E264-AG0-AAS1

Edge Server - Intel^® Xeon^® 6 Processors - 2U UP 4 x PCIe Gen5 GPUs

# AI # AI Training # AI Inference # Visual Computing # HPC # Networking # Edge # Hybrid/Private Cloud Server

Supports up to 4 x Dual slot Gen5 GPUs
Single Intel^® Xeon^® 6 Processors, LGA 7529
12-Channel DDR5 RDIMM / MRDIMM, 12 x DIMMs
Dual ROM Architecture
2 x 2.5" Gen5 NVMe/SATA/SAS-4 hot-swap bays
2 x 2.5" SATA/SAS-4 hot-swap bays
1 x M.2 slot with PCIe Gen5 x2 interface
1 x M.2 slot with PCIe Gen5 x2 interface, shared with SATA
4 x FHFL PCIe Gen5 x16 slots for GPUs
1 x OCP NIC 3.0 PCIe Gen5 x16 slot
2 x 3200W 80 PLUS Titanium redundant power supply

Get a Quote

비교

Get a Quote

* 사이트에서 제공되는 모든 자료는 참조용일 뿐입니다. 기가바이트는 사이트의 자료를 사전 통지없이 언제든지 수정할 권리를 지닙니다.
* 모든 상표와 로고는 해당 소유자의 자산입니다.
* PC의 표준 아키텍쳐에 의해, 메모리의 특정 부분이 시스템에 사용되어 실제 메모리 크기는 표준보다 적게 표시될 수 있습니다.

SPECIFICATIONS

Dimensions (WxHxD, mm)

2U
438 x 87.5 x 620

Motherboard

MAG4-GU0

CPU

Intel^® Xeon^® 6 Processors
- Intel^® Xeon^® 6900-Series Processors

Single processor, TDP up to 500W

Socket

1 x LGA 7529
Socket BR

Chipset

System on Chip

Memory

12 x DIMM slots
DDR5 memory supported
12-Channel memory architecture
MRDIMM supported^[1]
RDIMM: Up to 6400 MT/s
MRDIMM: Up to 8800 MT/s

^[1]MRDIMMs are only supported with Intel^® Xeon^® 6 Processors with P-cores.

LAN

Rear:
1 x 10/100/1000 Mbps Management LAN

Video

Integrated in Aspeed^® AST2600
- 1 x Mini-DP

Storage

Front hot-swap:
2 x 2.5" Gen5 NVMe/SATA/SAS-4^[1][2]
2 x 2.5" SATA/SAS-4^[1][2]

Internal M.2:
1 x M.2 (2280/22110), PCIe Gen5 x2
1 x M.2 (2280/22110), PCIe Gen5 x2, shared with SATA^[3]

^[1]SAS card is required to support SAS drives.
^[2]Only support SSDs.
^[3]To enable the M.2 slot, please adjust the switch according to the manual for proper support.

SAS

Require SAS add-in cards

RAID

Require RAID add-in cards
Onboard VROC key header

PCIe Expansion Slots

Riser Card CRC2023:
- 2 x FHFL x16 (Gen5 x16), for GPUs

Riser Card CRS202Q:
- 1 x FHFL x16 (Gen5 x16), for GPUs

Riser Card CRS201K:
- 1 x FHFL x16 (Gen5 x16), for GPUs

1 x OCP NIC 3.0 (Gen5 x16)
- Supports NCSI function

Front I/O

2 x USB 3.2 Gen1 ports (Type-A)
1 x Power button with LED
1 x ID button with LED
1 x NMI button
1 x Reset button
2 x LAN activity LEDs (disabled)
1 x Storage activity LED
1 x System status LED

Rear I/O

2 x USB 3.2 Gen1 ports (Type-A)
1 x Mini-DP
1 x MLAN port
1 x ID LED

Backplane Board

Speed and bandwidth:
Gen5 NVMe or SATA 6Gb/s or SAS-4 24Gb/s

Security Modules

1 x TPM header with SPI interface
- Optional TPM2.0 kit: CTM012

1 x PRoT connector (only enabled on RoT SKU)

Power Supply

2 x 3200W 80 PLUS Titanium redundant power supply^[1]

AC Input:
- 100-127V~/ 16A, 50-60Hz
- 200-220V~/ 16A, 50-60Hz
- 220-240V~/ 16A, 50-60Hz

DC Input: (Only for China)
- 240Vdc/ 16A

DC Output:
- Max 1300W/ 100-127V~
+12.2V/ 106.6A
+12.2Vsb/ 3A
- Max 3000W/ 200-220V~
+12.2V/ 246A
+12.2Vsb/ 3A
- Max 3200W/ 220-240V~ or 240Vdc Input
+12.2V/ 262.3A
+12.2Vsb/ 3A

^[1]The system power supply requires C19 power cord.
^[Note]GIGABYTE offers PSUs with various efficiency ratings and power outputs. Full redundancy may depend on your server configuration, and alternative PSU options may be needed. Please contact our sales representatives for the best power solution.

System Management

Aspeed^® AST2600 Baseboard Management Controller
GIGABYTE Management Console web interface

Dashboard
HTML5 KVM
Sensor Monitor (Voltage, RPM, Temperature, CPU Status …etc.)
Sensor Reading History Data
FRU Information
SEL Log in Linear Storage / Circular Storage Policy
Hardware Inventory
Fan Profile
System Firewall
Power Consumption
Power Control
Advanced power capping
LDAP / AD / RADIUS Support
Backup & Restore Configuration
Remote BIOS/BMC/CPLD Update
Event Log Filter
User Management
Media Redirection Settings
PAM Order Settings
SSL Settings
SMTP Settings

OS Compatibility

Please refer to OS compatibility table in support page

System Fans

4 x 80x80x56mm (15,500rpm)

Operating Properties

Operating temperature: 10°C to 30°C
Operating humidity: 8%-80% (non-condensing)
Non-operating temperature: -40°C to 60°C
Non-operating humidity: 20%-95% (non-condensing)

Packaging Dimensions

927 x 603 x 300 mm

Packaging Content

1 x E264-AG0-AAS1
1 x CPU heatsink
1 x Mini-DP to D-Sub cable
1 x GPU power cable (12VHPWR, 250mm)
2 x GPU power cables (12VHPWR, 450mm)
1 x GPU power cable (12VHPWR, 550mm)
1 x Carrier
1 x 2-section Rail kit

Part Numbers

- Barebone package: 6NE264AG0DR000AAS1*
- Motherboard: 9MAG4GU0UR-000*
- 2-Section Rail kit (CMA not supported): 25HB2-3A0206-K0R
- CPU heatsink: 25ST1-35310E-M1R
- M.2 heatsink: 12SP2-11000E-00R
- Front panel board - CFP2001: 9CFP2001NR-00*
- Backplane board - CBPE640: 9CBPE640NR-00*
- Fan module: 25ST2-885621-A0R
- Riser card - CRC2023: 9CRC2023NR-00*
- Riser card - CRS201K: 9CRS201KNR-00*
- Riser card - CRS202Q: 9CRS202QNR-00*
- Mini-DP to D-Sub cable: 25CRN-200801-K1R
- GPU power cable (12VHPWR, 250mm): 25CRI-2503B3-Y4R
- GPU power cable (12VHPWR, 450mm): 25CRI-4500B0-Y4R
- GPU power cable (12VHPWR, 550mm): 25CRI-5500B1-Y4R
- Power supply: 25EP0-232000-G1S

Optional parts:

- C19 power cord 125V/15A (US): 25CP1-018000-Q0R
- C19 power cord 250V/16A (EU): 25CP3-01830H-Q0R
- C19 power cord 125V/15A (JP): 25CPA-01830B-Q0R
- 3-Section Rail kit (Supports CMA): 25HB2-A56120-K0R
- Cable Management Arm: 25HBZ-R18100-K0R
