Imagine if your spare could change itself
You need DualBIOS™
Automated Dual Protection
Against BIOS Failure

GIGABYTE DualBIOS™ Motherboards
What if the BIOS Fails?
Have you ever been in the middle of a BIOS update and then had it fail for some reason? Or how about executing some applications only to find out that you've been infected by some new virus that completely renders your BIOS inoperable? If this has ever happened to you, you know how difficult it can be to fix the problem. Without the BIOS working, the motherboard is basically not functional at all, since it is unable to boot. Often, the only way to get your system up and running again is to send your board in for an RMA so the BIOS chip can be physically replaced.

TOP
What is the BIOS?
The BIOS (Basic Input/Output System) is a chip that has the software code to operate your computer when the system is first turned on. One primary function of BIOS is to direct the computer to execute various tasks before the operating system kicks in. The BIOS also controls certain functions on your system such as power management features, overclocking settings allowing you to change CPU frequencies to tweak desired performance from our system and a host of other functions.

TOP
GIGABYTE DualBIOS™
10 years ago, GIGABYTE engineers developed the unique GIGABYTE DualBIOS™ solution to automatically get your system up and running again without you having to do a thing.
  Patented
Dual Hardware BIOS
Protection

TOP
How does GIGABYTE DualBIOS™ Work?
GIGABYTE DualBIOS™ feature two physical BIOS ROMS mounted onto the motherboard. One chip acts as your "Main" BIOS, or the BIOS your system primarily uses during boot up. The second chip acts as a "Backup" BIOS and has the factory default BIOS version on it. If your "Main" BIOS happens to fail or stops functioning, the "Backup" will automatically take over on your next system boot with little or no down time.
Automatically invoked to recover Main BIOS, Only mission is to play the role of BIOS Recovery Agent
Work as normal BIOS
Boot
Start
BIOS
check
-
Pass
Hard
ware
check
- Pass
  Boot sequence
- On
Boot
UP !

BIOS
FAIL
Backup
BIOS
kick in
  Restore
data to
main
BIOS

Re-start BIOS Boot Up sequence

This process is completely automatic. When you discover you have a problem, all you need to do is shut the system down and then boot up again. The GIGABYTE DualBIOS™ does the rest. When there is a BIOS firmware failure detected, the "Backup" BIOS will first recover the "Main" BIOS file back to its factory default BIOS version, and everything is back to normal again. If the BIOS failure is due to actual hardware damage, the Backup BIOS will take over and function as the Main BIOS.
  Automatically recovers
Main BIOS data by
Backup BIOS when
Main BIOS has crashed
or failed



DualBIOS™ Benefits :
1. Repair failure BIOS instantly
2. Fully automated without
user intervention
3. Reduce service time



Any sort of event that causes the "Main" BIOS chip to fail, whether it is a virus attacking your system, or a user incorrectly flashing the BIOS, the "Backup" kicks in and gets your system up and running automatically.

What might cause a BIOS Failure?
1. Power shut down during BIOS update process
2. Improper Overclocking settings
3. Virus attacks
4. Hardware Failure

TOP
DualBIOS™ vs. Traditional single BIOS
Feature
  GIGABYTE DualBIOS™
  Single BIOS

2 physical BIOS ROMs onboard provide
double protection against virus attack and
firmware / physical damage
Yes No
Auto recovery from backup BIOS when
main BIOS firmware is damaged
Yes No

TOP
GIGABYE DualBIOS™ Motherboards

Intel Platform

Chipset Model

X58

GA-EX58-EXTREME GA-EX58-UD5 GA-EX58-UD4P
GA-EX58-UD4 GA-EX58-UD3R GA-EX58-UD3R-SLI

P45

GA-EP45-UD3P GA-EP45-UD3R GA-EP45T-UD3P
GA-EP45T-UD3R GA-EP45-UD3L GA-EP45-UD3LR
GA-EP45T-UD3LR
G45 GA-EG45M-UD2H GA-EG45M-DS2H
P43 GA-P43-ES3G GA-EP43-UD3L GA-EP43-US3L
G41 GA-EG41MF-S2H GA-EG41M-S2H GA-G41M-ES2L
*Intel X58/P45/G45/P43/G43/G41 all series motherboards support Dual BIOS function.

AMD Platform

Chipset Model

790FX

GA-MA790FXT-UD5P (rev. 1.0)
 Socket AM3
GA-MA790FX-DQ6 (rev. 1.0) GA-MA790FX-DS5 (rev. 1.0)
GA-MA790FX-UD5P (rev. 1.0)

790GX

GA-MA790GP-UD4H (rev. 1.0) GA-MA790GP-US4H (rev. 1.0)

790X

GA-MA790XT-UD4P (rev. 1.0)
 Socket AM3
GA-MA790X-UD4(rev.1.0) GA-MA790X-DS4(rev. 1.x)
GA-MA790X-UD4P (rev.1.0)

770

GA-MA770-UD3 (rev. 1.0) GA-MA770-US3(rev. 1.0)  GA-MA770-DS3P (rev. 2.0)
GA-MA770-S3P (rev. 2.0)  GA-MA770-DS3 (rev. 2.0)  GA-MA770-S3 (rev. 2.0)

780G

GA-MA78GM-US2H (rev.1.0) GA-MA78G-DS3HP (rev. 2.0) GA-MA78GPM-DS2H(rev. 1.x)
GA-MA78GM-DS2HP (rev. 2.1) GA-MA78GM-S2HP(rev. 2.1) GA-MA780G-UD3H(rev .1.0)
GA-MA78G-DS3H (rev. 1.0) GA-MA78G-DS3H (rev. 2.x) GA-MA78GM-DS2H (rev. 2.x)
GA-MA78GM-DS2H (rev. 1.0) GA-MA78GM-S2H (rev. 2.x) GA-MA78GM-UD2H (rev. 1.0)
GA-MA78GPM-UD2H (rev .1.0)

NVIDIA nForce 750a SLI

GA-M750SLI-DS4 (rev 1.0)

NVIDIA GeForce 720D

GA-M720-US3 (rev 1.0)

NVIDIA GeForce 6100 / nForce 430

GA-M61PME-S2P (rev 1.0)

NVIDIA nForce 520LE

GA-M52L-S3P (rev 1.0)

NVIDIA nForce 590 SLI

GA-M59SLI-S5 (rev 1.0)

*Please refer to GIGABYTE website for more Dual BIOS models.
