S472-Z30

Rev. A00

Storage Server - AMD EPYC™ 7003/7002 - 4U UP 50-Bay Gen4 NVMe/SATA/SAS

# Storage

Hardware-level root of trust
Single AMD EPYC™ 7003/7002 Series Processors (with AMD 3D V-Cache™ Technology)
8-Channel DDR4 RDIMM/LRDIMM, 16 x DIMMs
2 x 1Gb/s LAN ports via Intel^® I350-AM2
24 x 3.5"/2.5" SATA/SAS hot-swappable bays
4 x 2.5" Gen4 NVMe/SATA/SAS hot-swappable bays
8 x 2.5" Gen4 NVMe hot-swappable bays
12 x 2.5" SATA/SAS hot-swappable bays
2 x 2.5" SATA hot-swappable bays on the rear side
SAS expander with 12Gb/s transfer speed
2 x M.2 slots with PCIe Gen4 x4 interface
2 x LP PCIe Gen4 x16 and x8 slots
Up to 2 x LP PCIe Gen3 x16 and x8 slots
1+1 1600W 80 PLUS Platinum redundant power supplies

Get a Quote

비교

Get a Quote

* 사이트에서 제공되는 모든 자료는 참조용일 뿐입니다. 기가바이트는 사이트의 자료를 사전 통지없이 언제든지 수정할 권리를 지닙니다.
* 모든 상표와 로고는 해당 소유자의 자산입니다.
* PC의 표준 아키텍쳐에 의해, 메모리의 특정 부분이 시스템에 사용되어 실제 메모리 크기는 표준보다 적게 표시될 수 있습니다.

SPECIFICATIONS

Dimensions (WxHxD, mm)

4U
482 x 175 x 696.6

Motherboard

MZ32-AR1

CPU

AMD EPYC™ 7003 Series Processors
AMD EPYC™ 7003 Series Processors with AMD 3D V-Cache™ Technology
AMD EPYC™ 7002 Series Processors
Single processor, 7nm technology
Up to 64 cores, 128 threads
cTDP up to 280W

Socket

1 x LGA 4094
Socket SP3

Chipset

System on Chip

Memory

16 x DIMM slots
DDR4 memory supported only
8-Channel memory architecture
RDIMM up to 128GB supported
LRDIMM up to 128GB supported
3DS RDIMM/LRDIMM up to 256GB supported
Memory speed: Up to 3200*/2933 MT/s

*Follow BIOS setting and memory QVL if running 3200 MT/s with 2DPC.

LAN

Rear side:
2 x 1Gb/s LAN ports (1 x Intel^® I350-AM2)
Support NCSI function

1 x 10/100/1000 Mbps Management LAN

Video

Integrated in Aspeed^® AST2500
2D Video Graphic Adapter with PCIe bus interface
1920x1200@60Hz 32bpp

Storage

Right & Left side:
24 x 3.5"/2.5" SATA/SAS hot-swappable bays

Front side:
4 x 2.5" Gen4 NVMe/SATA/SAS hot-swappable bays
8 x 2.5" Gen4 NVMe hot-swappable bays
12 x 2.5" SATA/SAS hot-swappable bays

Rear side:
2 x 2.5" SATA hot-swappable bays

1 x Broadcom SAS35x36R expander
Bandwidth: SATA 6Gb/s or SAS 12Gb/s per port

Default configuration supports:
12 x NVMe devices on the front side and 2 x SATA on the rear side

SAS card is required to enable the drive bays

Recommended SAS cards:
Broadcom 9500-16i Tri-Mode Storage Adapter
Broadcom 9560-8i Tri-Mode Storage Adapter

SAS

Supported via SAS add-in cards

RAID

Depends on SAS add-in cards

Expansion Slots

Slot_6: PCIe x16 (Gen4 x16) low-profile slot, occupied by CNV3134 - 4 x Gen4 NVMe HBA
Slot_5: PCIe x16 (Gen4 x8) low-profile slot
Slot_4: PCIe x16 (Gen4 x16) low-profile slot, occupied by CNV3134 - 4 x Gen4 NVMe HBA
Slot_3: PCIe x16 (Gen4 x16) low-profile slot
Slot_2: PCIe x8 (Gen3 x0 or x8) low-profile slot
Slot_1: PCIe x16 (Gen3 x16 or x8) low-profile slot, shared with slot_2

1 x OCP 2.0 mezzanine slot with PCIe Gen3 x16 bandwidth (Type1, P1, P2, P3, P4)
Supports NCSI function

2 x M.2 slots:
- M-key
- PCIe Gen4 x4
- Supports 2242/2260/2280 cards

Internal I/O

1 x TPM header

Front I/O

2 x USB 3.0
1 x Power button with LED
1 x ID button with LED
1 x Reset button
2 x LAN activity LEDs
1 x Storage activity LED
1 x System status LED

Rear I/O

3 x USB 3.0
1 x VGA
1 x COM
2 x RJ45
1 x MLAN
1 x ID button with LED

Backplane Board

Speed and bandwidth:
Front side - CBP20O7: PCIe Gen4 x4 or SATA 6Gb/s or SAS 12Gb/s
Rear side - CBPD020: SATA 6Gb/s
Right side - CBPD2C0: SATA 6Gb/s or SAS 12Gb/s
Left side - CBPD2C1: SATA 6Gb/s or SAS 12Gb/s

TPM

1 x TPM header with SPI interface
- Optional TPM2.0 kit: CTM010

Power Supply

1+1 1600W 80 PLUS Platinum redundant power supplies

AC Input:
- 100-240V~/ 12-7A, 50-60Hz
- 200-240V~/ 9.5A, 50-60Hz

DC Input: (Only for China)
- 240Vdc/ 8A

DC Output:
- Max 1000W/ 100-240V~
+12V/ 80.5A
+12Vsb/ 3A
- Max 1600W/ 200-240V~ or 240Vdc Input
+12V/ 130.4A
+12Vsb/ 3A

System Management

Aspeed^® AST2500 management controller
GIGABYTE Management Console (AMI MegaRAC SP-X) web interface

Dashboard
HTML5 KVM
Sensor Monitor (Voltage, RPM, Temperature, CPU Status …etc.)
Sensor Reading History Data
FRU Information
SEL Log in Linear Storage/Circular Storage Policy
Hardware Inventory
Fan Profile
System Firewall
Power Consumption
Power Control
LDAP / AD / RADIUS Support
Backup & Restore Configuration
Remote BIOS/BMC/CPLD Update
Event Log Filter
User Management
Media Redirection Settings
PAM Order Settings
SSL Settings
SMTP Settings

OS Compatibility

Citrix Hypervisor 8.2.0 or later

Red Hat Enterprise Linux 8.3 (x64) or later
Red Hat Enterprise Linux 9.0 (x64) or later

SUSE Linux Enterprise Server 12 SP5 (x64) or later
SUSE Linux Enterprise Server 15 SP2 (x64) or later

Ubuntu 18.04.5 LTS (x64) or later
Ubuntu 20.04 LTS (x64) or later
Ubuntu 22.04 LTS (x64) or later

VMware ESXi 6.7 Update3 P03 or later
VMware ESXi 7.0 Update1 or later
VMware ESXi 8.0 or later

Windows Server 2016 (X2APIC/256T not supported)
Windows Server 2019
Windows Server 2022

System Fans

8 x 80x80x38mm (14,400rpm)

Operating Properties

Operating temperature: 10°C to 35°C
Operating humidity: 8-80% (non-condensing)
Non-operating temperature: -40°C to 60°C
Non-operating humidity: 20%-95% (non-condensing)

Packaging Dimensions

1100 x 700 x 483 mm

Packaging Content

1 x S472-Z30
1 x CPU heatsink
1 x 2-Section Rail kit

Part Numbers

- Barebone package: 6NS472Z30MR-00-A*
- Motherboard: 9MZ32AR1NR-00
- 2-Section Rail kit (Supports CMA): 25HB2-A66123-C0R
- CPU heatsink: 25ST1-15320E-J1R
- Backplane board - CBP20O7: 9CBP20O7NR-00
- Backplane board - CBPD020: 9CBPD020NR-00
- Backplane board - CBPD2C0: 9CBPD2C0NR-00
- Backplane board - CBPD2C1: 9CBPD2C1NR-00
- Fan module: 25ST2-883829-D0R
- Power supply: 25EP0-21600B-F3S

Optional parts:

- Cable Management Arm: 25HBZ-R18100-K0R
- RMA packaging: 6NS472Z30SR-RMA-A100
