- S251-3O0
- Single-Phase Immersion Ready Server
- 2nd Gen Intel® Xeon® Scalable Processors
- Intel® Xeon® W-3200 Processor Family
- Single processor, LGA 3647
- 6-Channel RDIMM/LRDIMM DDR4, 8 x DIMMs
- Supports Intel® Optane™ Persistent Memory
- Dual 1Gb/s LAN port (Intel® I210-AT)
- 1 x Dedicated management port
- 24 x 3.5" SATA/SAS hot-swappable bays
- 2 x 2.5" SATA hot-swappable bays on rear side
- Onboard 12Gb/s SAS expander
- 1 x M.2 slot with PCIe Gen3 x4 interface
- Up to 7 x LP PCIe Gen3 x16, x8, and x4 slots
- 1+1 1300W 80 PLUS Titanium redundant power supplies
* Todos los materiales aquí provistos son sólo para referencia. GIGABYTE se reserva el derecho de modificar o revisar el contenido a cualquier hora sin aviso alguno.
* Todas las marcas y logos son propiedad de sus propios dueños.
* Debido a la arquitectura estándar de la PC, cierta cantidad de memoria es reservada para uso del sistema y actualmente la memoria disponible es menor a la mencionada.
* Todas las marcas y logos son propiedad de sus propios dueños.
* Debido a la arquitectura estándar de la PC, cierta cantidad de memoria es reservada para uso del sistema y actualmente la memoria disponible es menor a la mencionada.
SPECIFICATIONS
Dimensions (WxHxD, mm)
2U
438 x 87 x 880
438 x 87 x 880
Motherboard
MU71-SU0
CPU
2nd Generation Intel® Xeon® Scalable Processors
Intel® Xeon® Platinum Processor, Intel® Xeon® Gold Processor, Intel® Xeon® Silver Processor and Intel® Xeon® Bronze Processor
Intel® Xeon® W-3200 Processor Family
Single processor
Intel® Xeon® Platinum Processor, Intel® Xeon® Gold Processor, Intel® Xeon® Silver Processor and Intel® Xeon® Bronze Processor
Intel® Xeon® W-3200 Processor Family
Single processor
Socket
1 x LGA 3647
Socket P
Socket P
Chipset
Intel® C621 Chipset
Memory
8 x DIMM slots
DDR4 memory supported only
6-channel memory architecture
RDIMM modules up to 128GB supported
LRDIMM modules up to 128GB supported
Supports Intel® Optane™ Persistent Memory (PMem)
1.2V modules: 2933/2666/2400/2133 MHz
DDR4 memory supported only
6-channel memory architecture
RDIMM modules up to 128GB supported
LRDIMM modules up to 128GB supported
Supports Intel® Optane™ Persistent Memory (PMem)
1.2V modules: 2933/2666/2400/2133 MHz
LAN
Rear side:
2 x 1Gb/s LAN ports (Intel® I210-AT)
1 x 10/100/1000 management LAN
2 x 1Gb/s LAN ports (Intel® I210-AT)
1 x 10/100/1000 management LAN
Video
Integrated in Aspeed® AST2500
2D Video Graphic Adapter with PCIe bus interface
1920x1200@60Hz 32bpp, DDR4 SDRAM
2D Video Graphic Adapter with PCIe bus interface
1920x1200@60Hz 32bpp, DDR4 SDRAM
Storage
Side-accessed:
24 x 3.5" SATA/SAS hot-swappable bays
LSI SAS35x36R expander
SAS card is required to enable the 24 drive bays
Rear side:
2 x 2.5" SATA hot-swappable bays, NVMe supported with optional CNV3022 NVMe Card
Default configuration supports:
2 x SATA drives on rear side
Recommend optional 12Gb/s SAS cards:
CRA4448 (Hardware RAID Card)
CSA4648 (Software HBA Card)
24 x 3.5" SATA/SAS hot-swappable bays
LSI SAS35x36R expander
SAS card is required to enable the 24 drive bays
Rear side:
2 x 2.5" SATA hot-swappable bays, NVMe supported with optional CNV3022 NVMe Card
Default configuration supports:
2 x SATA drives on rear side
Recommend optional 12Gb/s SAS cards:
CRA4448 (Hardware RAID Card)
CSA4648 (Software HBA Card)
SAS
Supported via add-on SAS Card
RAID
Depends on RAID card
Expansion Slots
Total 7 x PCIe Gen3 low-profile slots
Slot_7: 1 x PCIe x16 (Gen3 x0 or x8) slot, from CPU
Slot_6: 1 x PCIe x16 (Gen3 x16 or x8) slot, from CPU, shared with Slot_7
Slot_5: 1 x PCIe x16 (Gen3 x0 or x8) slot, from CPU
Slot_4: 1 x PCIe x16 (Gen3 x16 or x8) slot, from CPU, shared with Slot_5
Slot_3: 1 x PCIe x16 (Gen3 x0 or x8) slot, from CPU, reserved for optional NVMe Card
Slot_2: 1 x PCIe x16 (Gen3 x16 or x8) slot, from CPU, shared with Slot_3, reserved for optional SAS Card
Slot_1: 1 x PCIe x4 (Gen3 x4) slot, from PCH
1 x M.2 slot:
- M-key
- PCIe Gen3 x4, from PCH
- Supports NGFF-2280 cards
Slot_7: 1 x PCIe x16 (Gen3 x0 or x8) slot, from CPU
Slot_6: 1 x PCIe x16 (Gen3 x16 or x8) slot, from CPU, shared with Slot_7
Slot_5: 1 x PCIe x16 (Gen3 x0 or x8) slot, from CPU
Slot_4: 1 x PCIe x16 (Gen3 x16 or x8) slot, from CPU, shared with Slot_5
Slot_3: 1 x PCIe x16 (Gen3 x0 or x8) slot, from CPU, reserved for optional NVMe Card
Slot_2: 1 x PCIe x16 (Gen3 x16 or x8) slot, from CPU, shared with Slot_3, reserved for optional SAS Card
Slot_1: 1 x PCIe x4 (Gen3 x4) slot, from PCH
1 x M.2 slot:
- M-key
- PCIe Gen3 x4, from PCH
- Supports NGFF-2280 cards
Internal I/O
1 x M.2 slot
1 x CPU fan header
6 x System fan headers
1 x USB 3.2 Gen1 header
1 x TPM header
1 x VROC connector
1 x Front panel header
1 x Buzzer
1 x CPU fan header
6 x System fan headers
1 x USB 3.2 Gen1 header
1 x TPM header
1 x VROC connector
1 x Front panel header
1 x Buzzer
Front I/O
2 x USB 3.2 Gen1
1 x Power button with LED
1 x ID button with LED
1 x Reset button
1 x System status LED
1 x HDD activity LED
2 x LAN activity LEDs
1 x Power button with LED
1 x ID button with LED
1 x Reset button
1 x System status LED
1 x HDD activity LED
2 x LAN activity LEDs
Rear I/O
4 x USB 3.2 Gen1
1 x VGA
1 x COM
2 x RJ45
1 x MLAN
1 x ID button with LED
1 x VGA
1 x COM
2 x RJ45
1 x MLAN
1 x ID button with LED
Backplane Board
Left side: CBPD2C0: 12 x 3.5" SATA/SAS ports with expander
Right side: CBPD2C1: 12 x 3.5" SATA/SAS ports
Rear side: CBPD020: 2 x 2.5" NVMe/SATA hybrid ports
Right side: CBPD2C1: 12 x 3.5" SATA/SAS ports
Rear side: CBPD020: 2 x 2.5" NVMe/SATA hybrid ports
TPM
1 x TPM header with SPI interface
Optional TPM2.0 kit: CTM010
Optional TPM2.0 kit: CTM010
Power Supply
1+1 1300W 80 PLUS Titanium redundant power supplies
AC Input:
- 100-127V~/ 12A, 50-60Hz
- 200-240V~/ 8A, 50-60Hz
DC Input:
- 240Vdc/ 7A
DC Output:
- Max 1000W/ 100-127V~
+ 12.2V/ 82A
+ 12Vsb/ 3A
- Max 1300W/ 200-240V~
+ 12.2V/ 106A + 12Vsb/ 3A
AC Input:
- 100-127V~/ 12A, 50-60Hz
- 200-240V~/ 8A, 50-60Hz
DC Input:
- 240Vdc/ 7A
DC Output:
- Max 1000W/ 100-127V~
+ 12.2V/ 82A
+ 12Vsb/ 3A
- Max 1300W/ 200-240V~
+ 12.2V/ 106A + 12Vsb/ 3A
System Management
Aspeed® AST2500 management controller
GIGABYTE Management Console (AMI MegaRAC SP-X) web interface
GIGABYTE Management Console (AMI MegaRAC SP-X) web interface
- Dashboard
- JAVA Based Serial Over LAN
- HTML5 KVM
- Sensor Monitor (Voltage, RPM, Temperature, CPU Status …etc.)
- Sensor Reading History Data
- FRU Information
- SEL Log in Linear Storage / Circular Storage Policy
- Hardware Inventory
- Fan Profile
- System Firewall
- Power Consumption
- Power Control
- LDAP / AD / RADIUS Support
- Backup & Restore Configuration
- Remote BIOS/BMC/CPLD Update
- Event Log Filter
- User Management
- Media Redirection Settings
- PAM Order Settings
- SSL Settings
- SMTP Settings
OS Compatibility
Windows Server 2012 R2 with Update
Windows Server 2016
Windows Server 2019
Red Hat Enterprise Linux 7.6 (x64) or later
Red Hat Enterprise Linux 8.0 (x64) or later
Red Hat Enterprise Linux 9.0 (x64) or later
SUSE Linux Enterprise Server 12 SP3 (x64) or later
SUSE Linux Enterprise Server 15 (x64) or later
Ubuntu 18.04 LTS (x64) or later
Ubuntu 20.04 LTS (x64) or later
Ubuntu 22.04 LTS (x64) or later
VMware ESXi 6.0 Update3 or later
VMware ESXi 6.5 Update2 or later
VMware ESXi 6.7 Update1 or later
VMware ESXi 7.0 or later
VMware ESXi 8.0 or later
Citrix Xenserver 7.1.0 CU2 or later
Citrix Xenserver 7.5.0 or later
Citrix Hypervisor 8.0.0 or later
Windows Server 2016
Windows Server 2019
Red Hat Enterprise Linux 7.6 (x64) or later
Red Hat Enterprise Linux 8.0 (x64) or later
Red Hat Enterprise Linux 9.0 (x64) or later
SUSE Linux Enterprise Server 12 SP3 (x64) or later
SUSE Linux Enterprise Server 15 (x64) or later
Ubuntu 18.04 LTS (x64) or later
Ubuntu 20.04 LTS (x64) or later
Ubuntu 22.04 LTS (x64) or later
VMware ESXi 6.0 Update3 or later
VMware ESXi 6.5 Update2 or later
VMware ESXi 6.7 Update1 or later
VMware ESXi 7.0 or later
VMware ESXi 8.0 or later
Citrix Xenserver 7.1.0 CU2 or later
Citrix Xenserver 7.5.0 or later
Citrix Hypervisor 8.0.0 or later
System Fans
N/A
Operating Properties
Operating coolant temperature: 25°C to 35°C
Non-operating temperature: -40°C to 60°C
Non-operating humidity: 20%-95% (non-condensing)
Non-operating temperature: -40°C to 60°C
Non-operating humidity: 20%-95% (non-condensing)
Packaging Dimensions
1092 x 664 x 289 mm
Packaging Content
1 x S251-3O0
1 x CPU heatsink
2 x Non-Fabric CPU carriers
1 x CPU heatsink
2 x Non-Fabric CPU carriers
Part Numbers
- Barebone package: 6NS2513O0MR000IBH1*
- Motherboard: 9MU71SU0MR-00
- CPU heatsink: 25ST1-353105-T1R
- Backplane board_12-port_L_Side: 9CBPD2C0NR-00
- Backplane board_12-port_R_Side: 9CBPD2C1NR-00
- Backplane board_2-port_Rear_Side: 9CBPD020NR-00
- Power supply: 25EP0-213008-G1S
- 2-port NVMe card : 9CNV3022NR-00 (Optional)
- 12Gb/s SAS H/W RAID card : 9CRA4448NR-00 (Optional)
- 12Gb/s SAS S/W RAID card : 9CSA4648NR-00 (Optional)
- Motherboard: 9MU71SU0MR-00
- CPU heatsink: 25ST1-353105-T1R
- Backplane board_12-port_L_Side: 9CBPD2C0NR-00
- Backplane board_12-port_R_Side: 9CBPD2C1NR-00
- Backplane board_2-port_Rear_Side: 9CBPD020NR-00
- Power supply: 25EP0-213008-G1S
- 2-port NVMe card : 9CNV3022NR-00 (Optional)
- 12Gb/s SAS H/W RAID card : 9CRA4448NR-00 (Optional)
- 12Gb/s SAS S/W RAID card : 9CSA4648NR-00 (Optional)
