H263-S62- AAW1

2U 4-Node - Rear access
440 x 87.5 x 840

MS63-HD1

5th Generation Intel^® Xeon^® Scalable Processors
4th Generation Intel^® Xeon^® Scalable Processors

Dual processor per node, TDP up to 225W

^[Note] If only 1 CPU is installed, some PCIe or memory functions might be unavailable.

8 x LGA 4677
Socket E

Intel^® C741

64 x DIMM slots
DDR5 memory supported
8-Channel memory architecture

5th Gen Intel^® Xeon^®:
RDIMM: Up to 5600 MT/s

4th Gen Intel^® Xeon^®:
RDIMM: Up to 4800 MT/s

Rear:
4 x 10/100/1000 Mbps Management LAN
1 x CMC Management LAN <sup>[1]

[1]</sup> Please refer to optional parts for ring topology support.

^[Note] Spanning Tree Protocol (STP) must be enabled on LAN switches when using a ring topology.

Integrated in Aspeed^® AST2600 x 4
- 4 x VGA ports

Front hot-swap:
24 x 2.5" Gen4 NVMe/SATA/SAS ^[1]
- (NVMe from CPU_1)

Optional internal M.2 (CMTP061 x 4):
4 x M.2 (2280/22110), PCIe Gen4 x4, from CPU_1

^[1] SAS card is required to support SAS drives.

Require SAS add-in cards

Intel^® SATA RAID 0/1/10/5
Onboard VROC key header

Support optional RAID add-in cards

Riser Card CRSH01T x 4:
- 4 x LP x16 (Gen5 x16), from CPU_0

Riser Card CRSH01U x 4:
- 4 x LP x16 (Gen5 x16), from CPU_0

Optional Riser Card CRSH310 x 4:
- 4 x LP x16 (Gen5 x16), from CPU_1

4 x OCP NIC 3.0 (Gen5 x16), from CPU_0
- Support NCSI function

4 x Power buttons with LED
4 x ID buttons with LED
4 x Reset buttons
4 x System status LEDs
1 x CMC status LED
1 x CMC reset button

8 x USB 3.2 Gen1 ports (Type-A)
4 x VGA ports
4 x MLAN ports
4 x ID buttons with LED
1 x CMC port

Speed and bandwidth:
PCIe Gen4 x4 or SATA 6Gb/s or SAS 12Gb/s

1 x TPM header with SPI interface
- Optional TPM2.0 kit: CTM010

Dual 3000W 80 PLUS Titanium redundant power supply ^[1]
Available for 2+1 redundant power supply configuration (optional)

AC Input:
- 100-127V~/ 16A, 50/60Hz
- 200-207V~/ 16A, 50/60Hz
- 208-240V~/ 16A, 50/60Hz

DC Input: (Only for China)
- 240Vdc/ 16A

DC Output:
- Max 1200W/ 100-127V~
+12.2V/ 98.36A
+12.2Vsb/ 3A
- Max 2600W/ 200-207V~
+12.2V/ 213A
+12.2Vsb/ 3A
- Max 3000W/ 208-240V~ or 240Vdc Input
+12.2V/ 245.9A
+12.2Vsb/ 3A

^[1] The system power supply requires C19 power cord.

Aspeed^® AST2600 Baseboard Management Controller
Aspeed^® AST2520 Chassis Management Controller
GIGABYTE Management Console web interface

• Dashboard
• HTML5 KVM
• Sensor Monitor (Voltage, RPM, Temperature, CPU Status …etc.)
• Sensor Reading History Data
• FRU Information
• SEL Log in Linear Storage / Circular Storage Policy
• Hardware Inventory
• Fan Profile
• System Firewall
• Power Consumption
• Power Control
• Advanced power capping
• LDAP / AD / RADIUS Support
• Backup & Restore Configuration
• Remote BIOS/BMC/CPLD Update
• Event Log Filter
• User Management
• Media Redirection Settings
• PAM Order Settings
• SSL Settings
• SMTP Settings

Please refer to OS compatibility table in support page

Additional certifications:
Windows Server 2022

8 x 80x80x38mm (18,300rpm)

Operating temperature: 10°C to 35°C
Operating humidity: 8-80% (non-condensing)
Non-operating temperature: -40°C to 60°C
Non-operating humidity: 20%-95% (non-condensing)

Net Weight: 48.06 kg
Gross Weight: 50.36 kg

1180 x 779 x 300 mm

1 x H263-S62-AAW1
8 x CPU heatsinks
24 x Carriers
1 x 3-Section Rail kit

- Barebone package (5th/4th Gen): 6NH263S62DR000ABW1*
- Barebone package (4th Gen): 6NH263S62DR000AAW1*
- Motherboard: 9MS63HD1UR-000*
- 3-Section Rail kit: 25HB2-A66125-K0R
- CPU heatsink: 25ST1-453207-C1R/25ST1-453208-C1R
- Front panel board - CFPH004: 9CFPH004NR-00*
- Backplane board - CBPH7O1: 9CBPH7O1NR-00*
- Fan module: 25ST2-88382P-S1R/25ST2-88382Q-S1R
- Riser card - CRSH01T: 9CRSH01TNR-00*
- Riser card - CRSH01U: 9CRSH01UNR-00*
- LAN board - CLBH010: 9CLBH010NR-00*
- Power supply: 25EP0-23000L-L0S

Optional parts:

- C19 power cord 125V/15A (US): 25CP1-018000-Q0R
- C19 power cord 250V/16A (EU): 25CP3-01830H-Q0R
- C19 power cord 125V/15A (JP): 25CPA-01830B-Q0R
- M.2 riser card - CMTP061: 9CMTP061NR-00*
- Riser card - CRSH310: 9CRSH310NR-00*
- Ring topology kit (10-kit package): 6NH263S62S1000AAN11
- RMA packaging: 6NH263S62SR-RMA-A100
