R183-ZK0-LAJ1

Rev. 3.x

Rack Server - AMD EPYC™ 9005/9004 - 1U DP 4 x Gen5 NVMe/SATA/SAS-4 DLC

# Networking # Hybrid/Private Cloud Server

Direct liquid cooling solution
Dual AMD EPYC™ 9005/9004 Series Processors
12-Channel DDR5 RDIMM, 48 x DIMMs
Dual ROM Architecture
2 x 1Gb/s LAN ports via Intel^® I350-AM2
4 x 2.5" Gen5 NVMe/SATA/SAS-4 hot-swap bays
2 x M.2 slots with PCIe Gen3 x4 and x2 interface
1 x FHHL PCIe Gen5 x16 slot
2 x OCP NIC 3.0 PCIe Gen5 x16 slots
1+1 2000W 80 PLUS Titanium redundant power supplies

Quick Shipping See More Models More ready-to-ship models in the R183 series. R183-Z94-AAD1 R183-Z94-AAV1 R183-S92-AAD1 R183-S92-AAV1

Get a Quote

Vergelijker

Get a Quote

* Alle materialen zijn alleen voor uw referenctie. GIGABYTE behoudt zich het recht om zonder aankondiging de inhoud te wijzigen of te herzien.
* Alle handelsmerken en logo's zijn eigendom van hun respectieve houders.
* Door de standaard PC-architectuur, wordt een bepaalde hoeveelheid geheugen gereserveerd voor gebruik van het systeem en dus is de werkelijke geheugengrootte kleiner dan de aangegeven hoeveelheid.

SPECIFICATIONS

Dimensions (WxHxD, mm)

1U
438 x 43.5 x 815

Motherboard

MZK3-LM0

CPU

AMD EPYC™ 9005 Series Processors
AMD EPYC™ 9004 Series Processors

Dual processor, cTDP up to 500W

^[Note]If only 1 CPU is installed, some PCIe or memory functions might be unavailable.

Socket

2 x LGA 6096
Socket SP5

Chipset

System on Chip

Memory

48 x DIMM slots
DDR5 memory supported
12-Channel memory architecture

AMD EPYC™ 9005:
RDIMM: Up to 5200 MT/s (1DPC)
RDIMM: Up to 4400 MT/s (1R 2DPC), 4000 MT/s (2R 2DPC)

AMD EPYC™ 9004:
RDIMM: Up to 4800 MT/s (1DPC), 3600 MT/s (2DPC)

LAN

Rear:
2 x 1Gb/s LAN (1 x Intel^® I350-AM2)
- Support NCSI function

1 x 10/100/1000 Mbps Management LAN

Video

Integrated in Aspeed^® AST2600
- 1 x Mini-DP

Storage

Front hot-swap:
4 x 2.5" Gen5 NVMe/SATA/SAS-4^[1]
- (NVMe from CPU_1)
- (SATA via CRS2810 from CPU_0)

Internal M.2:
1 x M.2 (2280/22110), PCIe Gen3 x4, from CPU_0, occupied for SATA
1 x M.2 (2280/22110), PCIe Gen3 x4, from CPU_1
1 x M.2 (2280/22110), PCIe Gen3 x2, from CPU_1

^[1]SAS card is required to support SAS drives.

^[Note]SATA hotplug utility can be downloaded on support page.

SAS

Require SAS add-in cards

RAID

Require RAID add-in cards

PCIe Expansion Slots

PCIe Cable:
- 1 x FHHL x16 (Gen5 x16), from CPU_1

2 x OCP NIC 3.0 (Gen5 x16), from CPU_0
- Support NCSI function

Front I/O

1 x USB 3.2 Gen1 port (Type-A)
1 x Power button with LED
1 x ID button with LED
1 x NMI button
1 x Reset button
2 x LAN activity LEDs
1 x Storage activity LED
1 x System status LED

Rear I/O

2 x USB 3.2 Gen1 ports (Type-A)
1 x Mini-DP
2 x RJ45 ports
1 x MLAN port
1 x ID LED

Backplane Board

Speed and bandwidth:
PCIe Gen5 x4 or SATA 6Gb/s or SAS-4 24Gb/s

Security Modules

1 x TPM header with SPI interface
- Optional TPM2.0 kit: CTM012

Power Supply

1+1 2000W 80 PLUS Titanium redundant power supplies

AC Input:
- 100-127V~/ 13A, 50-60Hz
- 200-220V~/ 10A, 50-60Hz
- 220-240V~/ 10A, 50-60Hz

DC Input: (Only for China)
- 240Vdc/ 10A

DC Output:
- Max 1000W/ 100-127V~
+12.2V/ 82A
+12.2Vsb/ 3A
- Max 1800W/ 200-220V~
+12.2V/ 148A
+12.2Vsb/ 3A
- Max 2000W/ 220-240V~ or 240Vdc Input
+12.2V/ 164A
+12.2Vsb/ 3A

^[Note]GIGABYTE offers PSUs with various efficiency ratings and power outputs. Full redundancy may depend on your server configuration, and alternative PSU options may be needed. Please contact our sales representatives for the best power solution.

System Management

Aspeed^® AST2600 Baseboard Management Controller
GIGABYTE Management Console web interface

Dashboard
HTML5 KVM
Sensor Monitor (Voltage, RPM, Temperature, CPU Status …etc.)
Sensor Reading History Data
FRU Information
SEL Log in Linear Storage / Circular Storage Policy
Hardware Inventory
Fan Profile
System Firewall
Power Consumption
Power Control
Advanced power capping
LDAP / AD / RADIUS Support
Backup & Restore Configuration
Remote BIOS/BMC/CPLD Update
Event Log Filter
User Management
Media Redirection Settings
PAM Order Settings
SSL Settings
SMTP Settings

OS Compatibility

Please refer to OS compatibility table in support page

System Fans

2 x 40x40x28mm (34,000rpm)
6 x 40x40x56mm (38,000rpm)

Operating Properties

Operating temperature: 10°C to 35°C
Operating humidity: 8%-80% (non-condensing)
Non-operating temperature: -40°C to 60°C
Non-operating humidity: 20%-95% (non-condensing)

^[Note]If the room's relative humidity exceeds 60%, the inlet water temperature must be set between 40°C and 45°C to avoid condensation and ensure the system continues to operate optimally.

Packaging Dimensions

1086 x 588 x 261 mm

Packaging Content

1 x R183-ZK0-LAJ1
1 x GIGABYTE CPU cold plate loop
1 x Mini-DP to D-Sub cable
1 x 2-Section Rail kit

Part Numbers

- Barebone w/ cold plates:
    - EPYC 9005/9004: 6NR183ZK0DR000LCJ1*
    - EPYC 9004: 6NR183ZK0DR000LAJ1*
- Barebone w/o cold plates:
    - EPYC 9005/9004: 6NR183ZK0DZ000LCJ1*
    - EPYC 9004: 6NR183ZK0DZ000LAJ1*
- Motherboard: 9MZK3LM0UR-000-3*
- 2-Section Rail kit (CMA not supported): 25HB2-3A0206-K0R
- GIGABYTE CPU cold plate loop: 25ST7-20000M-J2R
- M.2 heatsink: 12SP2-11000E-00R
- Backplane board - CBP2025: 9CBP2025NR-00*
- Fan module 40x40x28mm: 25ST2-44282I-N2R
- Fan module 40x40x56mm: 25ST2-40562O-D0R
- M.2 type SATA card - CRS2810: 9CRS2810NR-00*
- G-SCM board - CDCR114: 9CDCR114NR-00*
- Mini-DP to D-Sub cable: 25CRN-200801-K1R
- Power supply: 25EP0-22000Q-G1S

Optional parts:

- 3-Section Rail kit (Supports CMA): 25HB2-A56121-K0R
- Cable Management Arm: 25HB1-R18300-K0R
