R264-SG5-AAJ1

2U
438 x 87.5 x 815

MSG4-GU1

Intel^® Xeon^® 6 Processors
- Intel^® Xeon^® 6700-Series Processors
- Intel^® Xeon^® 6500-Series Processors

Single processor, TDP up to 350W

^[Note] Please select CPUs with 136 PCIe lanes to enable all features.

1 x LGA 4710
Socket E2

System on Chip

16 x DIMM slots
DDR5 memory supported
8-Channel memory per processor
MRDIMM supported ^[1]
RDIMM: Up to 6400 MT/s (1DPC), 5200 MT/s (2DPC)
MRDIMM: Up to 8000 MT/s

^[1] MRDIMMs are only supported with Intel^® Xeon^® 6 Processors with P-cores and in a 1DPC configuration.

Rear (I/O board - CBG70):
1 x 10/100/1000 Mbps Management LAN

Integrated in ASPEED^® AST2600
- 1 x Mini-DP

Front hot-swap:
28 x E3.S Gen5 NVMe ^[1]

Internal M.2:
2 x M.2 (2280/22110), PCIe Gen5 x2

^[1] Please select CPUs with 136 PCIe lanes to enable all NVMe support.

Require SAS add-in cards

Require RAID add-in cards
Onboard VROC key header

PCIe Cable:
- 1 x FHFL x16 (Gen5 x16), for GPUs

1 x OCP NIC 3.0 (Gen5 x16), occupied for NVMe

2 x USB 3.2 Gen1 ports (Type-A)
1 x Power button with LED
1 x ID button with LED
1 x NMI button
1 x Reset button
2 x LAN activity LEDs (disabled)
1 x Storage activity LED
1 x System status LED

I/O board - CBG70:
2 x USB 3.2 Gen1 ports (Type-A)
1 x Mini-DP
1 x MLAN port
1 x ID LED

Speed and bandwidth:
PCIe Gen5 x4

1 x TPM header with SPI interface
- Optional TPM2.0 kit: CTM012

1 x PRoT connector (only enabled on RoT SKU)

1+1 2000W 80 PLUS Titanium redundant power supplies

AC Input:
- 100-127V~/ 13A, 50-60Hz
- 200-220V~/ 10A, 50-60Hz
- 220-240V~/ 10A, 50-60Hz

DC Input: (Only for China)
- 240Vdc/ 10A

DC Output:
- Max 1000W/ 100-127V~
+12.2V/ 82A
+12.2Vsb/ 3A
- Max 1800W/ 200-220V~
+12.2V/ 148A
+12.2Vsb/ 3A
- Max 2000W/ 220-240V~ or 240Vdc Input
+12.2V/ 164A
+12.2Vsb/ 3A

^[Note] GIGABYTE offers PSUs with various efficiency ratings and power outputs. Full redundancy may depend on your server configuration, and alternative PSU options may be needed. Please contact our sales representatives for the best power solution.

ASPEED^® AST2600 Baseboard Management Controller
GIGABYTE Management Console web interface

• Dashboard
• HTML5 KVM
• Sensor Monitor (Voltage, RPM, Temperature, CPU Status …etc.)
• Sensor Reading History Data
• FRU Information
• SEL Log in Linear Storage / Circular Storage Policy
• Hardware Inventory
• Fan Profile
• System Firewall
• Power Consumption
• Power Control
• Advanced power capping
• LDAP / AD / RADIUS Support
• Backup & Restore Configuration
• Remote BIOS/BMC/CPLD Update
• Event Log Filter
• User Management
• Media Redirection Settings
• PAM Order Settings
• SSL Settings
• SMTP Settings

Please refer to OS compatibility table in support page

3 x 80x80x38mm (18,300rpm)
1 x 80x80x56mm (15,500rpm)

Operating temperature: 10°C to 35°C
Operating humidity: 8%-80% (non-condensing)
Non-operating temperature: -40°C to 60°C
Non-operating humidity: 20%-95% (non-condensing)

1077 x 679 x 300 mm

1 x R264-SG5-AAJ1
1 x CPU heatsink
1 x Mini-DP to D-Sub cable
1 x GPU power cable (12VHPWR, 450mm)
2 x Carriers
1 x 2-Section Rail kit

- Barebone package: 6NR264SG5DR000AAJ1*
- Motherboard: 9MSG4GU1UR-000*
- 2-Section Rail kit (CMA not supported): 25HB2-3A0206-K0R
- CPU heatsink: 25ST1-323208-A0R
- M.2 heatsink: 12SP2-11000E-00R
- Front panel board - CFP2001: 9CFP2001NR-00*
- Backplane board - CBP20P0: 9CBP20P0NR-00*
- Fan module 80x80x38mm: 25ST2-443820-S1R
- Fan module 80x80x56mm: 25ST2-885621-A0R
- I/O board - CBG70: 9CBG70NR-00*
- Mini-DP to D-Sub cable: 25CRN-200801-K1R
- GPU power cable (12VHPWR, 450mm): 25CRI-4500B0-Y4R
- Power supply: 25EP0-22000L-G1S

Optional parts:

- 3-Section Rail kit (Supports CMA): 25HB2-A56121-K0R
- Cable Management Arm: 25HB1-R18300-K0R
