H223-V10-AAW1

2U 2-Node - Rear access
440 x 87.5 x 850

MV13-HD0

Per node:
NVIDIA GH200 Grace Hopper Superchip:
- 1 x NVIDIA Grace™ CPU
- 1 x NVIDIA Hopper™ GPU
- Connected with NVIDIA^® NVLink^®-C2C
- TDP up to 1000W (CPU + GPU + memory)

Per node:
NVIDIA Grace CPU:
- Up to 480GB of LPDDR5X memory with ECC
- Memory bandwidth up to 512GB/s

NVIDIA Hopper GPU:
- Up to 96GB HBM3
- Memory bandwidth up to 4TB/s

Rear:
4 x 10Gb/s LAN (2 x Intel^® X550-AT2)
- Support NCSI function

2 x 10/100/1000 Mbps Management LAN
1 x CMC Management LAN

Integrated in Aspeed^® AST2600 x 2
- 2 x Mini-DP

Front hot-swap:
8 x 2.5" Gen5 NVMe

Internal M.2:
4 x M.2 (2280/22110), PCIe Gen5 x4, from PEX89048

N/A

N/A

PCIe Cable x 4:
- 2 x FHHL x16 (Gen5 x16), Dual slot ^[1]
- 2 x FHHL x16 (Gen5 x16), Single slot

2 x OCP NIC 3.0 (Gen5 x16)
- Support NCSI function

^[1] When BlueField-3 DPUs are installed, the ambient temperature is limited to 25℃.

2 x Power buttons with LED
2 x ID buttons with LED
2 x Reset buttons
2 x System status LEDs
1 x CMC status LED
1 x CMC reset button

4 x USB 3.2 Gen1 ports (Type-A)
2 x Mini-DP
4 x RJ45 ports
2 x MLAN ports
2 x ID LEDs
1 x CMC port

Speed and bandwidth:
PCIe Gen5 x4

1 x TPM header with SPI interface
- Optional TPM2.0 kit: CTM012

2+1 3000W 80 PLUS Titanium redundant power supplies ^[1]

AC Input:
- 100-127V~/ 16A, 50/60Hz
- 200-207V~/ 16A, 50/60Hz
- 208-240V~/ 16A, 50/60Hz

DC Input: (Only for China)
- 240Vdc/ 16A

DC Output:
- Max 1200W/ 100-127V~
+12.2V/ 98.36A
+12.2Vsb/ 3A
- Max 2600W/ 200-207V~
+12.2V/ 213A
+12.2Vsb/ 3A
- Max 3000W/ 208-240V~ or 240Vdc Input
+12.2V/ 245.9A
+12.2Vsb/ 3A

^[1] The system power supply requires C19 power cord.

Aspeed^® AST2600 Baseboard Management Controller
Aspeed^® AST2520 Chassis Management Controller
GIGABYTE Management Console web interface

• Dashboard
• HTML5 KVM
• Sensor Monitor (Voltage, RPM, Temperature, CPU Status …etc.)
• Sensor Reading History Data
• FRU Information
• SEL Log in Linear Storage / Circular Storage Policy
• Hardware Inventory
• Fan Profile
• System Firewall
• Power Consumption
• Power Control
• Advanced power capping
• LDAP / AD / RADIUS Support
• Backup & Restore Configuration
• Remote BIOS/BMC/CPLD Update
• Event Log Filter
• User Management
• Media Redirection Settings
• PAM Order Settings
• SSL Settings
• SMTP Settings

Please refer to OS compatibility table in support page

4 x 80x80x80mm (16,500rpm)

Operating temperature: 10°C to 35°C
Operating humidity: 8-80% (non-condensing)
Non-operating temperature: -40°C to 60°C
Non-operating humidity: 20%-95% (non-condensing)

1180 x 706 x 306 mm

1 x H223-V10-AAW1
4 x Superchip heatsinks
1 x Mini-DP to D-Sub cable
1 x 3-Section Rail kit

- Barebone w/ NVIDIA module: 6NH223V10MR000AAW1*
- Motherboard: 9MV13HD0NR-000*
- 3-Section Rail kit: 25HB2-A66125-K0R
- Superchip heatsink: 25ST1-2532Z3-A0R
- Superchip heatsink: 25ST1-2532Z5-A0R
- Front panel board - CFPH004: 9CFPH004NR-00*
- Backplane board - CBPH7O1: 9CBPH7O1NR-00*
- Fan module: 25ST2-888020-S1R
- M.2 riser card - CMTP0A2: 9CMTP0A2NR-00*
- LAN board - CLBH010: 9CLBH010NR-00*
- Mini-DP to D-Sub cable: 25CRN-200801-K1R
- Power supply: 25EP0-23000L-L0S

Optional parts:

- RMA packaging: 6NH223V10SR-RMA-A100
