based on GIGABYTE UEFI DualBIOS™ technology and is available to consumers in two exclusive modes of interaction, providing enthusiast and mainstream users with a choice of unique and powerful graphical interfaces.

UEFI DualBIOS™ Technology
At the heart of this exciting 3D BIOS technology is a pair of physical BIOS ROMs containing GIGABYTE's exclusive in-house designed UEFI BIOS technology. With a superior graphical interface capable of 32-bit color imaging and fluid user-friendly mouse navigation, UEFI DualBIOS™ makes BIOS configuration a new and exciting experience for novice and experienced users alike. UEFI BIOS also brings native support for large hard drives on 64-bit operating systems.

3D Mode
Designed to provide an extremely streamlined and user-friendly BIOS environment, GIGABYTE's exclusive 3D mode offers a fully interactive and illustrative GUI that allows users to easily and intuitively make key adjustments to the UEFI BIOS settings for optimum performance. 3D Mode allows novice or casual users to more clearly understand the areas of the motherboard that are being affected through the BIOS settings, gaining a clearer understanding of the BIOS functionality.

Advanced Mode
Advanced mode provides a more comprehensive UEFI BIOS environment that is designed specifically for overclockers and power users who want maximum control over their PC's hardware. GIGABTYE's signature M.I.T. tuning technology can be found alongside fully configurable parameters for GIGABTE's all new digital 3D Power engine. In short, advanced mode combines the signature GIGABYTE BIOS expertise you've come to expect, wrapped a slick, new and optimized graphical UEFI interface.

Os novos processadores da 3 ª geração Intel ^® Core ™ são baseados na nova arquitetura da 3 ª geração Intel ^® Core ™, fabricados com os processos mais recentes para criar uma plataforma de 22nm, visualmente otimizada. Com base no soquete LGA 1155, a 3 ª geração Intel ^® Core ™ apresenta até quatro núcleos de alto desempenho de 64 bits de processamento e 8MB do L3 Smart Cache, garantindo total performance quando você mais precisa.

As placas-mãe GIGABYTE Série 7 têm a vantagem da mais nova tecnologia de conectividade e bus de expansão disponível na plataforma Intel. Além do suporte nativo para SuperSpeed USB 3.0, a plataforma do processador da 3a geração Intel^® Core™ (incluindo chipset Intel^®Z77) estréia o novo bus de expansão PCI Express gen. 3.0, permitindo aos usuários desfrutarem da próxima geração, soluções de placas gráficas discretas e de alta banda larga.
* PCIE Gen.3 depende da compatibilidade da CPU e da placa de expansão.

Retorna rapidamente para onde o seu sistema estava, saindo da hibernação para totalmente ligado em um piscar de olhos.

Fique em dia com atualizações automáticas, sem espera em seu email e redes sociais, até quando o seu PC estiver dormindo.

	Proteção Contra Umidade A umidade pode causar uma devastação nos circuitos de uma placa-mãe. O novo modelo de PCB de Fibra de Vidro da GIGABYTE ajuda na proteção contra curtos circuitos causados pela umidade através da redução do espaço entre os filamentos da PCB.
	Proteção Contra Estática As placas-mãe GIGABYTE Ultra Durable 4 Classic possuem chips de Alta Resistência que protegem a placa contra descargas eletroestáticas.
	Proteção Contra Falha de Energia Danos permanentes causados por surto de energia ou falha durante a atualização de BIOS podem ser evitados com o GIGABYTE DualBIOS que automaticamente ativa uma BIOS secundária para backup. A GIGABYTE também utiliza chips com proteção Anti-Surto para proteger a placa-mãe contra surtos de energia.
	Proteção Contra Alta Temperatura GIGABTYE utiliza capacitores sólidos e MOSFETs de Baixo RDS(on) que permitem trabalhar em temperaturas altas, proporcionando até 50.000* horas de vida útil dos componentes.

The GIGABYTE EZ Smart Response utility is a simple application that allows users to quickly and easily configure their system for Intel^® Smart Response Technology. In the past, enabling Intel^® Smart Response meant users needed to enter the BIOS in order to configure their system for RAID mode, which then required a complete reinstall of the operating system. Once that processes was complete, users then needed to install the Intel^® Rapid Storage Utility as well as configure Intel's Smart Response Technology. GIGABYTE EZ Smart Response does all of this automatically, without users having to perform a complicated install process. This allows them to quickly and effortlessly enjoy a significant boost in system performance.

GIGABYTE EZ Setup is an exclusive application that allows GIGABYTE 7 series users to more easily configure and setup three important Intel Technologies on their new system; Intel^® Smart Response, Intel^® Rapid Start and Intel^® Smart Connect. GIGABYTE EZ Setup makes it far easier to enjoy these technologies by greatly reducing the number of steps involved to install setup and configure your system.

GIGABYTE 7 series motherboards feature GIGABYTE 333 Onboard Acceleration , a range of the latest technologies that are designed help speed up data transfer, including SuperSpeed USB 3.0 technology, SATA Revision 3.0 (6Gbps) technology and an unprecedented 3x USB power boost on all USB ports for more power hungry USB devices.

GIGABYTE 7 series motherboards feature ON/OFF Charge, a unique GIGAYTE technology which allows you not only to charge your iPhone, iPad or iPod Touch, but also allows you to Quick Charge it. As an added bonus, it can even be charged when your PC is turned off, so even if you forget to plug it into your charger after you've synced up your music, it will be fully charged when you need it.

* Due to certain mobile phone limitations, users may need to connect the mobile phone to their PC before the PC enters S4/S5 mode to enable a quick charge from non ON/OFF Charge USB ports.
Charging results may vary by model.

Como parte do seu kit, a placa-mãe dispõe de um conveniente painel de controle frontal que permite acesso rápido e fácil à 2 portas USB 3.0

Recursos Adicionais ao Painel Traseiro
Power eSATA para conectividade rápida a unidades externas. Botão Quick Boost que permite aos jogadores um overclock instantâneo de seu sistema com um simples apertar de botão.

Rápido desempenho para codificação de mídia Economize tempo ao criar e editar vídeos, sincronizá-lo a outros dispositivos e compartilhá-lo em casa e na internet. O Intel Quick Sync utiliza hardware de vídeo no processador em vez do software, acelerando a codificação de vídeo.
