W771-Z00
GPU Workstation - AMD Ryzen™ Threadripper™ PRO 5000/3000 WX-Series - UP
- Supports up to 4 x Dual slot Gen4 GPUs
- Single AMD Ryzen™ Threadripper™ PRO 5000/3000 WX-Series Processors
- 8-Channel DDR4 UDIMM/RDIMM/LRDIMM, 8 x DIMMs
- 2 x 10Gb/s LAN ports via Intel® X550-AT2
- 1 x 1Gb/s LAN port via Intel® I210-AT
- Up to 8 x 3.5"/2.5" SATA hot-swappable bays (4 x optional bays)
- 2 x M.2 slots with PCIe Gen4 x4 or SATA interface
- 1 x M.2 slot for Wi-Fi add-in cards
- 7 x PCIe Gen4 x16 and x8 slots
- 1+1 2000W 80 PLUS Platinum redundant power supplies
* Les informations ici proposées le sont pour référence uniquement. GIGABYTE se réserve le droit de modifier ce contenu à tout moment et sans préavis.
* Marques et logos appartiennent aux détenteurs respectifs de leurs droits.
* L'architecture de grand nombre de PC affectera directement la capacité mémoire, en effet, une certaine quantité de RAM sera affectée au système, la quantité totale affichée pourra alors varier de celle insérée sur votre carte mère
* Marques et logos appartiennent aux détenteurs respectifs de leurs droits.
* L'architecture de grand nombre de PC affectera directement la capacité mémoire, en effet, une certaine quantité de RAM sera affectée au système, la quantité totale affichée pourra alors varier de celle insérée sur votre carte mère
SPECIFICATIONS
Dimensions (WxHxD, mm)
Pedestal
175 x 438 x 680 mm
175 x 438 x 680 mm
Motherboard
MC62-G40
CPU
AMD Ryzen™ Threadripper™ PRO 5000 WX-Series Processors
AMD Ryzen™ Threadripper™ PRO 3000 WX-Series Processors
Up to 64 cores, 128 threads
TDP up to 280W
AMD Ryzen™ Threadripper™ PRO 3000 WX-Series Processors
Up to 64 cores, 128 threads
TDP up to 280W
Socket
1 x sWRX8
Chipset
AMD WRX80
Memory
8 x DIMM slots
DDR4 memory supported only
8-channel memory architecture
ECC UDIMM supported
Total capacity up to 2TB (256GB LRDIMM)
Memory speed: 3200/2933/2666/2400/2133 MT/s
DDR4 memory supported only
8-channel memory architecture
ECC UDIMM supported
Total capacity up to 2TB (256GB LRDIMM)
Memory speed: 3200/2933/2666/2400/2133 MT/s
LAN
2 x 10Gb/s LAN ports (Intel® X550-AT2)
1 x 1Gb/s LAN port (Intel® I210-AT)
Supports NCSI function on Intel® I210-AT
1 x 10/100/1000 Mbps Management LAN
1 x 1Gb/s LAN port (Intel® I210-AT)
Supports NCSI function on Intel® I210-AT
1 x 10/100/1000 Mbps Management LAN
Video
Integrated in Aspeed® AST2600
2D Video Graphic Adapter with PCIe bus interface
1920x1200@60Hz 32bpp
2D Video Graphic Adapter with PCIe bus interface
1920x1200@60Hz 32bpp
Audio
Realtek® ALC4080 HD Audio Codec
Supports 7.1 channel configuration
3 x Audio Jacks (Audio in/Audio out/Mic)
Supports 7.1 channel configuration
3 x Audio Jacks (Audio in/Audio out/Mic)
Storage
4 x 3.5"/2.5" SATA hot-swappable bays, from FCH
Optional 4 x 3.5"/2.5" SATA hot-swappable bays, from FCH
SAS card is required for SAS devices support
Optional 4 x 3.5"/2.5" SATA hot-swappable bays, from FCH
SAS card is required for SAS devices support
RAID
RAID 0/1/5/10
Peripheral Drives
2 x 5.25" space reserved for ODD devices
Expansion Slots
Slot_7: PCIe x16 (Gen4 x16) slot
Slot_6: PCIe x16 (Gen4 x16) slot
Slot_5: PCIe x16 (Gen4 x16) slot
Slot_4: PCIe x16 (Gen4 x16) slot
Slot_3: PCIe x16 (Gen4 x16) slot
Slot_2: PCIe x16 (Gen4 x8) slot
Slot_1: PCIe x16 (Gen4 x16) slot
2 x M.2 slots for storage:
- M-key
- PCIe Gen4 x4 or SATA, from CPU
- Support 2242/2280 cards
1 x M.2 slot for Wi-Fi:
- E-key
- Supports 2230 cards
Slot_6: PCIe x16 (Gen4 x16) slot
Slot_5: PCIe x16 (Gen4 x16) slot
Slot_4: PCIe x16 (Gen4 x16) slot
Slot_3: PCIe x16 (Gen4 x16) slot
Slot_2: PCIe x16 (Gen4 x8) slot
Slot_1: PCIe x16 (Gen4 x16) slot
2 x M.2 slots for storage:
- M-key
- PCIe Gen4 x4 or SATA, from CPU
- Support 2242/2280 cards
1 x M.2 slot for Wi-Fi:
- E-key
- Supports 2230 cards
Internal I/O
1 x TPM header
Front I/O
2 x USB 3.2 Gen1 (FCH)
1 x Power button
1 x Reset button
1 x Power LED
2 x LAN activity LEDs
1 x Storage activity LED
1 x System status LED
1 x ID LED
1 x Power button
1 x Reset button
1 x Power LED
2 x LAN activity LEDs
1 x Storage activity LED
1 x System status LED
1 x ID LED
Rear I/O
1 x USB 3.2 Gen2x1 (Type-C)(FCH)
4 x USB 3.2 Gen2x1 (Type-A)(CPU)
1 x USB 3.2 Gen2x1 (Type-A)(FCH)
1 x VGA
2 x RJ45 (10Gb/s)
1 x RJ45 (1Gb/s)
1 x MLAN
3 x Audio jacks
1 x ID button with LED
4 x USB 3.2 Gen2x1 (Type-A)(CPU)
1 x USB 3.2 Gen2x1 (Type-A)(FCH)
1 x VGA
2 x RJ45 (10Gb/s)
1 x RJ45 (1Gb/s)
1 x MLAN
3 x Audio jacks
1 x ID button with LED
TPM
1 x TPM header with SPI interface
- Optional TPM2.0 kit: CTM010
- Optional TPM2.0 kit: CTM010
Power Supply
1+1 2000W 80 PLUS Platinum redundant power supplies
AC Input:
- 100-127V~/ 13A, 50-60Hz
- 200-240V~/ 12A, 50-60Hz
DC Output:
- Max 996W/ 90-140V~
+12.2V/ 83A
+12Vsb/ 2.1A
- Max 1560W/ 180-220V~
+12.2V/ 130A
+12Vsb/ 3A
- Max 2000W/ 240-300V~
+12.2V/ 166.7A
+12Vsb/ 3A
AC Input:
- 100-127V~/ 13A, 50-60Hz
- 200-240V~/ 12A, 50-60Hz
DC Output:
- Max 996W/ 90-140V~
+12.2V/ 83A
+12Vsb/ 2.1A
- Max 1560W/ 180-220V~
+12.2V/ 130A
+12Vsb/ 3A
- Max 2000W/ 240-300V~
+12.2V/ 166.7A
+12Vsb/ 3A
System Management
ASPEED® AST2600 Management Controller
GIGABYTE Management Console (AMI MegaRAC SP-X) web interface
GIGABYTE Management Console (AMI MegaRAC SP-X) web interface
- Dashboard
- HTML5 KVM
- Sensor Monitor (Voltage, RPM, Temperature, CPU Status …etc.)
- Sensor Reading History Data
- FRU Information
- SEL Log in Linear Storage / Circular Storage Policy
- Hardware Inventory
- Fan Profile
- System Firewall
- Power Consumption
- Power Control
- Advanced power capping
- LDAP / AD / RADIUS Support
- Backup & Restore Configuration
- Remote BIOS/BMC/CPLD Update
- Event Log Filter
- User Management
- Media Redirection Settings
- PAM Order Settings
- SSL Settings
- SMTP Settings
OS Compatibility
Red Hat Enterprise Linux 8.2 (x64)
Red Hat Enterprise Linux 8.3 (x64)
Ubuntu 20.04 LTS (x64)
Windows 10 (x64)
Windows 11 (x64)
Red Hat Enterprise Linux 8.3 (x64)
Ubuntu 20.04 LTS (x64)
Windows 10 (x64)
Windows 11 (x64)
System Fans
4 x 80x80x38mm (11,000rpm)
2 x 80x80x38mm (8,200rpm)
Optional GPU fan modules are recommended to achieve maximum performance with multiple 300W GPUs.
2 x 80x80x38mm (8,200rpm)
Optional GPU fan modules are recommended to achieve maximum performance with multiple 300W GPUs.
Operating Properties
Operating temperature: 10°C to 35°C
Operating humidity: 8-80% (non-condensing)
Non-operating temperature: -40°C to 60°C
Non-operating humidity: 20%-95% (non-condensing)
Operating humidity: 8-80% (non-condensing)
Non-operating temperature: -40°C to 60°C
Non-operating humidity: 20%-95% (non-condensing)
Weight
Net Weight: 22 kg
Gross Weight: 24 kg
Gross Weight: 24 kg
Packaging Dimensions
1078 x 588 x 388 mm
Packaging Content
1 x W771-Z00
1 x CPU fansink
1 x Quick installation guide
1 x CPU fansink
1 x Quick installation guide
Part Numbers
- Barebone package: 6NW771Z00MR-00-1*
- Motherboard: 9MC62G40MR-00
- CPU fansink (A)+(B):
(A) 25ST2-88382C-D0R (fan)
(B) 25ST1-243103-A0R (heatsink)
- FCH fansink: 12SF2-01A095-00R
- I/O shield: 12AIO-MC62G4-00R
- Power supply: 25EP0-22000G-A0S
Optional parts:
- GPU fan module: 25HB1-MC6200-C0R
- Storage cage: 25HB1-MC6201-C0R
- Rail kit (A)+(B):
(A) 25HB2-A66123-C0R (Slide rail)(Qty: 1)
(B) 25HB4-MC6200-C0R (Handle+Rack ear+Rail screws)(Qty: 1)
- Motherboard: 9MC62G40MR-00
- CPU fansink (A)+(B):
(A) 25ST2-88382C-D0R (fan)
(B) 25ST1-243103-A0R (heatsink)
- FCH fansink: 12SF2-01A095-00R
- I/O shield: 12AIO-MC62G4-00R
- Power supply: 25EP0-22000G-A0S
Optional parts:
- GPU fan module: 25HB1-MC6200-C0R
- Storage cage: 25HB1-MC6201-C0R
- Rail kit (A)+(B):
(A) 25HB2-A66123-C0R (Slide rail)(Qty: 1)
(B) 25HB4-MC6200-C0R (Handle+Rack ear+Rail screws)(Qty: 1)
