Intel® H61 Express Chipset
เมนบอร์ด GIGABYTE Super4™ ทุกรุ่นได้รับการออกแบบจากสถาปัตยกรรม Intel® H61 Express Chipset ซึ่งสนับสุนนการทำงานร่วมกับ 2nd generation 'Sandy Bridge' Intel® Core™ CPUs อันทรงสมรรนนะ. พร้อมเติมเต็มความสมบูรณ์แบบด้านระบบกราฟิกและมัลติมีเดียที่เหนือระดับ, Intel® H61 Express chipset เป็นชุดควบคุมรุ่นใหม่ล่าสุดที่ได้รับการออกแบบมาด้วยเทคโนโลยีที่มีคุณภาพสูง กินไฟต่ำ ส่งมอบประสิทธิภาพที่แตกต่างสำหรับ Intel's latest CPU technology โดยเฉพาะ. ด้วยเทคโนโลยีที่มีอยู่ใน Intel® H61 Express Chipset จะทำให้เมนบอร์ด GIGABYTE Super4™ คือตัวเลือกที่ดีที่สุดของเมนบอร์ดยุคใหม่. |
|
![](super4-models_01.jpg) |
Model Name |
|
|
|
CPU Support |
2nd Generation Intel Core Processors |
2nd Generation Intel Core Processors |
2nd Generation Intel Core Processors |
CPU Socket |
LGA1155 |
LGA1155 |
LGA1155 |
QPI/FSB |
- |
- |
- |
Chipset |
|
|
|
Onboard Graphics |
- |
- |
Intel HD Graphics 2000/3000 |
Graphics Interface |
1*PCI-E x16 slot |
1*PCI-E x16 slot |
1*PCI-E x16 slot
HDMI/DVI ports |
Memory Type |
Dual-Channel DDR3
1333/1066/800 MHz |
Dual-Channel DDR3
1333/1066/800 MHz |
Dual-Channel DDR3
1333/1066/800 MHz |
Memory DIMM |
2*DDR3 (Max 16 GB) |
2*DDR3 (Max 16 GB) |
2*DDR3 (Max 16 GB) |
Expansion Slots |
2*PCI-Ex1+ 3*PCI |
2*PCI-Ex1+ 3*PCI |
1*PCI-Ex1+ 2*PCI |
ATA connector |
4*SATA 3Gb/s |
4*SATA 3Gb/s |
2*SATA 6Gb/s +4*SATA 3Gb/s |
SATA RAID |
- |
- |
RAID 0,1 |
USB |
2* USB3.0+8*USB2.0 |
10*USB2.0 |
2* USB3.0+8*USB2.0 |
Audio |
8-channel HD |
8-channel HD |
8-channel HD |
LAN |
GbE LAN |
GbE LAN |
GbE LAN |
Features & Software |
VRD12, Ultra Durable 2,
All 50000hrs solid cap,
Dual BIOS 3TB+ HDD Support,
108dB SNR Blu-ray,USB 3x power, On/Off Charge port,
Smart6, ErP Ready |
VRD12, Ultra Durable 2,
All 50000hrs solid cap,
Dual BIOS 3TB+ HDD Support,
108dB SNR Blu-ray,USB 3x power, On/Off Charge port, Smart6,
ErP Ready |
VRD12,Ultra Durable 2,
All 50000hrs solid cap,
Dual BIOS 3TB+ HDD Support,
108dB SNR Blu-ray,USB 3x power,
On/Off Charge port, Smart6,
ErP Ready
|
Form Factor (mm) |
ATX (305x190) |
ATX (305x190) |
mATX (244x222) |
|
|
Model Name |
|
|
|
CPU Support |
2nd Generation Intel Core Processors |
2nd Generation Intel Core Processors |
2nd Generation Intel Core Processors |
CPU Socket |
LGA1155 |
LGA1155 |
LGA1155 |
QPI/FSB |
- |
- |
- |
Chipset |
|
|
|
Onboard Graphics |
Intel HD Graphics 2000/3000 |
Intel HD Graphics 2000/3000 |
Intel HD Graphics 2000/3000 |
Graphics Interface |
1*PCI-E x16 slot
DVI port |
1*PCI-E 2.0 x16 slot
DVI port |
1*PCI-E 2.0 x16 slot
DVI port |
Memory Type |
Dual-Channel DDR3
1333/1066/800 MHz |
Dual-Channel DDR3
1333/1066/800 MHz |
Dual-Channel DDR3
1333/1066/800 MHz |
Memory DIMM |
2*DDR3 (Max 16 GB) |
2*DDR3 (Max 16 GB) |
2*DDR3 (Max 16 GB) |
Expansion Slots |
1*PCI-Ex1+ 2*PCI |
3*PCI-Ex1 |
3*PCI-Ex1 |
ATA connector |
4*SATA 3Gb/s |
4*SATA 3Gb/s |
4*SATA 3Gb/s |
SATA RAID |
- |
- |
- |
USB |
2* USB3.0+8*USB2.0 |
10*USB2.0 |
10*USB2.0 |
Audio |
8-channel HD |
8-channel HD |
8-channel HD |
LAN |
GbE LAN |
GbE LAN |
GbE LAN |
Features & Software |
VRD12,Ultra Durable 2,
On/Off Charge,
All 50000hrs solid cap,
Dual BIOS 3TB+ HDD Support,
108dB SNR Blu-ray,USB 3x power, Smart6,
ErP Ready |
VRD12,Ultra Durable 2,
On/Off Charge,
All 50000hrs solid cap,
Dual BIOS 3TB+ HDD Support,
108dB SNR Blu-ray,USB 3x power,
Smart6, ErP Ready |
VRD12,Ultra Durable 2(CPU VRM),
On/Off Charge,
Dual BIOS 3TB+ HDD Support,
108dB SNR Blu-ray,USB 3x power,
Smart6, ErP Ready |
Form Factor (mm) |
mATX (244x205) |
mATX (244x195) |
mATX (244x195) |
|
D : All solid capacitor design
* Product features may vary by model.
* Motherboard models may vary based on local distribution.
* Please refer to GIGABYTE website for CPU support information |
