MZ72-HB2
Motherboard - AMD EPYC™ 7003/7002 - E-ATX DP AST2600 BMC
- Dual AMD EPYC™ 7003/7002 Series Processors (with AMD 3D V-Cache™ Technology)
- 8-Channel DDR4 RDIMM/LRDIMM, 16 x DIMMs
- 2 x 10Gb/s LAN ports via Broadcom® BCM57416
- 3 x SlimSAS connectors with PCIe Gen4 x4 or SATA interface
- 2 x SlimSAS connectors with PCIe Gen4 x4 interface
- 4 x SATA 6Gb/s ports
- 1 x M.2 slot with PCIe Gen4 x4 interface
- 5 x PCIe Gen4 x16 and x8 expansion slots
* Les informations ici proposées le sont pour référence uniquement. GIGABYTE se réserve le droit de modifier ce contenu à tout moment et sans préavis.
* Marques et logos appartiennent aux détenteurs respectifs de leurs droits.
* L'architecture de grand nombre de PC affectera directement la capacité mémoire, en effet, une certaine quantité de RAM sera affectée au système, la quantité totale affichée pourra alors varier de celle insérée sur votre carte mère
* Marques et logos appartiennent aux détenteurs respectifs de leurs droits.
* L'architecture de grand nombre de PC affectera directement la capacité mémoire, en effet, une certaine quantité de RAM sera affectée au système, la quantité totale affichée pourra alors varier de celle insérée sur votre carte mère
SPECIFICATIONS
Form Factor
E-ATX
305W x 330D mm
305W x 330D mm
CPU
AMD EPYC™ 7003 Series Processors
AMD EPYC™ 7003 Series Processors with AMD 3D V-Cache™ Technology
AMD EPYC™ 7002 Series Processors
Dual processor, 7nm technology
Up to 64 cores, 128 threads per processor
TDP up to 280W
AMD EPYC™ 7003 Series Processors with AMD 3D V-Cache™ Technology
AMD EPYC™ 7002 Series Processors
Dual processor, 7nm technology
Up to 64 cores, 128 threads per processor
TDP up to 280W
Socket
2 x LGA 4094
Socket SP3
Socket SP3
Chipset
System on Chip
Memory
16 x DIMM slots
DDR4 memory supported only
8-Channel memory architecture
RDIMM up to 128GB supported
LRDIMM up to 128GB supported
3DS RDIMM/LRDIMM up to 256GB supported
Memory speed: Up to 3200 MT/s
DDR4 memory supported only
8-Channel memory architecture
RDIMM up to 128GB supported
LRDIMM up to 128GB supported
3DS RDIMM/LRDIMM up to 256GB supported
Memory speed: Up to 3200 MT/s
LAN
2 x 10Gb/s LAN ports (1 x Broadcom® BCM57416)
Support NCSI function
1 x 10/100/1000 Mbps Management LAN
Support NCSI function
1 x 10/100/1000 Mbps Management LAN
Video
Integrated in Aspeed® AST2600
- 1 x VGA port
- 1 x VGA port
Audio
N/A
Storage Interface
CPU_0:
- 2 x SlimSAS connectors for 2 x Gen4 NVMe
- 4 x SATA 6Gb/s ports
CPU_1:
- *3 x SlimSAS connectors for 3 x Gen4 NVMe or 12 x SATA 6Gb/s
*To enable NVMe support, please navigate to the BIOS Setup section, then proceed to Advances > PCI Subsystem settings.
- 2 x SlimSAS connectors for 2 x Gen4 NVMe
- 4 x SATA 6Gb/s ports
CPU_1:
- *3 x SlimSAS connectors for 3 x Gen4 NVMe or 12 x SATA 6Gb/s
*To enable NVMe support, please navigate to the BIOS Setup section, then proceed to Advances > PCI Subsystem settings.
RAID
N/A
Expansion Slots
Slot_6: PCIe x16 (Gen4 x16) slot, from CPU_0
Slot_4: PCIe x16 (Gen4 x16) slot, from CPU_0
Slot_3: PCIe x16 (Gen4 x16) slot, from CPU_1
Slot_2: PCIe x16 (Gen4 x8) slot, from CPU_0
Slot_1: PCIe x16 (Gen4 x8) slot, from CPU_1
1 x M.2 slot:
- M-key
- PCIe Gen4 x4, from CPU_0
- Supports 2280/22110 cards
Slot_4: PCIe x16 (Gen4 x16) slot, from CPU_0
Slot_3: PCIe x16 (Gen4 x16) slot, from CPU_1
Slot_2: PCIe x16 (Gen4 x8) slot, from CPU_0
Slot_1: PCIe x16 (Gen4 x8) slot, from CPU_1
1 x M.2 slot:
- M-key
- PCIe Gen4 x4, from CPU_0
- Supports 2280/22110 cards
Internal I/O
1 x 24-pin ATX main power connector
2 x 8-pin ATX 12V power connectors
2 x CPU fan headers
4 x System fan headers
1 x USB 3.0 header
1 x USB 2.0 header
1 x M.2 slot
5 x SlimSAS connectors
4 x SATA connectors
1 x Front panel header
1 x Backplane board header
1 x PMBus connector
1 x IPMB connector
1 x TPM header
2 x 8-pin ATX 12V power connectors
2 x CPU fan headers
4 x System fan headers
1 x USB 3.0 header
1 x USB 2.0 header
1 x M.2 slot
5 x SlimSAS connectors
4 x SATA connectors
1 x Front panel header
1 x Backplane board header
1 x PMBus connector
1 x IPMB connector
1 x TPM header
Rear I/O
2 x USB 3.0
1 x VGA
1 x COM
2 x RJ45
1 x MLAN
1 x ID button with LED
1 x VGA
1 x COM
2 x RJ45
1 x MLAN
1 x ID button with LED
TPM
1 x TPM header with SPI interface
- Optional TPM2.0 kit: CTM010
- Optional TPM2.0 kit: CTM010
OS Supported
Citrix Hypervisor 8.2.0 or later
Red Hat Enterprise Linux 8.3 or later
Red Hat Enterprise Linux 9.0 or later
SUSE Linux Enterprise Server 12 SP5 or later
SUSE Linux Enterprise Server 15 SP2 or later
Ubuntu 18.04.5 LTS or later
Ubuntu 20.04 LTS or later
Ubuntu 22.04 LTS or later
VMware ESXi 6.7 Update3 P03 or later
VMware ESXi 7.0 Update1 or later
VMware ESXi 8.0 or later
Windows Server 2016 (X2APIC/256T not supported)
Windows Server 2019
Windows Server 2022
Red Hat Enterprise Linux 8.3 or later
Red Hat Enterprise Linux 9.0 or later
SUSE Linux Enterprise Server 12 SP5 or later
SUSE Linux Enterprise Server 15 SP2 or later
Ubuntu 18.04.5 LTS or later
Ubuntu 20.04 LTS or later
Ubuntu 22.04 LTS or later
VMware ESXi 6.7 Update3 P03 or later
VMware ESXi 7.0 Update1 or later
VMware ESXi 8.0 or later
Windows Server 2016 (X2APIC/256T not supported)
Windows Server 2019
Windows Server 2022
Board Management
Aspeed® AST2600 Baseboard Management Controller
GIGABYTE Management Console web interface
GIGABYTE Management Console web interface
- Dashboard
- HTML5 KVM
- Sensor Monitor (Voltage, RPM, Temperature, CPU Status …etc.)
- Sensor Reading History Data
- FRU Information
- SEL Log in Linear Storage / Circular Storage Policy
- Hardware Inventory
- Fan Profile
- System Firewall
- Power Consumption
- Power Control
- Advanced power capping
- LDAP / AD / RADIUS Support
- Backup & Restore Configuration
- Remote BIOS/BMC/CPLD Update
- Event Log Filter
- User Management
- Media Redirection Settings
- PAM Order Settings
- SSL Settings
- SMTP Settings
PSU Connectors
1 x 24-pin ATX main power connector
2 x 8-pin ATX 12V power connectors
2 x 8-pin ATX 12V power connectors
Operating Properties
Operating temperature: 10°C to 40°C
Operating humidity: 8-80% (non-condensing)
Non-operating temperature: -40°C to 60°C
Non-operating humidity: 20%-95% (non-condensing)
Operating humidity: 8-80% (non-condensing)
Non-operating temperature: -40°C to 60°C
Non-operating humidity: 20%-95% (non-condensing)
Retail Packaging Content
1 x MZ72-HB2
1 x I/O shield
1 x Quick start guide
2 x SATA 6Gb/s cables (500mm)
Single Box dimensions: 409 x 355 x 78 mm
Carton dimensions: 729 x 415 x 432 mm
Quantity: 10 x single boxes in one carton
1 x I/O shield
1 x Quick start guide
2 x SATA 6Gb/s cables (500mm)
Single Box dimensions: 409 x 355 x 78 mm
Carton dimensions: 729 x 415 x 432 mm
Quantity: 10 x single boxes in one carton
Bulk Packaging Content
10 x MZ72-HB2
10 x I/O shields
Carton dimensions: 600 x 473 x 495 mm
10 x I/O shields
Carton dimensions: 600 x 473 x 495 mm
Reference Numbers
Retail: 9MZ72HB2MR-00-3*
Bulk: 9MZ72HB2NR-00-3*
Part Numbers:
- I/O shield: 12AIO-MZ72H0-00R
- SATA cable (500mm)(2 in 1 package): 25CF4-500541-K1R
Optional parts:
- CPU fansink (A)+(B)+(C):
(A) Heatsink: 25ST1-243103-A0R
(B) Fan (9,000rpm): 25ST2-88382C-D0R
(C) Fan extension power cable: 25CRI-350B02-A4R
Bulk: 9MZ72HB2NR-00-3*
Part Numbers:
- I/O shield: 12AIO-MZ72H0-00R
- SATA cable (500mm)(2 in 1 package): 25CF4-500541-K1R
Optional parts:
- CPU fansink (A)+(B)+(C):
(A) Heatsink: 25ST1-243103-A0R
(B) Fan (9,000rpm): 25ST2-88382C-D0R
(C) Fan extension power cable: 25CRI-350B02-A4R
