Intel® H61 Express Chipset
All GIGABYTE Super4™ motherboards are based on the Intel® H61 Express Chipset with support for 2nd generation ‘Sandy Bridge’ Intel® Core™ CPUs. With outstanding graphics and multimedia performance, the Intel® H61 Express chipset leverages the power and efficiency of Intel’s latest CPU technology to deliver a highly balanced, yet visually stunning PC experience. GIGABYTE Super4™ motherboards combine with the Intel® H61 Express Chipset to offer the most compelling choice for everyday computing needs.


Model Name
GA-H61M-USB3-B3
GA-H61M-USB3-B3
GA-H61M-S2H
GA-H61N-USB3
CPU Support
2nd Generation Intel Core Processors
2nd Generation Intel Core Processors
2nd Generation Intel Core Processors
CPU Socket
LGA1155
LGA1155
LGA1155
QPI/FSB
-
-
-
Chipset

Intel H61 chipset

Intel H61 chipset

Intel H61 chipset
Onboard Graphics
Intel HD Graphics 2000/3000
Intel HD Graphics 2000/3000
Intel HD Graphics 2000/3000
Graphics Interface
1*PCI-E x16 slot
DVI port
1*PCI-E 2.0 x16 slot
HDMI / DVI / GRB port
1*PCI-E 2.0 x16 slot
HDMI / DVI / GRB port
Memory Type
Dual-Channel DDR3
1333/1066/800 MHz
Dual-Channel DDR3
1333/1066/800 MHz
Dual-Channel DDR3
1333/1066/800 MHz
Memory DIMM
2*DDR3 (Max 16 GB)
2*DDR3 (Max 16 GB)
2*DDR3 (Max 16 GB)
Expansion Slots
1*PCI-Ex1+ 2*PCI
2*PCI + 1*PCI
-
ATA connector
4*SATA 3Gb/s
4*SATA 3Gb/s
2*SATA 3Gb/s + 1*eSATA 3Gb/s
SATA RAID
-
-
-
USB
2* USB3.0+8*USB2.0
8*USB2.0
2*USB3.0 + 8*USB2.0
Audio
8-channel HD
8-channel HD
8-channel HD
LAN
GbE LAN
GbE LAN
GbE LAN
Features & Software
VRD12,Ultra Durable 2,
On/Off Charge,
All 50000hrs solid cap,
Dual BIOS 3TB+ HDD Support, 108dB SNR Blu-ray,USB 3x power, Smart6, ErP Ready
VRD12,Ultra Durable 2,
All solid cap,
Dual BIOS 3TB+ HDD Support,
108dB SNR Blu-ray,
Smart6, ErP Ready
VRD12, All solid cap,
On/Off Charge,
Dual BIOS 3TB+ HDD Support,
108dB SNR Blu-ray,
Smart6, ErP Ready
Form Factor (mm)
mATX (244x205)
mATX (244x205)
mini-ITX (170x170)
D : All solid capacitor design
* Product features may vary by model.
* Motherboard models may vary based on local distribution.
* Please refer to GIGABYTE website for CPU support information
For further product information,please visit our website: www.gigabyte.us
* The specifications and pictures are subject to change without notice
* All trademarks and logos are the properties of their respective holders
