G363-SR0- LAX1

3U
448 x 130 x 800

MS63-HD2

5th Generation Intel^® Xeon^® Scalable Processors
4th Generation Intel^® Xeon^® Scalable Processors
Intel^® Xeon^® CPU Max Series

Dual processor, TDP up to 385W

^[Note] If only 1 CPU is installed, some PCIe or memory functions might be unavailable.

2 x LGA 4677
Socket E

Intel^® C741

16 x DIMM slots
DDR5 memory supported
8-Channel memory per processor

5th Gen Intel^® Xeon^®:
RDIMM: Up to 5600 MT/s

4th Gen Intel^® Xeon^®:
RDIMM: Up to 4800 MT/s

Intel^® Xeon^® Max Series:
RDIMM: Up to 4800 MT/s

Front (I/O board - CLBH160):
2 x 1Gb/s LAN (1 x Intel^® I350-AM2)
- Support NCSI function (by switch setting)

1 x 10/100/1000 Mbps Management LAN

Rear:
2 x 10Gb/s LAN (1 x Broadcom^® BCM57416)
- Support NCSI function (by switch setting)

Rear (MLAN board - CDB66):
1 x 10/100/1000 Mbps Management LAN

^[Note] When both MLAN ports are connected with cables, the front MLAN port will be set as the default.

Integrated in Aspeed^® AST2600
- 1 x Mini-DP

Front hot-swap:
8 x 2.5" Gen5 NVMe/SATA/SAS ^[1]
- (NVMe from PEX89144)

Internal M.2 (CMTP192):
1 x M.2 (2280/22110), PCIe Gen4 x4, from CPU_0

^[1] SAS card is required to support SAS drives.

Require SAS add-in cards

Intel^® SATA RAID 0/1/10/5

Support optional RAID add-in cards

Liquid-cooled NVIDIA HGX™ H100 with 4 x SXM5 GPUs

Front:
Riser Card CRSH01R:
- 1 x LP x16 (Gen5 x16), from CPU_0

PCIe Cable:
- 1 x LP x16 (Gen5 x16), from CPU_1

1 x OCP NIC 3.0, from CPU_0, disabled

Rear:
4 x LP x16 (Gen5 x16), from PEX89144, support RDMA
- (Equipped with full-height brackets)

1 x Power button with LED
1 x ID button with LED
1 x Reset button
1 x Storage activity LED
1 x System status LED

I/O board - CLBH160:
2 x USB 3.2 Gen1 ports (Type-A)
1 x Mini-DP
2 x RJ45 ports (Intel I350)
1 x MLAN port (default)

2 x RJ45 ports (Broadcom BCM57416)

MLAN board - CDB66:
1 x MLAN port

Speed and bandwidth:
PCIe Gen5 x4 or SATA 6Gb/s or SAS 12Gb/s

1 x TPM header with SPI interface
- Optional TPM2.0 kit: CTM010

2+1 3000W 80 PLUS Titanium redundant power supplies ^[1]

AC Input:
- 115-127V~/ 14.2A, 50-60Hz
- 200-220V~/ 15.8A, 50-60Hz
- 220-240V~/ 14.9A, 50-60Hz

DC Input: (Only for China)
- 240Vdc/ 14A

DC Output:
- Max 1450W/ 115-127V~
+54V/ 26.6A
+12Vsb/ 3A
- Max 2900W/ 200-220V~
+54V/ 53.4A
+12Vsb/ 3A
- Max 3002.4W/ 220-240V~ or 240Vdc Input
+54V/ 55.6A
+12Vsb/ 3A

^[1] The system power supply requires C19 power cord.

Aspeed^® AST2600 Baseboard Management Controller
GIGABYTE Management Console web interface

• Dashboard
• HTML5 KVM
• Sensor Monitor (Voltage, RPM, Temperature, CPU Status …etc.)
• Sensor Reading History Data
• FRU Information
• SEL Log in Linear Storage / Circular Storage Policy
• Hardware Inventory
• Fan Profile
• System Firewall
• Power Consumption
• Power Control
• Advanced power capping
• LDAP / AD / RADIUS Support
• Backup & Restore Configuration
• Remote BIOS/BMC/CPLD Update
• Event Log Filter
• User Management
• Media Redirection Settings
• PAM Order Settings
• SSL Settings
• SMTP Settings

Please refer to OS compatibility table in support page

Additional certifications:
Windows Server 2022

4 x 80x80x80mm (17,000rpm)

Operating temperature: 10°C to 40°C
Operating humidity: 8%-80% (non-condensing)
Non-operating temperature: -40°C to 60°C
Non-operating humidity: 20%-95% (non-condensing)

^[Note] To ensure system stability and prevent condensation, when the relative humidity exceeds 50%, the coolant inlet temperature must be higher than the dry-bulb temperature and it should not exceed 40°C.

Net Weight: 50 kg
Gross Weight: 65.2 kg

1176 x 782 x 295 mm

1 x G363-SR0-LAX1
1 x Mini-DP to D-Sub cable
6 x Carriers
1 x L-shape Rail kit

- Barebone w/ NVIDIA module (5/4th Gen): 6NG363SR0DR000LBX1*
- Barebone w/ NVIDIA module (4th Gen): 6NG363SR0DR000LAX1*
- Motherboard: 9MS63HD2UR-000*
- L-shape Rail kit: 25HB2-A86102-K0R
- CoolIT CPU cold plate loop: 25ST7-100006-C4R
- CoolIT GPU cold plate loop: 25ST7-3000Z5-C4R
- Front panel board - CFP1000: 9CFP1000NR-00*
- Backplane board - CBP2081: 9CBP2081NR-00*
- Fan module: 25ST2-888030-S1R
- Fan module: 25ST2-888031-S1R
- M.2 expansion card - CMTP192: 9CMTP192NR-00*
- Riser card - CRSH01R: 9CRSH01RNR-00*
- OCP card - CNVC171: 9CNVC171NR-00*
- Front I/O board (incl. I350-AM2) - CLBH160: 9CLBH160NR-00*
- PCIe switch board: - CPBG901 9CPBG901NR-00*
- Rear MLAN board - CDB66: 9CDB66NR-00*
- Mini-DP to D-Sub cable: 25CRN-200801-K1R
- Power supply: 25EP0-23000A-D0S

Optional parts:

- C19 power cord 125V/15A (US): 25CP1-018000-Q0R
- C19 power cord 250V/16A (EU): 25CP3-01830H-Q0R
- C19 power cord 125V/15A (JP): 25CPA-01830B-Q0R
- RMA packaging: 6NG363SR0SR-RMA-L100
