G493-SB2-AAP1

4U
448 x 176 x 880

MSB3-G40

5th Generation Intel^® Xeon^® Scalable Processors
4th Generation Intel^® Xeon^® Scalable Processors
Intel^® Xeon^® CPU Max Series

Dual processor, TDP up to 350W

^[Note] If only 1 CPU is installed, some PCIe or memory functions might be unavailable.

2 x LGA 4677
Socket E

Intel^® C741

32 x DIMM slots
DDR5 memory supported
8-Channel memory per processor

5th Gen Intel^® Xeon^®:
RDIMM: Up to 5600 MT/s (1DPC), 4400 MT/s (2DPC)

4th Gen Intel^® Xeon^®:
RDIMM: Up to 4800 MT/s (1DPC), 4400MT/s (2DPC)

Intel^® Xeon^® Max Series:
RDIMM: Up to 4800 MT/s (1DPC), 4400 MT/s (2DPC)

Front (I/O board - CDCG120):
2 x 10Gb/s LAN (1 x Intel^® X710-AT2)
- Support NCSI function

1 x 10/100/1000 Mbps Management LAN

Integrated in Aspeed^® AST2600
- 1 x VGA port

Front hot-swap:
12 x 3.5"/2.5" Gen5 NVMe/SATA/SAS-4 ^[1]
- (2 x NVMe from CPU_0, 2 x NVMe from CPU_1)
- (4 x NVMe from PEX89144_0, 4 x NVMe from PEX89144_1)

Internal M.2:
1 x M.2 (2280/22110), PCIe Gen3 x1, from PCH

^[1] SAS card is required to support SAS drives.

Require SAS add-in cards

Intel^® SATA RAID 0/1/10/5
Onboard VROC key header

Support optional RAID add-in cards

Rear:
4 x FHFL x16 (Gen5 x16), from PEX89144_0, for GPUs
4 x FHFL x16 (Gen5 x16), from PEX89144_1, for GPUs

2 x FHFL x16 (Gen5 x16), from PEX89144_0
2 x FHFL x16 (Gen5 x16), from PEX89144_1

Front:
1 x LP x16 (Gen5 x16), from CPU_0
1 x LP x16 (Gen5 x16), from CPU_1

^[Note] The system is only validated with a uniform GPU model.

I/O board - CDCG120:
2 x USB 3.2 Gen1 ports (Type-A)
1 x VGA port
2 x RJ45 ports
1 x MLAN port
1 x Power button with LED
1 x ID button with LED
1 x NMI button
1 x Reset button
1 x Storage activity LED
1 x System status LED

N/A

Speed and bandwidth:
PCIe Gen5 x4 or SATA 6Gb/s or SAS-4 24Gb/s

1 x TPM header with SPI interface
- Optional TPM2.0 kit: CTM010

3+1 3000W 80 PLUS Titanium redundant power supplies ^[1]

AC Input:
- 100-127V~/ 14.5A, 50/60Hz
- 200-220V~/ 16A, 50/60Hz
- 220-240V~/ 16A, 50/60Hz

DC Input: (Only for China)
- 240Vdc/ 16A

DC Output:
- Max 1097.4W/ 100-127V~
+12.2V/ 87A
+12Vsb/ 3A
- Max 2598W/ 200-220V~
+12.2V/ 210A
+12Vsb/ 3A
- Max 3037.2W/ 220-240V~ or 240Vdc Input
+12.2V/ 246A
+12Vsb/ 3A

^[1] The system power supply requires C19 power cord.

Aspeed^® AST2600 Baseboard Management Controller
GIGABYTE Management Console web interface

• Dashboard
• HTML5 KVM
• Sensor Monitor (Voltage, RPM, Temperature, CPU Status …etc.)
• Sensor Reading History Data
• FRU Information
• SEL Log in Linear Storage / Circular Storage Policy
• Hardware Inventory
• Fan Profile
• System Firewall
• Power Consumption
• Power Control
• Advanced power capping
• LDAP / AD / RADIUS Support
• Backup & Restore Configuration
• Remote BIOS/BMC/CPLD Update
• Event Log Filter
• User Management
• Media Redirection Settings
• PAM Order Settings
• SSL Settings
• SMTP Settings

Please refer to OS compatibility table in support page

Additional certifications:
Windows Server 2022

12 x 60x60x38mm (23,000rpm)*

*Two fans share a single power connector.

Operating temperature: 10°C to 35°C
Operating humidity: 8%-80% (non-condensing)
Non-operating temperature: -40°C to 60°C
Non-operating humidity: 20%-95% (non-condensing)

1200 x 800 x 444 mm w/ pallet

1 x G493-SB2-AAP1
2 x CPU fansinks
8 x GPU power cables (12VHPWR, 150mm)
6 x Carriers
1 x L-shape Rail kit

- Barebone package (5th/4th Gen): 6NG493SB2DR000ABP1*
- Barebone package (4th Gen): 6NG493SB2DR000AAP1*
- Motherboard: 9MSB3G40NR-000*
- L-shape Rail kit: 25HB2-A96100-K0R
- CPU fansink: 25ST1-363204-C1R
- Backplane board - CBP20C7: 9CBP20C7NR-00*
- Fan module: 25ST2-663823-F1R
- I/O board - CDCG120: 9CDCG120UR-00*
- PCIe switch board - CPBGA80: 9CPBGA80NR-00*
- GPU power cable (12VHPWR, 150mm): 25CRI-150004-Y4R
- Power supply: 25EP0-23000C-D0S

Optional parts:

- C19 power cord 125V/15A (US): 25CP1-018000-Q0R
- C19 power cord 250V/16A (EU): 25CP3-01830H-Q0R
- C19 power cord 125V/15A (JP): 25CPA-01830B-Q0R
- RMA packaging: 6NG493SB2SR-RMA-A100
