R133-C11- AAG1
Rack Server - AMD EPYC™ 4004 / Ryzen™ 9000 / Ryzen™ 7000 - 1U UP 1 x PCIe Gen5 GPU Titanium
- Supports 1 x Dual slot Gen5 GPU
- Single AMD EPYC™ 4004 / Ryzen™ 9000 / Ryzen™ 7000 Series Processors
- Dual Channel DDR5 ECC/Non-ECC UDIMM, 4 x DIMMs
- 2 x 10Gb/s LAN ports via Broadcom® BCM57416
- 2 x 1Gb/s LAN ports via Broadcom® BCM5720
- 4 x 3.5"/2.5" SATA hot-swap bays
- 4 x 2.5" 7mm SATA hot-swap bays
- 1 x M.2 slot with PCIe Gen4 x4 interface
- 1 x FHFL PCIe Gen5 x16 slot for GPUs
- 1 x FHHL PCIe Gen4 x4 slot
- 1+1 800W 80 PLUS Titanium redundant power supplies
* Les informations ici proposées le sont pour référence uniquement. GIGABYTE se réserve le droit de modifier ce contenu à tout moment et sans préavis.
* Marques et logos appartiennent aux détenteurs respectifs de leurs droits.
* L'architecture de grand nombre de PC affectera directement la capacité mémoire, en effet, une certaine quantité de RAM sera affectée au système, la quantité totale affichée pourra alors varier de celle insérée sur votre carte mère
* Marques et logos appartiennent aux détenteurs respectifs de leurs droits.
* L'architecture de grand nombre de PC affectera directement la capacité mémoire, en effet, une certaine quantité de RAM sera affectée au système, la quantité totale affichée pourra alors varier de celle insérée sur votre carte mère
SPECIFICATIONS
Dimensions (WxHxD, mm)
1U
438 x 43.5 x 710
438 x 43.5 x 710
Motherboard
MC13-BL0
CPU
AMD EPYC™ 4004 Series Processors
AMD Ryzen™ 9000 Series Processors
AMD Ryzen™ 7000 Series Processors
Single processor, TDP up to 170W
[Note] Overclocking is not supported due to thermal limitations.
AMD Ryzen™ 9000 Series Processors
AMD Ryzen™ 7000 Series Processors
Single processor, TDP up to 170W
[Note] Overclocking is not supported due to thermal limitations.
Socket
1 x AM5
Chipset
AMD B650E
Memory
4 x DIMM slots
DDR5 memory supported
Dual Channel memory architecture
AMD Ryzen™ 9000:
UDIMM: Up to 5600 MT/s (1DPC), 3600 MT/s (2DPC)
AMD EPYC™ 4004 / Ryzen™ 7000:
UDIMM: Up to 5200 MT/s (1DPC), 3600 MT/s (2DPC)
DDR5 memory supported
Dual Channel memory architecture
AMD Ryzen™ 9000:
UDIMM: Up to 5600 MT/s (1DPC), 3600 MT/s (2DPC)
AMD EPYC™ 4004 / Ryzen™ 7000:
UDIMM: Up to 5200 MT/s (1DPC), 3600 MT/s (2DPC)
LAN
Rear:
2 x 10Gb/s LAN (1 x Broadcom® BCM57416)
2 x 1Gb/s LAN (1 x Broadcom® BCM5720)
- Support NCSI function (by switch)
1 x 10/100/1000 Mbps Management LAN
2 x 10Gb/s LAN (1 x Broadcom® BCM57416)
2 x 1Gb/s LAN (1 x Broadcom® BCM5720)
- Support NCSI function (by switch)
1 x 10/100/1000 Mbps Management LAN
Video
Integrated in Aspeed® AST2600
- 1 x Mini-DP
- 1 x Mini-DP
Storage
Front hot-swap:
4 x 3.5"/2.5" SATA [1]
4 x 2.5" 7mm SATA [1]
Internal M.2:
1 x M.2 (2280/22110), PCIe Gen4 x4, from FCH
[1] SATA supported only.
4 x 3.5"/2.5" SATA [1]
4 x 2.5" 7mm SATA [1]
Internal M.2:
1 x M.2 (2280/22110), PCIe Gen4 x4, from FCH
[1] SATA supported only.
SAS
N/A
RAID
RAID 0/1/10
PCIe Expansion Slots
PCIe Cable:
- 1 x FHFL x16 (Gen5 x16), from CPU, for GPUs [1]
Riser Card CRSE016:
- 1 x FHHL x4 (Gen4 x4), from CPU
[1] Supports GPUs up to 300W.
- 1 x FHFL x16 (Gen5 x16), from CPU, for GPUs [1]
Riser Card CRSE016:
- 1 x FHHL x4 (Gen4 x4), from CPU
[1] Supports GPUs up to 300W.
Front I/O
1 x USB 3.2 Gen1 port (Type-A)
1 x Power button with LED
1 x ID button with LED
1 x NMI button
1 x Reset button
2 x LAN activity LEDs
1 x Storage activity LED
1 x System status LED
1 x Power button with LED
1 x ID button with LED
1 x NMI button
1 x Reset button
2 x LAN activity LEDs
1 x Storage activity LED
1 x System status LED
Rear I/O
2 x USB 3.2 Gen1 ports (Type-A)
1 x Mini-DP
4 x RJ45 ports
1 x MLAN port
1 x ID button with LED
1 x Mini-DP
4 x RJ45 ports
1 x MLAN port
1 x ID button with LED
Backplane Board
Speed and bandwidth:
SATA 6Gb/s
SATA 6Gb/s
Security Modules
1 x TPM header with SPI interface
- Optional TPM2.0 kit: CTM010
- Optional TPM2.0 kit: CTM010
Power Supply
1+1 800W 80 PLUS Titanium redundant power supplies
AC Input:
- 100-127V~/ 10A, 50-60Hz
- 200-240V~/ 5A, 50-60Hz
DC Input: (Only for China)
- 240Vdc/ 5A
DC Output:
- Max 800W
+12.2V/ 65A
+12.2Vsb/ 3A
AC Input:
- 100-127V~/ 10A, 50-60Hz
- 200-240V~/ 5A, 50-60Hz
DC Input: (Only for China)
- 240Vdc/ 5A
DC Output:
- Max 800W
+12.2V/ 65A
+12.2Vsb/ 3A
System Management
Aspeed® AST2600 Baseboard Management Controller
GIGABYTE Management Console web interface
GIGABYTE Management Console web interface
- Dashboard
- HTML5 KVM
- Sensor Monitor (Voltage, RPM, Temperature, CPU Status …etc.)
- Sensor Reading History Data
- FRU Information
- SEL Log in Linear Storage / Circular Storage Policy
- Hardware Inventory
- Fan Profile
- System Firewall
- Power Consumption
- Power Control
- Advanced power capping
- LDAP / AD / RADIUS Support
- Backup & Restore Configuration
- Remote BIOS/BMC/CPLD Update
- Event Log Filter
- User Management
- Media Redirection Settings
- PAM Order Settings
- SSL Settings
- SMTP Settings
OS Compatibility
EPYC 4004 Series:
Ubuntu 22.04
Ubuntu 24.04
Windows Server 2022
Ryzen 9000/7000 Series:
Windows 10 21H2
Windows 11
Ubuntu 22.04
Ubuntu 24.04
Windows Server 2022
Ryzen 9000/7000 Series:
Windows 10 21H2
Windows 11
System Fans
2 x 40x40x56mm (29,700rpm)
3 x 40x40x56mm (32,000rpm)
3 x 40x40x56mm (32,000rpm)
Operating Properties
Operating temperature: 10°C to 30°C
Operating humidity: 8%-80% (non-condensing)
Non-operating temperature: -40°C to 60°C
Non-operating humidity: 20%-95% (non-condensing)
Operating humidity: 8%-80% (non-condensing)
Non-operating temperature: -40°C to 60°C
Non-operating humidity: 20%-95% (non-condensing)
Weight
Net Weight: 16.8 kg
Gross Weight: 18.8 kg
Gross Weight: 18.8 kg
Packaging Dimensions
977 x 588 x 236 mm
Packaging Content
1 x R133-C11-AAG1
1 x CPU heatsink
1 x Mini-DP to D-Sub cable
1 x GPU power cable (2x PCIe 8pin, 700mm)
1 x 2-Section Rail kit
1 x CPU heatsink
1 x Mini-DP to D-Sub cable
1 x GPU power cable (2x PCIe 8pin, 700mm)
1 x 2-Section Rail kit
Part Numbers
- Barebone package (EPYC/Ryzen 9000): 6NR133C11MR000ACG1*
- Barebone package (EPYC/Ryzen 7000): 6NR133C11MR000ABG1*
- Barebone package (Ryzen 7000): 6NR133C11MR000AAG1*
- Motherboard: 9MC13BL0NR-000*
- 2-Section Rail kit (CMA not supported): 25HB2-3A0203-K0R
- CPU heatsink: 25ST1-443300-S7R
- M.2 heatsink: 12SP2-11000E-00R
- Front panel board - CFP1010: 9CFP1010NR-00*
- Backplane board - CBP1045: 9CBP1045NR-00*
- Backplane board - CBP1047: 9CBP1047NR-00*
- Fan module: 25ST2-405623-A0R/25ST2-40562H-A0R
- Riser card - CRSE016: 9CRSE01016NR-00*
- Mini-DP to D-Sub cable: 25CRN-200801-K1R
- GPU power cable (2x PCIe 8pin, 700mm): 25CRI-700004-G5R
- Power supply: 25EP0-20800C-G1S
Optional parts:
- 3-Section Rail kit (Supports CMA): 25HB2-A56120-K0R
- Cable Management Arm: 25HBZ-R18100-K0R
- Barebone package (EPYC/Ryzen 7000): 6NR133C11MR000ABG1*
- Barebone package (Ryzen 7000): 6NR133C11MR000AAG1*
- Motherboard: 9MC13BL0NR-000*
- 2-Section Rail kit (CMA not supported): 25HB2-3A0203-K0R
- CPU heatsink: 25ST1-443300-S7R
- M.2 heatsink: 12SP2-11000E-00R
- Front panel board - CFP1010: 9CFP1010NR-00*
- Backplane board - CBP1045: 9CBP1045NR-00*
- Backplane board - CBP1047: 9CBP1047NR-00*
- Fan module: 25ST2-405623-A0R/25ST2-40562H-A0R
- Riser card - CRSE016: 9CRSE01016NR-00*
- Mini-DP to D-Sub cable: 25CRN-200801-K1R
- GPU power cable (2x PCIe 8pin, 700mm): 25CRI-700004-G5R
- Power supply: 25EP0-20800C-G1S
Optional parts:
- 3-Section Rail kit (Supports CMA): 25HB2-A56120-K0R
- Cable Management Arm: 25HBZ-R18100-K0R
