Exigez une carte mère Ultra Durable™ pour votre nouveau PC




Coming Soon
* Product features may vary by model.

Références
GA-Z77X-UP7
GA-Z77X-UP7
GA-Z77X-UP5 TH
GA-Z77X-UP5 TH
GA-Z77X-UP4 TH
GA-Z77X-UP4 TH
Support CPU
3rd and 2nd Gen Intel Core CPUs
3rd and 2nd Gen Intel Core CPUs
3rd and 2nd Gen Intel Core CPUs
Socket CPU
LGA1155
LGA1155
LGA1155
Chipset
Intel Z77 chipset
Intel Z77 chipset
Intel Z77 chipset
Interface graphique
3*PCIE 3.0X16+2*PCIE 3.0X8
1*PCIE 3.0X16+1*PCIE 3.0X8
1*PCIE 3.0X16+1*PCIE 3.0X8
Type Mémoire
Dual-Channel DDR3
2800/2600 (OC*)/1600 MHz
Dual-Channel DDR3
2800/2600 (OC*)/1600 MHz
Dual-Channel DDR3
2800/2600 (OC*)/1600 MHz
DIMMs mémoire
4*DDR3(Max 32 GB)
4*DDR3(Max 32 GB)
4*DDR3 (Max 32 GB)
Ports d'extension
2*PCIEx1
1*PCIEx4+3*PCIEx1+1*PCI
1*PCIEx4+3*PCIEx1+1*PCI
Connecteurs SATA / SAS
6*SATA 6Gb/s+4*SATA 3Gb/s
4*SATA 6Gb/s+4*SATA 3Gb/s
2*SATA 6Gb/s+4*SATA 3Gb/s
SATA RAID
RAID 0,1,5,10
RAID 0,1,5,10
RAID 0,1,5,10
USB
10*USB3.0+4*USB2.0
10*USB3.0+6*USB2.0
8*USB3.0+6*USB2.0
Audio
8-channel HD
8-channel HD
8-channel HD
1394
-
1*1394a
-
LAN
Dual LAN
GbE LAN
GbE LAN
Sorties Vidéos
HDMI/DVI/RGB/Display Port
HDMI/DVI/RGB/2xThunderbolt port
HDMI/DVI/RGB/2xThunderbolt port
Innovations et logiciels
Ultra Durable 5,
32 CPU VRM phase,
3D Power, 3D BIOS,
WiFi+BlueTooth 4.0, Lucid MVP, mSATA, EZ Smart Response,
4-Way SLI, 4-Way CrossFireX,
On/off charge,
All Japanese Solid capacitors
Ultra Durable 5,
Thunderbolt support,
3D Power, 3D BIOS, WiFi+BlueTooth 4.0, Lucid MVP, mSATA, EZ Smart Response, SLI, CrossFireX, CFOS, On/off charge,
All Japanese Solid capacitors
Ultra Durable 5,
Thunderbolt support,
3D Power, 3D BIOS,
Lucid MVP, mSATA,
EZ Smart Response, SLI, CrossFireX, On/off charge,
All Japanese Solid capacitors
Form Factor (mm)
E-ATX(305x264)
ATX(305x244)
ATX(305x244)



Références
GA-X79S-UP5 WIFI
GA-X79-UP4
Support CPU
2nd Generation Intel Core Processors
2nd Generation Intel Core Processors
Socket CPU
LGA 2011
LGA 2011
Chipset
Intel C606 chipset
Intel X79 chipset
Interface graphique
2*PCIE 3.0X16+1*PCIE 3.0X8
2*PCIE 3.0X16+2*PCIE 3.0X8
Type Mémoire
4 Channel DDR3
2400/1866 (OC*)/1600 MHz
4 Channel DDR3
2400/1866 (OC*)/1600 MHz
DIMMs mémoire
8*DDR3(Max 64 GB)
8*DDR3(Max 64 GB)
Ports d'extension
1*PCIEx4+1*PCIEx1+1*PCI
2*PCIEx1+1*PCI
Connecteurs SATA / SAS
8*SAS+2*SATA 6Gb/s+4*SATA 3Gb/s +2*eSATA 6Gb/s
6*SATA 6Gb/s+4*SATA 3Gb/s +2*eSATA 6Gb/s
SATA RAID
RAID 0,1,5,10
RAID 0,1,5,10
USB
6*USB3.0+12*USB2.0
4*USB3.0+14*USB2.0
Audio
8-channel HD
8-channel HD
1394
2*1394a
-
LAN
Dual LAN
GbE LAN
Sorties Vidéos
-
-
Innovations et logiciels
Ultra Durable 5,
3D Power, 3D BIOS,
3-Way SLI, 3-Way CrossFireX, On/Off Charge,
WIFI+BlueTooth 4.0, OC DualBIOS, eSATA, All Japanese Solid Capacitors, 110dB
Ultra Durable 5,
3D Power, 3D BIOS,
4-Way SLI, 4-Way CrossFireX,
On/Off Charge, All Japanese Solid Capacitors
Form Factor (mm)
E-ATX(305x262)
ATX(305x244)
U : PCB à 2 Onces de cuivre      P : Power stage + Condensateurs Solides
* Support mémoire pouvant varier selon référence et système d'exploitation
* Disponibilité de nos références pouvant varier selon lieu de distribution
* Se rendre sur le site gigabyte pour obtenir la liste de support processeur
