R162-ZA2

Rack Server - AMD EPYC™ 7003 - 1U UP 12-Bay Gen4 NVMe
  • Hardware-level root of trust support
  • AMD EPYC™ 7003 Series processors
  • Single processor, 7nm technology
  • 8-Channel DDR4 RDIMM/LRDIMM, 16 x DIMMs
  • 2 x 1Gb/s LAN ports (Intel® I350-AM2)
  • 12 x 2.5" Gen4 NVMe hot-swappable bays
  • 1 x M.2 slot with PCIe Gen4 x4 interface
  • 2 x M.2 slots with PCIe Gen3 x4 interface
  • 2 x FHHL PCIe Gen4 x16 and x8 slots
  • 1 x Internal FHHL PCIe Gen4 x16 slot
  • 1 x OCP 3.0 Gen4 x16 slot
  • 1 x OCP 2.0 Gen3 x8 mezzanine slot
  • 1+1 800W 80 PLUS Platinum redundant power supplies
Get a Quote
* The entire materials provided herein are for reference only. GIGABYTE reserves the right to modify or revise the content at anytime without prior notice.
* Advertised performance is based on maximum theoretical interface values from respective Chipset vendors or organization who defined the interface specification. Actual performance may vary by system configuration.
* All trademarks and logos are the properties of their respective holders.
* Due to standard PC architecture, a certain amount of memory is reserved for system usage and therefore the actual memory size is less than the stated amount.

SPECIFICATIONS

Dimensions (WxHxD, mm)
1U
438 x 43.5 x 780
Motherboard
MZA2-CE0 Rev. 3.0
CPU
AMD EPYC™ 7003 Series processors
AMD EPYC™ 7002 Series processors
Single processor, 7nm technology
Up to 64 cores, 128 threads per processor
cTDP up to 240W

Note: Select 1300W power supply to support cTDP 280W CPU
Socket
1 x LGA 4094
Socket SP3
Chipset
System on Chip
Memory
16 x DIMM slots
DDR4 memory supported only
8-Channel memory architecture
RDIMM up to 128GB supported
LRDIMM up to 128GB supported
3DS RDIMM/LRDIMM up to 256GB supported
Memory speed: Up to 3200*/2933 MT/s

*Follow BIOS setting and memory QVL if running 3200 MT/s with 2DPC.
LAN
Rear side:
2 x 1Gb/s LAN ports (1 x Intel® I350-AM2)
Support NCSI function

1 x 10/100/1000 Mbps Management LAN
Video
Integrated in Aspeed® AST2500
- 1 x VGA port
Storage
Front side:
12 x 2.5" Gen4 NVMe hot-swappable bays
SAS
N/A
RAID
N/A
Expansion Slots
Riser Card CRS1221 x 2:
- 1 x PCIe x16 (Gen4 x16) FHHL slot
- 1 x PCIe x16 (Gen4 x8 or x16) FHHL slot, shared with OCP 2.0

Internal Riser Card CRS101H:
- 1 x PCIe x16 (Gen4 x16) FHHL slot, occupied by CNV3134, 4 x U.2 HBA

1 x OCP 3.0 slot with PCIe Gen4 x16 bandwidth

1 x OCP 2.0 mezzanine slot with PCIe Gen3 x0 or x8 bandwidth, shared with CRS1221

1 x M.2 slot:
- M-key
- PCIe Gen4 x4
- Supports 2280/22110 cards

2 x M.2 slots (CMTP063):
- M-key
- PCIe Gen3 x4
- Supports 2280/22110 cards
Internal I/O
1 x TPM header
Front I/O
1 x USB 3.0
1 x Power button with LED
1 x ID button with LED
1 x NMI button
1 x Reset button
2 x LAN activity LEDs
1 x Storage activity LED
1 x System status LED
Rear I/O
2 x USB 3.0
1 x VGA
2 x RJ45
1 x MLAN
1 x ID button with LED
Backplane Board
Speed and bandwidth:
PCIe Gen4 x4
TPM
1 x TPM header with SPI interface
- Optional TPM2.0 kit: CTM010
Power Supply
1+1 800W 80 PLUS Platinum redundant power supplies

AC Input:
- 100-240V~/ 10-4A, 50-60Hz

DC Input:
- 240Vdc/ 4.5A

DC Output:
- Max 800W
+ 12V/ 66A
+ 12Vsb/ 2.5A
System Management
Aspeed® AST2500 Baseboard Management Controller
GIGABYTE Management Console web interface

  • Dashboard
  • HTML5 KVM
  • Sensor Monitor (Voltage, RPM, Temperature, CPU Status …etc.)
  • Sensor Reading History Data
  • FRU Information
  • SEL Log in Linear Storage / Circular Storage Policy
  • Hardware Inventory
  • Fan Profile
  • System Firewall
  • Power Consumption
  • Power Control
  • LDAP / AD / RADIUS Support
  • Backup & Restore Configuration
  • Remote BIOS/BMC/CPLD Update
  • Event Log Filter
  • User Management
  • Media Redirection Settings
  • PAM Order Settings
  • SSL Settings
  • SMTP Settings
OS Compatibility
Citrix Hypervisor 8.2.0 or later

Red Hat Enterprise Linux 8.3 or later
Red Hat Enterprise Linux 9.0 or later

SUSE Linux Enterprise Server 12 SP5 or later
SUSE Linux Enterprise Server 15 SP2 or later

Ubuntu 18.04.5 LTS or later
Ubuntu 20.04 LTS or later
Ubuntu 22.04 LTS or later

VMware ESXi 6.7 Update3 P03 or later
VMware ESXi 7.0 Update1 or later
VMware ESXi 8.0 or later

Windows Server 2016 (X2APIC/256T not supported)
Windows Server 2019
Windows Server 2022
System Fans
4 x 40x40x56mm (29,700rpm)
4 x 40x40x28mm (25,000rpm)
Operating Properties
Operating temperature: 10°C to 35°C
Operating humidity: 8%-80% (non-condensing)
Non-operating temperature: -40°C to 60°C
Non-operating humidity: 20%-95% (non-condensing)
Weight
Net Weight: 14.6 kg
Packaging Dimensions
1038 x 588 x 223 mm
Packaging Content
1 x R162-ZA2
1 x CPU heatsink
1 x 2-Section Rail kit
Part Numbers
- Barebone package: 6NR162ZA2MR-00-A*
- Motherboard: 9MZA2CE0NR-00
- 2-Section Rail kit (CMA not supported): 25HB2-3A0203-K0R
- CPU heatsink: 25ST1-443107-A3R
- Front panel board - CFP1030: 9CFP1030NR-00
- Backplane board - CBP10C0: 9CBP10C0NR-00
- Riser card - CRS1221: 9CRS1221NR-00
- Internal Riser card - CRS101H: 9CRS101HNR-00
- 4-port NVMe card - CNVP142: 9CNVP142NR-00
- Fan module: 25ST2-405622-A0R/25ST2-442828-D0R
- Power supply (800W): 25EP0-208004-L0S

Optional parts:

- 3-Section Rail kit (Supports CMA): 25HB2-A56121-K0R
- Cable Management Arm: 25HB1-R18300-K0R
- Power Supply (1300W): 25EP0-213004-F3S
- Power Supply (1300W): 25EP0-213006-F3S
- RMA packaging: 6NR162ZA2SR-RMA-A100
