R283-S92- AAJ1

2U
438 x 87.5 x 815

MS93-FS0

5th Generation Intel^® Xeon^® Scalable Processors
4th Generation Intel^® Xeon^® Scalable Processors
Intel^® Xeon^® CPU Max Series

Dual processor, TDP up to 350W

^[Note] If only 1 CPU is installed, some PCIe or memory functions might be unavailable.

2 x LGA 4677
Socket E

Intel^® C741

32 x DIMM slots
DDR5 memory supported
8-Channel memory architecture

5th Gen Intel^® Xeon^®:
RDIMM: Up to 5600 MT/s (1DPC), 4400 MT/s (2DPC) ^[1]

4th Gen Intel^® Xeon^®:
RDIMM: Up to 4800 MT/s (1DPC), 4400 MT/s (2DPC)

Intel^® Xeon^® Max Series:
RDIMM: Up to 4800 MT/s (1DPC), 4400 MT/s (2DPC)

^[1] 5600 MT/s support under 2DPC configuration requires verified memory and BIOS setup. Please refer to the QVL for more information.

Rear (G-SCM board - CDCR112):
2 x 1Gb/s LAN (1 x Intel^® I350-AM2)
- Support NCSI function

1 x 10/100/1000 Mbps Management LAN

Integrated in Aspeed^® AST2600
- 1 x Mini-DP

Front hot-swap:
12 x 2.5" Gen4 NVMe/SATA/SAS ^[1]
12 x 2.5" Gen4 NVMe
- (12 x NVMe from CPU_0, 12 x NVMe from CPU_1)

Rear hot-swap:
4 x 2.5" SATA/SAS <sup>[1]

[1]</sup> SAS card is required to support SAS drives.

Require SAS add-in cards

Intel^® SATA RAID 0/1/10/5
Onboard VROC key header

Optional compatible RAID Cards:

NVMe/NVMe-oF RAID Cards with SupremeRAID™ by Graid Technology
RAID Card models: SR-1000-ED12, SR-1000-FD32, SR-1010-FD32
Support RAID 0/1/5/6/10

Riser Card CRS101J:
- 1 x FHHL x16 (Gen5 x16), from CPU_0

Riser Card CRS101K:
- 1 x FHHL x16 (Gen5 x16), from CPU_1

Riser Card CRS202G:
- 1 x FHHL x16 (Gen5 x16), from CPU_0

Riser Card CRS202H:
- 1 x FHHL x16 (Gen5 x16), from CPU_1

2 x USB 3.2 Gen1 ports (Type-A)
1 x Power button with LED
1 x ID button with LED
1 x NMI button
1 x Reset button
2 x LAN activity LEDs
1 x Storage activity LED
1 x System status LED

G-SCM board - CDCR112:
2 x USB 3.2 Gen1 ports (Type-A)
1 x Mini-DP
2 x RJ45 ports
1 x MLAN port
1 x ID LED

Speed and bandwidth:
Front side - CBP20O7: PCIe Gen4 x4 or SATA 6Gb/s or SAS 12Gb/s
Rear side - CBP2022: SATA 6Gb/s or SAS 12Gb/s

1 x TPM header with SPI interface
- Optional TPM2.0 kit: CTM010

1+1 2000W 80 PLUS Titanium redundant power supplies

AC Input:
- 100-127V~/ 13A, 50-60Hz
- 200-220V~/ 10A, 50-60Hz
- 220-240V~/ 10A, 50-60Hz

DC Input: (Only for China)
- 240Vdc/ 10A

DC Output:
- Max 1000W/ 100-127V~
+12.2V/ 82A
+12.2Vsb/ 3A
- Max 1800W/ 200-220V~
+12.2V/ 148A
+12.2Vsb/ 3A
- Max 2000W/ 220-240V~ or 240Vdc Input
+12.2V/ 164A
+12.2Vsb/ 3A

^[Note] GIGABYTE offers PSUs with various efficiency ratings and power outputs. Full redundancy may depend on your server configuration, and alternative PSU options may be needed. Please contact our sales representatives for the best power solution.

Aspeed^® AST2600 Baseboard Management Controller
GIGABYTE Management Console web interface

• Dashboard
• HTML5 KVM
• Sensor Monitor (Voltage, RPM, Temperature, CPU Status …etc.)
• Sensor Reading History Data
• FRU Information
• SEL Log in Linear Storage / Circular Storage Policy
• Hardware Inventory
• Fan Profile
• System Firewall
• Power Consumption
• Power Control
• Advanced power capping
• LDAP / AD / RADIUS Support
• Backup & Restore Configuration
• Remote BIOS/BMC/CPLD Update
• Event Log Filter
• User Management
• Media Redirection Settings
• PAM Order Settings
• SSL Settings
• SMTP Settings

Please refer to OS compatibility table in support page

Additional certifications:
VMware ESXi 8.0 (for 4400/3400 series)
VMware ESXi 8.0 (for 6400/5400 series)
VMware ESXi 8.0 (for 8400 series)
VMware ESXi 8.0 (for 4500/3500 series)
VMware ESXi 8.0 (for 4500/3500 series)
VMware ESXi 8.0 (for 6500/5500 series)
VMware ESXi 8.0 (for 8500 series)
Windows Server 2022

4 x 80x80x38mm (18,300rpm)

Operating temperature: 10°C to 35°C
Operating humidity: 8%-80% (non-condensing)
Non-operating temperature: -40°C to 60°C
Non-operating humidity: 20%-95% (non-condensing)

1077 x 679 x 300 mm

1 x R283-S92-AAJ1
2 x CPU heatsinks
1 x Mini-DP to D-Sub cable
6 x Carriers
1 x 2-Section Rail kit

- Barebone package (5th/4th Gen): 6NR283S92DR000ABJ1*
- Barebone package (4th Gen): 6NR283S92DR000AAJ1*
- Motherboard: 9AS93FS0UR-000*
- 2-Section Rail kit (CMA not supported): 25HB2-3A0206-K0R
- CPU heatsink: 25ST1-323208-A0R
- Front panel board - CFP2001: 9CFP2001NR-00*
- Backplane board - CBP20O7: 9CBP20O7NR-00*
- Backplane board - CBP2022: 9CBP2022NR-00*
- Fan module: 25ST2-88382T-S1R
- Riser card - CRS101J: 9CRS101JNR-00*
- Riser card - CRS101K: 9CRS101KNR-00*
- Riser card - CRS202G: 9CRS202GNR-00*
- Riser card - CRS202H: 9CRS202HNR-00*
- G-SCM board - CDCR112: 9CDCR112NR-00*
- Mini-DP to D-Sub cable: 25CRN-200801-K1R
- Power supply: 25EP0-22000J-G1S

Optional parts:

- RAID card (SR-1000-ED12): 25FC1-SR1000-AFS
- RAID card (SR-1000-FD32): 25FC1-SRBUN0-AFS
- RAID card (SR-1010-ED32): 25FC1-SRBUN4-AFR
- 3-Section Rail kit (Supports CMA): 25HB2-A56121-K0R
- Cable Management Arm: 25HB1-R18300-K0R
- RMA packaging: 6NR283S92SR-RMA-A100
