S183-SH0- AAV1

1U
438 x 43.5 x 730

MSH3-ES0

5th Generation Intel^® Xeon^® Scalable Processors
4th Generation Intel^® Xeon^® Scalable Processors
Intel^® Xeon^® CPU Max Series

Dual processor, TDP up to 350W

^[Note] If only 1 CPU is installed, some PCIe or memory functions might be unavailable.

2 x LGA 4677
Socket E

Intel^® C741

32 x DIMM slots
DDR5 memory supported
8-Channel memory architecture

5th Gen Intel^® Xeon^®:
RDIMM: Up to 5600 MT/s (1DPC), 4400 MT/s (2DPC) ^[1]

4th Gen Intel^® Xeon^®:
RDIMM: Up to 4800 MT/s (1DPC), 4400 MT/s (2DPC)

Intel^® Xeon^® Max Series:
RDIMM: Up to 4800 MT/s (1DPC), 4400 MT/s (2DPC)

^[1] 5600 MT/s support under 2DPC configuration requires verified memory and BIOS setup. Please refer to the QVL for more information.

Rear (G-SCM board - CDCR112):
2 x 1Gb/s LAN (1 x Intel^® I350-AM2)
- Support NCSI function

1 x 10/100/1000 Mbps Management LAN

Integrated in Aspeed^® AST2600
- 1 x Mini-DP

Front hot-swap:
32 x 9.5mm E1.S NVMe
- (16 x NVMe from CPU_0, 16 x NVMe from CPU_1)

Internal M.2 (CMTP0C0):
1 x M.2 (2280/22110), PCIe Gen3 x4 or SATA, from PCH

Internal M.2 (CMTP0C1):
1 x M.2 (2280/22110), PCIe Gen3 x4 or SATA, from PCH

N/A

Optional compatible RAID Cards:

NVMe/NVMe-oF RAID Cards with SupremeRAID™ by Graid Technology
RAID Card models: SR-1000-FD32, SR-1010-FD32
Support RAID 0/1/5/6/10

Riser Card CRSD013:
- 1 x FHHL x16 (Gen5 x16), from CPU_1

Riser Card CRSD022:
- 1 x FHHL x16 (Gen5 x16 or x8), from CPU_0
- 1 x FHHL x16 (Gen5 x0 or x8), from CPU_0

1 x USB 3.2 Gen1 port (Type-A)
1 x Power button with LED
1 x ID button with LED
1 x Storage activity LED
1 x System status LED

G-SCM board - CDCR112:
2 x USB 3.2 Gen1 ports (Type-A)
1 x Mini-DP
2 x RJ45 ports
1 x MLAN port
1 x ID LED

N/A

1 x TPM header with SPI interface
- Optional TPM2.0 kit: CTM010

Dual 1600W 80 PLUS Titanium redundant power supply

AC Input:
- 100-240V~/ 12-9.5A, 50/60Hz

DC Input: (Only for China)
- 240Vdc/ 9.5A

DC Output:
- Max 1000W/ 100-127V~
+12.2V/ 82A
+12Vsb/ 3A
- Max 1600W/ 200-240V~ or 240Vdc Input
+12.2V/ 131.2A
+12Vsb/ 3A

Aspeed^® AST2600 Baseboard Management Controller
GIGABYTE Management Console web interface

• Dashboard
• HTML5 KVM
• Sensor Monitor (Voltage, RPM, Temperature, CPU Status …etc.)
• Sensor Reading History Data
• FRU Information
• SEL Log in Linear Storage / Circular Storage Policy
• Hardware Inventory
• Fan Profile
• System Firewall
• Power Consumption
• Power Control
• Advanced power capping
• LDAP / AD / RADIUS Support
• Backup & Restore Configuration
• Remote BIOS/BMC/CPLD Update
• Event Log Filter
• User Management
• Media Redirection Settings
• PAM Order Settings
• SSL Settings
• SMTP Settings

Please refer to OS compatibility table in support page

Additional certifications:
Windows Server 2022 (x64)

7 x 40x40x56mm (32,000rpm)

Operating temperature: 10°C to 35°C
Operating humidity: 8%-80% (non-condensing)
Non-operating temperature: -40°C to 60°C
Non-operating humidity: 20%-95% (non-condensing)

985 x 588 x 250 mm

1 x S183-SH0-AAV1
2 x CPU heatsinks
1 x Mini-DP to D-Sub cable
6 x Carriers
1 x 2-Section Rail kit

- Barebone package (5th/4th Gen): 6NS183SH0DR000ABV1*
- Barebone package (4th Gen): 6NS183SH0DR000AAV1*
- Motherboard: 9MSH3ES0UR-000*
- 2-Section Rail kit (CMA not supported): 25HB2-3A0202-K0R
- CPU heatsink: 25ST1-4Z3200-S7R
- M.2 heatsink: 12SP2-11000E-00R
- Front panel board - CFPD040: 9CFPD040NR-00*
- Fan module: 25ST2-40562H-A0R
- M.2 expansion card - CMTP0C0: 9CMTP0C0NR-00*
- M.2 expansion card - CMTP0C1: 9CMTP0C1NR-00*
- Riser card - CRSD013: 9CRSD013NR-00*
- Riser card - CRSD022: 9CRSD022NR-00*
- EDSFF bridge board - CBG060: 9CBG60NR-00*
- EDSFF bridge board - CBG061: 9CBG61NR-00*
- G-SCM board - CDCR112: 9CDCR112NR-00*
- Mini-DP to D-Sub cable: 25CRN-200801-K1R
- Power supply: 25EP0-21600E-L0S

Optional parts:

- RAID card (SR-1000-FD32): 25FC1-SRBUN0-AFS
- RAID card (SR-1010-FD32): 25FC1-SRBUN4-AFR
- 3-Section Rail kit (CMA supported): 25HB2-AA6105-K0R
- Cable Management Arm: 25HBZ-R18100-K0R
- RMA packaging: 6NS183SH0SR-RMA-A100
