TO15-S41-IA01

ORv3 GPU Server - 5th/4th Gen Intel^® Xeon^® Scalable - 1OU DP 8 x PCIe Gen5 GPUs Immersion

Immersion Ready Server
Supports up to 8 x Single slot Gen5 GPUs
Dual 5th/4th Gen Intel^® Xeon^® Scalable Processors
Dual Intel^® Xeon^® CPU Max Series
8-Channel DDR5 RDIMM, 16 x DIMMs
Dual ROM Architecture
2 x 10Gb/s LAN ports via Broadcom^® BCM57416
4 x 15mm E1.S NVMe hot-swap bays
2 x M.2 slots with SATA interface (optional)
8 x FHFL PCIe Gen5 x16 slots for GPUs
2 x LP PCIe Gen5 x8 slots
48V DC Bus Bar power solution

Get a Quote

* 사이트에서 제공되는 모든 자료는 참조용일 뿐입니다. 기가바이트는 사이트의 자료를 사전 통지없이 언제든지 수정할 권리를 지닙니다.
* 모든 상표와 로고는 해당 소유자의 자산입니다.
* PC의 표준 아키텍쳐에 의해, 메모리의 특정 부분이 시스템에 사용되어 실제 메모리 크기는 표준보다 적게 표시될 수 있습니다.

SPECIFICATIONS

Dimensions (WxHxD, mm)

1OU
537 x 45 x 805.7

Open Rack Version

ORv3

Motherboard

MS43-G21

CPU

5th Generation Intel^® Xeon^® Scalable Processors
4th Generation Intel^® Xeon^® Scalable Processors
Intel^® Xeon^® CPU Max Series

Dual processor, TDP up to 350W

^[Note]If only 1 CPU is installed, some PCIe or memory functions might be unavailable.

Memory

16 x DIMM slots
DDR5 memory supported
8-Channel memory per processor

5th Gen Intel^® Xeon^®:
RDIMM: Up to 5600 MT/s

4th Gen Intel^® Xeon^®:
RDIMM: Up to 4800 MT/s

Intel^® Xeon^® Max Series:
RDIMM: Up to 4800 MT/s

LAN

Top:
2 x 10Gb/s LAN (1 x Broadcom^® BCM57416)
- Support NCSI function

1 x 10/100/1000 Mbps Management LAN

Storage

Top hot-swap:
4 x 15mm E1.S NVMe
- (2 x NVMe from CPU_0, 2 x NVMe from CPU_1)

Optional internal M.2 (COMTP61):
2 x M.2 (2280/22110), SATA, from CPU_1

SAS

N/A

RAID

N/A

PCIe Expansion Slots

Riser Card CORC208 x 2:
- 2 x FHFL x16 (Gen5 x16), from CPU_0, for GPUs
- 2 x FHFL x16 (Gen5 x16), from CPU_1, for GPUs

Riser Card CORC209 x 2:
- 2 x FHFL x16 (Gen5 x16), from CPU_0, for GPUs
- 2 x FHFL x16 (Gen5 x16), from CPU_1, for GPUs

Riser Card CRSG01F x 2:
- 1 x LP x16 (Gen5 x8), from CPU_0
- 1 x LP x16 (Gen5 x8), from CPU_1

Top I/O

2 x USB 3.2 Gen1 ports (Type-A)
1 x VGA port
2 x RJ45 ports
1 x MLAN port
1 x Power button with LED
1 x ID button with LED
1 x NMI button
1 x Reset button
1 x System status LED

System Management

Aspeed^® AST2600 Baseboard Management Controller
GIGABYTE Management Console web interface

Dashboard
HTML5 KVM
Sensor Monitor (Voltage, RPM, Temperature, CPU Status …etc.)
Sensor Reading History Data
FRU Information
SEL Log in Linear Storage / Circular Storage Policy
Hardware Inventory
Fan Profile
System Firewall
Power Consumption
Power Control
Advanced power capping
LDAP / AD / RADIUS Support
Backup & Restore Configuration
Remote BIOS/BMC/CPLD Update
Event Log Filter
User Management
Media Redirection Settings
PAM Order Settings
SSL Settings
SMTP Settings

OS Compatibility

Please refer to OS compatibility table in support page

Additional certifications:
Windows Server 2022

System Fans

N/A

Packaging Dimensions

1095 x 709 x 235 mm

Packaging Content

1 x TO15-S41-IA01
2 x CPU heatsinks
8 x GPU power cables (12VHPWR, 550mm)
6 x Carriers

Part Numbers

- Barebone package (5th/4th Gen): 6NTO15S41DR000IB01*
- Barebone package (4th Gen): 6NTO15S41DR000IA01*
- Motherboard: 9MS43G21UR-000*
- CPU heatsink: 25ST1-25320R-C1R/25ST1-25320S-C1R
- Riser card - CORC208: 9CORC208NR-00*
- Riser card - CORC209: 9CORC209NR-00*
- Riser card - CRSG01F: 9CRSG01FNR-00*
- EDSFF Base board - COBP720: 9COBP720NR-00*
- EDSFF Bypass card - CSPP010: 9CSPP010NR-00*
- GPU power cable (12VHPWR, 550mm): 25CRI-55030B-Y4R

Optional parts:

- M.2 expansion card - COMTP61: 9COMTP61NR-00*
- RMA packaging: 6NTO15S41SR-RMA-I100

No. of Bus Bars

1 x 48V Bus Bar
