GA-8IEXP (Rev. 2.0)

Rev. 2.0Rev. 1.2
СпецификацииПоддержкаНовости & НаградыWhere to Buy

Спецификации

  • Процессор
    1. Socket 478 for Intel® mPGA478 Pentium® 4 processor in 478 pin package
    2. 533/400 MHz FSB
  • Чипсет
    1. Intel® 845E
    2. Intel® 82801DB ICH4
    3. Intel® PRO/100 VE LAN chip
    4. Promise PDC20276 RAID controller chip supports RAID 0,1
    5. Realtek ALC650 AC'97 codec
    6. Super I/O: ITE I/O IT8712F chip
    7. Smart I/O: Winbond Smart@ I/O chip
    8. IEEE 1394: VIA6306 controller chip
    9. 2 x 4M bit flash ROM
  • Подсистема памяти
    1. Type: DDR266 (PC 2100) / DDR200(PC1600) 184 pin (2.5v)
    2. Max capacity: Up to 2 GB by 3 DIMM slots
  • Разъёмы для плат расширения
    1. 1 x AGP 4x, supports 1.5v display card only
    2. 6 x PCI (PCI 2.2 compliant)
    3. 1 x CNR
  • Разъемы на системной плате
    1. 1 x FDD
    2. 2 x ATA 133/100/66 Bus Master IDE for RAID 0 and RAID 1 ( only two HDDs could be used by RAID function )
    3. 2 x UDMA ATA 100/66 Bus Master IDE
    4. 2 x USB 2.0 (4 ports by cable with rear USB bracket)
    5. 3 x IEEE 1394 ports (with rear bracket)
    6. Memory Stick / Security Digital (MMC) / Smart Card Reader connectors
    7. S/P DIF output (with rear bracket)
    8. 3 x cooling fan pin headers
    9. CD/AUX in
  • Разъемы на задней панели
    1. 2 x USB 2.0 ports
    2. 1 x RJ45 LAN port
    3. 1 x LPT, 2 x COM ports
    4. Audio (1 x Line-in / 1 x Line-out / 1 x MIC) connector
    5. PS/2 Keyboard/Mouse connector
    6. 1 x Game/Midi port
  • Контроль за состоянием системы
    1. System health status auto-detect and report by BIOS
    2. H / W detect and report power-in voltage, CPU voltage, and fan speed
  • ПО в комплекте поставки
    1. Anti-Virus OEM version
    2. GIGABYTE Windows Utility Manager
    3. Adobe Acrobat Reader
    4. IAA (Intel® Application Accelerator)
  • Форм-фактор
    1. ATX form factor, 4 layers PCB (30.5 x 23 cm)
  • CPU/AGP/DIMM setting
    1. CPU FSB / Multiplier / Vcore Voltage adjustable via BIOS
    2. AGP Voltage / Clock adjustable via BIOS
    3. DIMM Voltage / Clock adjustable via BIOS
  • Driver
    1. Creative sound driver
    2. Promise RAID controller driver (includes pure ATA 133 driver)
    3. Intel®LAN driver
    4. Winbond Smart I/O driver
  • Other Features
    1. GIGABYTE patented DualBIOS™
    2. IDE #1-#4, SCSI, LS120, ZIP, CD-ROM and USB bootable
    3. Suspend to RAM (STR)
    4. Supports USB KB / MS wake up from S3
    5. Poly fuse for keyboard over-current protection
    6. @BIOS™, Easy Tune™ 4, Q-Flash™, GMC™
  • Процессор
    1. Socket 478 for Intel® mPGA478 Pentium® 4 processor in 478 pin package
    2. 533/400 MHz FSB
  • Чипсет
    1. Intel® 845E
    2. Intel® 82801DB ICH4
    3. Intel® PRO/100 VE LAN chip
    4. Promise PDC20276 RAID controller chip supports RAID 0,1
    5. Realtek ALC650 AC'97 codec
    6. Super I/O: ITE I/O IT8712F chip
    7. Smart I/O: Winbond Smart@ I/O chip
    8. IEEE 1394: VIA6306 controller chip
    9. 2 x 4M bit flash ROM
  • Подсистема памяти
    1. Type: DDR266 (PC 2100) / DDR200(PC1600) 184 pin (2.5v)
    2. Max capacity: Up to 2 GB by 3 DIMM slots
  • Разъёмы для плат расширения
    1. 1 x AGP 4x, supports 1.5v display card only
    2. 6 x PCI (PCI 2.2 compliant)
    3. 1 x CNR
  • Разъемы на системной плате
    1. 1 x FDD
    2. 2 x ATA 133/100/66 Bus Master IDE for RAID 0 and RAID 1 ( only two HDDs could be used by RAID function )
    3. 2 x UDMA ATA 100/66 Bus Master IDE
    4. 2 x USB 2.0 (4 ports by cable with rear USB bracket)
    5. 3 x IEEE 1394 ports (with rear bracket)
    6. Memory Stick / Security Digital (MMC) / Smart Card Reader connectors
    7. S/P DIF output (with rear bracket)
    8. 3 x cooling fan pin headers
    9. CD/AUX in
  • Разъемы на задней панели
    1. 2 x USB 2.0 ports
    2. 1 x RJ45 LAN port
    3. 1 x LPT, 2 x COM ports
    4. Audio (1 x Line-in / 1 x Line-out / 1 x MIC) connector
    5. PS/2 Keyboard/Mouse connector
    6. 1 x Game/Midi port
  • Контроль за состоянием системы
    1. System health status auto-detect and report by BIOS
    2. H / W detect and report power-in voltage, CPU voltage, and fan speed
  • ПО в комплекте поставки
    1. Anti-Virus OEM version
    2. GIGABYTE Windows Utility Manager
    3. Adobe Acrobat Reader
    4. IAA (Intel® Application Accelerator)
  • Форм-фактор
    1. ATX form factor, 4 layers PCB (30.5 x 23 cm)
  • CPU/AGP/DIMM setting
    1. CPU FSB / Multiplier / Vcore Voltage adjustable via BIOS
    2. AGP Voltage / Clock adjustable via BIOS
    3. DIMM Voltage / Clock adjustable via BIOS
  • Driver
    1. Creative sound driver
    2. Promise RAID controller driver (includes pure ATA 133 driver)
    3. Intel®LAN driver
    4. Winbond Smart I/O driver
  • Other Features
    1. GIGABYTE patented DualBIOS™
    2. IDE #1-#4, SCSI, LS120, ZIP, CD-ROM and USB bootable
    3. Suspend to RAM (STR)
    4. Supports USB KB / MS wake up from S3
    5. Poly fuse for keyboard over-current protection
    6. @BIOS™, Easy Tune™ 4, Q-Flash™, GMC™

* Термины HDMI, HDMI High-Definition Multimedia Interface, фирменный стиль HDMI и логотип HDMI являются товарными знаками или зарегистрированными товарными знаками компании HDMI Licensing Administrator, Inc.
* The entire materials provided herein are for reference only. GIGABYTE reserves the right to modify or revise the content at anytime without prior notice.
* Advertised performance is based on maximum theoretical interface values from respective Chipset vendors or organization who defined the interface specification. Actual performance may vary by system configuration.
* All trademarks and logos are the properties of their respective holders.
* Due to standard PC architecture, a certain amount of memory is reserved for system usage and therefore the actual memory size is less than the stated amount.
