R143-EG0- AAC2

1U
438 x 43.5 x 815

MEG3-GU0

AMD EPYC™ 8004 Series Processors

Single processor, cTDP up to 225W

1 x LGA 4844
Socket SP6

System on Chip

12 x DIMM slots
DDR5 memory supported
6-Channel memory per processor
RDIMM: Up to 4800 MT/s (1DPC), 3600 MT/s (2DPC)

Rear:
1 x 10/100/1000 Mbps Management LAN

Integrated in ASPEED^® AST2600
- 1 x Mini-DP

Front hot-swap:
4 x 3.5"/2.5" Gen4 NVMe/SATA/SAS ^[1]

Internal M.2:
1 x M.2 (2280/22110), PCIe Gen3 x4

^[1] SAS card is required to support SAS drives.

Require SAS add-in cards

Require RAID add-in cards

PCIe Cable x 3:
- 1 x FHFL x16 (Gen5 x16), for GPUs
- 1 x FHFL x16 (Gen5 x16) ^[1]
- 1 x FHHL x16 (Gen5 x16)

1 x OCP NIC 3.0 (Gen5 x16)
- Supports NCSI function

^[1] Blocked when a Dual slot GPU is installed.

2 x USB 3.2 Gen1 ports (Type-A)
1 x Power button with LED
1 x ID button with LED
1 x NMI button
1 x Reset button
2 x LAN activity LEDs (disabled)
1 x Storage activity LED
1 x System status LED

2 x USB 3.2 Gen1 ports (Type-A)
1 x Mini-DP
1 x MLAN port
1 x ID button with LED

Speed and bandwidth:
PCIe Gen4 x4 or SATA 6Gb/s or SAS 12Gb/s

1 x TPM header with SPI interface
- Optional TPM2.0 kit: CTM010

1+1 1300W 80 PLUS Platinum redundant power supplies

AC Input:
- 100-240V~/ 12-7A, 50-60Hz
- 200-240V~/ 8A, 50-60Hz

DC Input: (Only for China)
- 240Vdc/ 6.5A

DC Output:
- Max 1000W/ 100-240V~
+12V/ 80.5A
+12Vsb/ 3A
- Max 1300W/ 200-240V~ or 240Vdc Input
+12V/ 105.4A
+12Vsb/ 3A

ASPEED^® AST2600 Baseboard Management Controller
GIGABYTE Management Console web interface

• Dashboard
• HTML5 KVM
• Sensor Monitor (Voltage, RPM, Temperature, CPU Status …etc.)
• Sensor Reading History Data
• FRU Information
• SEL Log in Linear Storage / Circular Storage Policy
• Hardware Inventory
• Fan Profile
• System Firewall
• Power Consumption
• Power Control
• Advanced power capping
• LDAP / AD / RADIUS Support
• Backup & Restore Configuration
• Remote BIOS/BMC/CPLD Update
• Event Log Filter
• User Management
• Media Redirection Settings
• PAM Order Settings
• SSL Settings
• SMTP Settings

Please refer to OS compatibility table in support page

8 x 40x40x56mm (29,700rpm)

Operating temperature: 10°C to 35°C
Operating humidity: 8%-80% (non-condensing)
Non-operating temperature: -40°C to 60°C
Non-operating humidity: 20%-95% (non-condensing)

1038 x 588 x 238 mm

1 x R143-EG0-AAC2
1 x CPU heatsink
1 x Mini-DP to D-Sub cable
1 x GPU power cable (12VHPWR, 450mm)
1 x 2-Section Rail kit

- Barebone package: 6NR143EG0DR000AAC2*
- Motherboard: 9MEG3GU0UR-000*
- 2-Section Rail kit (CMA not supported): 25HB2-3A0206-K0R
- CPU heatsink: 25ST1-44320G-A0R
- M.2 heatsink: 12SP2-11000E-00R
- Front board - CFP1010: 9CFP1010NR-00*
- Backplane board - CBP1047: 9CBP1047NR-00*
- Fan module: 25ST2-405623-A0R
- I/O board - CBG70: 9CBG70NR-00*
- Mini-DP to D-Sub cable: 25CRN-200801-K1R
- GPU power cable (12VHPWR, 450mm): 25CRI-450101-Y4R
- Power supply: 25EP0-21300B-F3S

Optional parts:

- 3-Section Rail kit (Supports CMA): 25HB2-A56121-K0R
- Cable Management Arm: 25HB1-R18300-K0R
